9505-00-592-4690
Nonelectrical Wire
9505005924690 005924690 QQ-W-461 946423-1300 9509005924690 MS20995F32
A ferrous or nonferrous wire having a solid cross section that is square or rectangular with sharp or rounded corners or edges, or is round, half-round, hexagonal, or octagonal and whose diameter, width, or greatest distance between parallel faces is less than 3/8 inch or 10.0mm. The rectangular shape is limited to a thickness less than 3/32 inch or 2.5mm and a width of 1 1/4 inch or 30.0mm or less. For dimensions greater than above, see BAR, METAL. Excludes items having electrical resistivity or conductivity ratings. View more Nonelectrical Wire
May 2023
43
Marketplace 9505-00-592-4690
Request a Quotation from participating marketplace vendors
Related Documents 9505-00-592-4690 5+ Documents (More...)
https CL3 QQ-W-461 A-A- QQ-W-461 https//www.nsnlookup.com CL3 QQ-W-461 A-A- QQ-W-461 Nonelectrical
Nonelectrical Wire 9505005924690005924690, A-A- QQ-W-461 https CL3 QQ-W-461 A-A- QQ-W-461 https
-1300 MS20995F32 Wire Rope 5340200026695200026695 how to enable JavaScript in your web browser . 5340
Nonelectrical Wire 9505005924690 005924690, Account Upgrade 9505-00-592-4690Nonelectrical Wire9505005924690
QQ-W-461 946423-1300 MS20995F32 Wire Rope 5340200026695200026695 how to enable JavaScript https//www.nsnlookup.com
/fsg-95/fsc-9505/us 9505-00-592-4690 Nonelectrical Wire 9505005924690 005924690, Nonelectrical Wire
Account Upgrade 9505-00-592-4690Nonelectrical Wire9505005924690 005924690 QQ-W-461 946423 946423-1300
Nonelectrical Wire 9505005924690 005924690, https CL3 QQ-W-461 A-A- QQ-W-461 https//www.nsnlookup.com
461 CL3 QQ-W-461 A-A-1007 CL3 CL3 QQ-W-461 A-A-1007 CL3 QQ-W-461 A-A-1007 CL3 https//www.nsnlookup.com
/fsg-95/fsc-9505/us 9505-00-592-4690 Nonelectrical Wire 9505005924690 005924690, https CL3 QQ-W-461
Restrictions 9505-00-592-4690
9505-00-592-4690 is a Nonelectrical Wire that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 9505-00-592-4690
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 1995
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 9505-00-592-4690
- Part Number
- Manufacturer
- Status
- QQ-W-461
- Manufacturer
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
- 9509005924690
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 9505005924690
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- MS20995F32
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 946423-1300
- 06481 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 9505-00-592-4690
- Characteristic
- Specifications
- FIIG
- Specifications
- A13100
- Basic Shape Style [AGTA]
- Round
- Coating Weight [BWDC]
- 0.070 Ounces Per Square Foot
- Cross Section Outside Diameter [ADVL]
- 0.032 Inches Nominal
- Heat Treatment [HEAT]
- Soft Temper
- Material Document And Classification [MDCL]
- Qq-W-461, Comp 1006 Fed Spec Single Material Response
- Material [MATT]
- Steel Comp 1006
- Minimum Tensile Strength [CQBC]
- 90000 Pounds Per Square Inch
- Nondefinitive Spec/Std Data [ZZZT]
- 1006 Composition And 5 Finish And 1 Class
- Length [ABRY]
- 366.100 Feet Nominal
- Weight Per Unit Measure [BRFD]
- 1.000 Pounds Per Piece
- Surface Treatment [SFTT]
- Zinc
Similar Supply Items to 9505-00-592-4690
Freight Information 9505-00-592-4690
9505-00-592-4690 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 107480. A Sub NMFC of X. It has a NMFC Description of WIRE/BARBED WIRE I/S ACID COPPERED. 9505-00-592-4690 is rated as class 50 when transported by Less-Than Truckload (LTL) freight. 9505-00-592-4690 is rated as class 50 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 55270 which rates the freight between FCL and LCL. 9505-00-592-4690 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 664 for ocean manifesting and military sealift. 9505-00-592-4690 is not classified as a special type of cargo when transported by water. 9505-00-592-4690 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
