6685-00-286-1129
Self-Indicating Thermometer
6685002861129 002861129 GG-T-321
An item that has confined liquid whose physical property(ies) changes with variation in temperature and indicates the temperature to a division or number on a graduated scale(s). May include flexible tubing (capillary) for indoor/outdoor applications. Excludes: THERMOMETER, CLINICAL, HUMAN. View more Self-Indicating Thermometer
May 2023
5
Marketplace 6685-00-286-1129
Request a Quotation from participating marketplace vendors
Related Documents 6685-00-286-1129 5+ Documents (More...)
GG-T-321 THERMOMETER,SELF-INDICATING 1 EA NS Request Quotation Updated Every Day 6685-00-286-1129 RQST
Self-Indicating Thermometer 6685002861129 Photo 1/3 6685-00-286-1129 Photo 2/3 NSN 6685-00-286-1129
GG-T-321 THERMOWELL 1 EA NS Request Quotation Updated Every Day 6685-00-245-4527 RQST NE Updated
Thermometer6685002861129 002861129 GG-T-321 Self-Indicating Thermometer 6685002916863GG-T-321 THERMOMETER
Restrictions 6685-00-286-1129
6685-00-286-1129 is a Self-Indicating Thermometer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.
Import and Export 6685-00-286-1129
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6685-00-286-1129
- US Navy (N9BG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 6685-00-286-1129
- Part Number
- Manufacturer
- Status
- GG-T-321
- Manufacturer
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 6685-00-286-1129
- Characteristic
- Specifications
- FIIG
- Specifications
- A27600
- Actuating Medium [BKCM]
- Mercury
- Bulb Tip Outside Diameter [BKBD]
- 0.625 Inches Nominal
- Design Type [APGF]
- Fluctuating
- External Thread Size [AWMG]
- 3/4 In. Npt
- Features Provided [CBBL]
- Lens Magnifying Front And Expansion Chamber
- Material [MATT]
- Brass Meter Case
- Neck Length [AGQB]
- 2.500 Inches Nominal
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 3 Class And C Range And 3 Style And B Form
- Internal Thread Size [AWMH]
- 1-1/4 In. -18 Nep-2
- Scale Inscription/Background Color [BGKZ]
- Black Marking On Silver Background
- Scale Adjustment Variation [BKCQ]
- 2 Degree
- Scale Smallest Increment [AWAG]
- 2.0 Deg Fahrenheit
- Scale Type [ATEQ]
- Metal Nonmagnetic
- Separable Socket Style [CSYR]
- Lagging Extension
- Socket Overall Length [AGPM]
- 6.813 Inches Nominal
- Tip Length [AEDN]
- 2.625 Inches Nominal
DLA Procurement Analysis 6685-00-286-1129
Management Data 6685-00-286-1129
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material Content:
- 4
- Item or part that contains hazardous material(s) and could require special handling during maintenance or disposal
Similar Supply Items to 6685-00-286-1129
Freight Information 6685-00-286-1129
6685-00-286-1129 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 058360. A Sub NMFC of Z. It has a NMFC Description of THERMOMETERS,O/THAN CLINICAL. 6685-00-286-1129 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 33220 which rates the freight between FCL and LCL. 6685-00-286-1129 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 652 for ocean manifesting and military sealift. 6685-00-286-1129 is classified as a Corrosive Material, UN Class 8, when transported by water. 6685-00-286-1129 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6685-00-286-1129
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- Special requirement – See specific instructions or drawings provided
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 6685-00-286-1129 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
