8315-01-508-8034
Buckle
8315015088034 015088034 6411
A fastening device used to join two ends of a belt, strap or the like. It may be a single unit designed to be attached to one end of a belt or strap and secure the opposite end by penetration, by clamping, or by friction, or it may consist of male and female sections having one section attached at each end of the belt or strap and joins the two ends by a hook-like or other interlocking action. View more Buckle
January 2023
1
Marketplace 8315-01-508-8034
Request a Quotation from participating marketplace vendors
Related Documents 8315-01-508-8034 2+ Documents (More...)
BUCKLE RQST NS Request Quotation 6411 BUCKLE RQST NS Request Quotation Updated Every Day 8315-01-508
Documents 8315-01-508-8034 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-83/fsc-8315/us 8315
Restrictions 8315-01-508-8034
8315-01-508-8034 is a Buckle that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 8315-01-508-8034
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 8315-01-508-8034
- Canada (ZC01)
- Effective Date:
- 1 Jun 2003
Approved Sources 8315-01-508-8034
- Part Number
- Manufacturer
- Status
- 6411
- Manufacturer
- 07MZ0 - National Molding Corp. (Active)
- Primary Buy
- Primary Buy
Datasheet 8315-01-508-8034
- Characteristic
- Specifications
- FIIG
- Specifications
- T372-G
- Material And Location [ANNQ]
- Plastic Overall
- Enameled Feature [CBTB]
- Not Included
- Buckle Style Designator [CXKH]
- Hook
- Overall Length [ABHP]
- 1.760 Inches Nominal
- Overall Width [ABMK]
- 1.360 Inches Nominal
- Strap Accommodation Width [BXQL]
- 1.020 Inches Nominal
- Specific Usage Design [ALXZ]
- Repair On A Field Broken Female Buckle
- Insignia [BYMJ]
- Not Included
- Special Features [FEAT]
- Used With Pat Numbers 7005 Or 6358
- Part Name Assigned By Controlling Agency [CXCY]
- Female Buckle Stealth Quik Attachment
Similar Supply Items to 8315-01-508-8034
Freight Information 8315-01-508-8034
8315-01-508-8034 has freight characteristics managed by the Department of the Air Force.It has a National Motor Freight Classification (NMFC) of 094570. A Sub NMFC of Z. It has a NMFC Description of FASTENERS/HOOKS/LACINGS BELT. 8315-01-508-8034 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 48840 which rates the freight between FCL and LCL. 8315-01-508-8034 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 8315-01-508-8034 is not classified as a special type of cargo when transported by water. 8315-01-508-8034 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
