8145-01-231-3747
Engine Shipping And Storage Container
8145012313747 012313747 12338064 8145PL0823831
A multisectional shipping and storage container with provisions included for assembly. View more Engine Shipping And Storage Container
June 2023
10
Marketplace 8145-01-231-3747
Request a Quotation from participating marketplace vendors
Related Documents 8145-01-231-3747 1+ Documents (More...)
United States (US) 4. 8145-01-231-3747 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 8145-01-231-3747 RQST Updated Every Day 8145-01-231-3747 RQST NE Related Documents
Restrictions 8145-01-231-3747
8145-01-231-3747 is a Engine Shipping And Storage Container Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 8145-01-231-3747
- US Army (A202)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- BD
- US Air Force (FGTC)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MA5T)
- Effective Date:
- 1 Apr 1991
- Lithuania (WI01)
- Effective Date:
- 1 Jul 2000
- Poland (WP01)
- Effective Date:
- 1 Jun 2011
- Canada (ZC01)
- Effective Date:
- 1 Jul 2013
- Greece (ZU01)
- Effective Date:
- 1 May 2006
Approved Sources 8145-01-231-3747
- Part Number
- Manufacturer
- Status
- 12338064
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 8145PL0823831
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 8145-01-231-3747
- Characteristic
- Specifications
- FIIG
- Specifications
- T358-E
- Shape [SHPE]
- Rectangular
- Mounting Surface Plane [AFJR]
- Parallel
- Overall Length [ABHP]
- 53.380 Feet Nominal
- Overall Width [ABMK]
- 42.500 Feet Nominal
- Overall Height [ABKW]
- 41.250 Feet Nominal
- Window [ATDN]
- Not Included
- Accommodated Equipment Identifying Number [BJMZ]
- 12338770 Part No.
- End Item Identification [AGAV]
- Pccn Chmmwv 1 1/4 Ton
Management Data 8145-01-231-3747
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Oct 2021
- US Marine Corps (DM)
- EA
- Subscribe
- EA
- Nov 2020
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Oct 2020
- US Marine Corps (DM)
- EA
- Subscribe
- EA
- Nov 2019
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- L
- R
- Refer To Net Price 1964.00
- NET PRICE 1964.00
- R
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- N5
- Tactical Vehicles
High Mobility Multi-Purpose Wheeled Vehicle(HMMWV)
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 51
- Operational Test:
- No Special Procedures
Similar Supply Items to 8145-01-231-3747
Freight Information 8145-01-231-3747
8145-01-231-3747 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 041050. A Sub NMFC of B. It has a NMFC Description of CONTAINERS R VANS SHIPPING SUB2. 8145-01-231-3747 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. 8145-01-231-3747 is rated as class 150 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 30570 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 691 for ocean manifesting and military sealift. 8145-01-231-3747 is not classified as a special type of cargo when transported by water. 8145-01-231-3747 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 8145-01-231-3747
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Freeze – Below 32 F (Below 0 C)
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 53.4" H x 42.5" W x 41.3" L
- --
- Plated/Coated Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 53.4" H x 42.5" W x 41.3" L
- --
- --
- --
- Special Requirements
- 53.4" H x 42.5" W x 41.3" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
