9540-00-487-5676
Structural Beam
9540004875676 004875676 AMS4617 AND10136-2407 AMS 10136-2407 AMS-QQ-A-200/11 QQA200-11
A structural shape fabricated from a ferrous or nonferrous material and resembles the following cross-sectional forms: For the letter H, both flanges of the H section are equal or longer than the width measured along the axis of the web; for the letter I, a 16 2/3 percent slope on the inside face of the ferrous type flange, either one or both of the nonferrous type flanges are shorter than the length measured along the axis of the web; for the letters T and Z, on nonferrous type, the web is usually at right angles to the flanges. Letter H section may have a maximum of 5 percent slope on the inside face of the flanges. View more Structural Beam
November 2023
9
Marketplace 9540-00-487-5676
Request a Quotation from participating marketplace vendors
Updated Every 15 Minutes
Updated Every Day Updated Every Day
Updated Every Day Related Documents 9540-00-487-5676 5+ Documents (More...)
-200/11 ,AMS4617 Metal AMS-QQ-A -200/11 https//www.nsnlookup.com - 200/11 ,AMS4617 Metal AMS-QQ-A -200
/11 Metal AMS-QQ-A-200/11 ,AMS4617 Metal /www.nsnlookup.com -200 /11 MMS158 AMS-QQ-A-200/11 ,AMS4617
- 200/11 ,AMS4617 Metal AMS-QQ-A -200/11 Metal AMS-QQ-A-200/11 ,AMS4617 Metal /www.nsnlookup.com -200
/11 MMS158 AMS-QQ-A-200/11 ,AMS4617 https//www.nsnlookup.com /fsg-95/fsc-9540/us 9540-00-487-5676 Structural
,AMS4617 Metal AMS-QQ-A-200/11 MMS158 https//www.nsnlookup.com ,AMS4617 AMS-QQ-A-200/11 013634308 010518359
,AMS4617 ,AMS4617 Metal AMS-QQ-A-200/11 MMS158 https//www.nsnlookup.com -200/11 MMS158 AMS-QQ-A-200/11
AMS4617 Metal AMS-QQ-A -200/11 https//www.nsnlookup.com 9540004875676004875676 /fsg-95/fsc-9540/us 9540
https ,AMS4617 https Quotation ASTM-B221 -T73511 /11 MMS158 AMS-QQ-A-200/11 MMS158 https//www.nsnlookup.com
,AMS4617 Metal AMS-QQ-A-200 ,AMS4617 ,AMS4617 Metal AMS-QQ-A-200/11 /us 9530-01-051-8359 Metal https
,AMS4617 Metal AMS-QQ-A-200/11 MMS158 https//www.nsnlookup.com 013634308 010518359,AMS4617 , AMS4617
Restrictions 9540-00-487-5676
9540-00-487-5676 is a Structural Beam that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 9540-00-487-5676
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 9540-00-487-5676
- US Air Force (FGGI)
- Effective Date:
- 1 Mar 2006
- Former MOE Rule:
- FGKZ
Approved Sources 9540-00-487-5676
- Part Number
- Manufacturer
- Status
- AMS4617
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AMS 10136-2407
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AND10136-2407
- 99237 - Airforce-Navy Aeronautical Design (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AMS 10136-2407
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- AMS-QQ-A-200/11
- 0U583 - Sae International (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- QQA200-11
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AMS-QQ-A-200/11
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 9540-00-487-5676
- Characteristic
- Specifications
- FIIG
- Specifications
- A13100
- Basic Shape Style [AGTA]
- T Shape
- Fabrication Method [AARN]
- Extruded
- Fillet Radius Where Top Left Flange Joins Web Flange/Leg [BPXJ]
- 0.125 Inches Nominal
- Fillet Radius Where Top Right Flange Joins Web Flange/Leg [BPXL]
- 0.125 Inches Nominal
- First Tip Radius [AJJB]
- 0.125 Inches Nominal
- First Tip Style [CMZY]
- Lower Radius
- Heat Treatment [HEAT]
- T-73511 Solution Heat Treated
- Material [MATT]
- Aluminum Alloy Ams-Qq-A-200/11, Alloy 7075
- Nondefinitive Spec/Std Data [ZZZT]
- T73511 Temper
- Left Side Top Flange Distance To Center Of Both Flanges [BPXD]
- 1.250 Inches Nominal
- Left Side Top Flange Thickness [ADXR]
- 0.125 Inches Nominal
- Left Top Inside Angle [CSMZ]
- 90.0 Degrees Nominal
- Leg Thickness [AJJP]
- 0.125 Inches Nominal
- Length [ABRY]
- 10.000 Feet Minimum And 12.000 Feet Maximum
- Right Side Top Flange Distance To Center Of Both Flanges [BPXG]
- 1.250 Inches Nominal
- Right Side Top Flange Thickness [ADXS]
- 0.125 Inches Nominal
- Right Top Inside Angle [CRZC]
- 90.0 Degrees Nominal
- Second Tip Relationship To First Tip [CNQJ]
- Identical
- Overall Height [ABKW]
- 2.000 Inches Nominal
- Top Flange Width [BQJG]
- 2.500 Inches Nominal
- Weight Per Unit Measure [BRFD]
- 0.650 Pounds Per Linear Foot
- Third Tip Radius [CNBB]
- 0.062 Inches Nominal
- Third Tip Relationship To Preceding Tips [CNQL]
- Not Identical
- Third Tip Style [CNQM]
- Full Radius
Weapon Systems (WSDC) 9540-00-487-5676
DLA Procurement Analysis 9540-00-487-5676
- Last Stock Position:
- 281 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 9540-00-487-5676
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Air Force (DF)
- FT
- Subscribe
- 1
- FT
- Apr 2022
- Department of the Air Force (DF)
- FT
- Subscribe
- 1
- FT
- Oct 2021
- Department of the Air Force (DF)
- FT
- Subscribe
- 1
- FT
- Oct 2020
- Department of the Air Force (DF)
- FT
- Subscribe
- 1
- FT
- Oct 2019
- Department of the Air Force (DF)
- FT
- Subscribe
- 1
- FT
Similar Supply Items to 9540-00-487-5676
Freight Information 9540-00-487-5676
9540-00-487-5676 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 104420. A Sub NMFC of X. It has a NMFC Description of BEAMS NOI I/S. 9540-00-487-5676 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 53800 which rates the freight between FCL and LCL. 9540-00-487-5676 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 9540-00-487-5676 is not classified as a special type of cargo when transported by water. 9540-00-487-5676 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 9540-00-487-5676
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 9540-00-487-5676 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- H
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
