6685-00-431-7438
Dial Indicating Pressure Gage
6685004317438 004317438 1379S
An instrument designed to measure air, gas, fluid, and vapor pressure by means of an internal pressure sensitive element (bellows, bourdon tube, transducer/transmitter and the like) which transmits energy, by direct linkage, to the indicating pointer of a scale or a digital display, calibrated in units of pressure.It may include a temperature equivalent scale.For items that do not have an internal pressure sensitive element see INDICATOR, PRESSURE. View more Dial Indicating Pressure Gage
November 2023
7
Marketplace 6685-00-431-7438
Request a Quotation from participating marketplace vendors
Related Documents 6685-00-431-7438 5+ Documents (More...)
Dial Indicating Pressure Gage 6685004317438 Photo 1/3 6685-00-431-7438 Photo 2/3 6685-00-431-7438 Photo
Dial Indicating Pressure Gage 6685004317438 Photo 1/3 6685-00-431-7438 Photo 2/3 6685-00-431-7438 Photo
/www.nsnlookup.com /fsg-47/fsc-4730/us 4730-01-559-7349 Lubrication Fitting 4730015597349015597349 1379S
Pressure Gage6685004317438 004317438 1379S Upgrade your Account Upgrade 6685-00-368-8019Dial Indicating
Pressure Gage6685004317438 004317438 1379S Upgrade your Account Upgrade 6685-00-368-8018Dial Indicating
/www.nsnlookup.com /fsg-47/fsc-4730/us 4730-01-559-7349 Lubrication Fitting 4730015597349015597349 1379S
/www.nsnlookup.com /fsg-47/fsc-4730/us 4730-01-559-7349 Lubrication Fitting 4730015597349015597349 1379S
Pressure Gage6685004317438 004317438 1379S Upgrade your Account Upgrade 6685-00-368-8018Dial Indicating
Pressure Gage6685004317438 004317438 1379S Pressure Gage6685003688019 0036880191379S Upgrade your Account
Upgrade 6685-00-368-8018Dial Indicating Pressure Gage6685003688018 003688018 1379S Upgrade your Account
Restrictions 6685-00-431-7438
6685-00-431-7438 is a Dial Indicating Pressure Gage that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
End Users 6685-00-431-7438
- NASA (G900)
- Effective Date:
- 1 Apr 1991
Approved Sources 6685-00-431-7438
- Part Number
- Manufacturer
- Status
- 1379S
- Manufacturer
- 38056 - Ashcroft Inc (Active)
- Incomplete Reference
- Incomplete Reference
Datasheet 6685-00-431-7438
- Characteristic
- Specifications
- Actuating Element Material [BGKY]
- Specifications
- Steel, Stainless
- Actuation Type [APCM]
- Single Bourdon Tube
- Adjustability [APCS]
- Adjustable
- Bezel Type [BHMD]
- Thread
- Bolt Circle Diameter [ABKG]
- 5.875 Inches Nominal
- Case Material [ADTV]
- Aluminum Alloy
- Case Surface Treatment [ADTY]
- Enamel, Black
- Connection Size [BHMG]
- 1/4 In. Npt
- Connection Location [BGRY]
- Back
- Connection Quantity [ASMM]
- 1
- Connector Type Vent [BHMK]
- Not Provided
- Connection Type [AWLS]
- External
- Dial Size [ARCH]
- 4-1/2 In. Dia
- Graduation Unit [ANBJ]
- 5.0 Pounds Per Square Inch
- Material [MATT]
- Aluminum Alloy
- Mounting Hole Diameter [ABTB]
- 0.219 Inches Nominal
- Mounting Hole Quantity [ABTJ]
- 3
- Mounting Method [AXGY]
- Surface Wall
- Pointer Color [ASSS]
- Black
- Pointer Type [ASST]
- Indicating
- Protective Crystal Material [BHMF]
- Glass
- Scale Accuracy [BGKS]
- 1/2 Of 1 Pct Of Full Range
- Scale Inscription/Background Color [BGKZ]
- Black Figures On White Background
- Scale Range [APSK]
- +0.000 To 60.000 Pounds Per Square Inch
- Scale Name [AQFZ]
- Pressure
- Scale Smallest Increment [AWAG]
- 1.0 Pounds Per Square Inch
- Scale Type [ATEQ]
- Concentric Arc Dial
- Overall Depth [ABFY]
- 2.250 Inches Nominal
- Overall Diameter [ADAV]
- 5.812 Inches Nominal
- Surface Treatment [SFTT]
- Enamel
Similar Supply Items to 6685-00-431-7438
Freight Information 6685-00-431-7438
6685-00-431-7438 has freight characteristics.. 6685-00-431-7438 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
