8115-01-015-1313
Shipping Box
8115010151313 010151313 PPP-B-1672 TP0 0004GR4
A general-purpose box which may be reusable and designed specifically for the shipment of goods. It may have facilities for handling by hoist, forklift truck, or by skidding. It may also have provisions for humidity control. For containers designed for specific items, see SHIPPING AND STORAGE CONTAINER (as modified). Excludes BOX (1), INTERMEDIATE PACKAGING; and CRATE, SHIPPING. View more Shipping Box
May 2023
26
Marketplace 8115-01-015-1313
Request a Quotation from participating marketplace vendors
Related Documents 8115-01-015-1313 5+ Documents (More...)
Photo 1/2 NSN 8115-01-015-1313 (Identification) 2/2 - - 1.
PPP-B-1672 BOX,SHIPPING 4 EA NS Request Quotation Subscribe to View Vendor Details... 8115-01-015-1313
PPP-B-1672 TY1 37 A general-purpose box which may be reusable and designed specifically for the
PPP-B-1672 BOX,SHIPPING 4 EA NS Request Quotation Subscribe to View Vendor Details... 37 BOX,SHIPPING
Shipping Box 8115010151313 010151313 PPP-B-1672 BOX,SHIPPING 4 EA NS Request Quotation Subscribe
to View Vendor Details... 8115-01-015-1313 PPP-B-1672 BOX,SHIPPING 4 EA NS Request Quotation Subscribe
TY1STASZ8X8X12 8115-00-192-1604 A general-purpose box which may be reusable PPP-B-1672 BOX,SHIPPING
Shipping Box 8115010151313 010151313 Box Managed by United States NSN Created on 15 Jan 1976 Data
PPP-B-1672 BOX,SHIPPING 4 EA NS Request Quotation Subscribe to View Vendor Details... 8115-00-192-1604
https//www.nsnlookup.com /fsg-81/fsc-8115/us 8115-01-015-1313 Shipping Box 8115010151313 010151313 PPP-B
Restrictions 8115-01-015-1313
8115-01-015-1313 is a Shipping Box that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 8115-01-015-1313
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 8115-01-015-1313
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- NASA (G861)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GG
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Spain (YB01)
- Effective Date:
- 1 Jan 2003
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Dec 2003
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Jul 2007
Approved Sources 8115-01-015-1313
- Part Number
- Manufacturer
- Status
- TP0 0004GR4
- Manufacturer
- 98752 - Warner Robins Air Logistics Center (Active)
- Primary Buy
- Primary Buy
- PPP-B-1672
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 8115-01-015-1313
- Characteristic
- Specifications
- FIIG
- Specifications
- A06600
- Assembly Form [AFPM]
- Set-Up
- Assembly Method [AFPN]
- Any Acceptable
- Box Manufacturer Certificate [AFQG]
- Required
- Closure Fastening Type [AFPQ]
- Any Acceptable
- Closure Method [AFPP]
- Detachable Cover
- Container Load Hazard Designation [AFPZ]
- Not Rated
- Cover Depth [AFMR]
- 9.000 Inches Nominal
- Departure From Cited Designator [ZZZX]
- As Modified By Special Features
- Environmental Attribute Code [ENAC]
- Comprehensive Procurement Guideline - Paper And Paper Products - Paperboard And Packaging Products
- Humidity Control Design Feature [AFPX]
- No
- Material [MATT]
- Fiberboard, Ppp-F-320, Type Cf, Class Weather Resistant, Variety Sw, Grade V3c
- Nondefinitive Spec/Std Data [ZZZT]
- 3 Type And G Style
- Inside Depth [AFEF]
- 9.000 Inches Nominal
- Inside Width [ADJT]
- 9.000 Inches Nominal
- Inside Length [ADJU]
- 26.000 Inches Nominal
- Material Bursting Strength [AFPH]
- 400.0 Pounds Per Square Inch
- Special Features [FEAT]
- Cushion Assembly In Accordance With View Box Of Figure 3. Convolated Type Cushioning. Dimensions Of Cushions,Top 18-1/2 In. X 3-1/2 In. X 2-3/4 In,Bottom 18-1/2 In. X 9 In. X 2-3/4 In,Sides 18-1/2 In. X 6-1/4 In. X 2-3/4 In,Ends 9 In. X 3-3/4 In.
- Usage Design [ACVE]
- Weather Resistant
- Stacking Feature [AFQA]
- No
- Style Designator [STYL]
- Full Telescope, Ftd
DLA Procurement Analysis 8115-01-015-1313
Management Data 8115-01-015-1313
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9Q
Similar Supply Items to 8115-01-015-1313
Freight Information 8115-01-015-1313
8115-01-015-1313 has freight characteristics managed by the General Services Administration (GSA).It has a National Motor Freight Classification (NMFC) of 029205. A Sub NMFC of Z. It has a NMFC Description of BOXES FIBREBOARD/PAPER ETC. 8115-01-015-1313 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 14240 which rates the freight between FCL and LCL. 8115-01-015-1313 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 763 for ocean manifesting and military sealift. 8115-01-015-1313 is not classified as a special type of cargo when transported by water. 8115-01-015-1313 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
