6685-00-079-6427
Dial Indicating Pressure Gage
6685000796427 000796427 G-2228 G2228 123SCH114-1
An instrument designed to measure air, gas, fluid, and vapor pressure by means of an internal pressure sensitive element (bellows, bourdon tube, transducer/transmitter and the like) which transmits energy, by direct linkage, to the indicating pointer of a scale or a digital display, calibrated in units of pressure.It may include a temperature equivalent scale.For items that do not have an internal pressure sensitive element see INDICATOR, PRESSURE. View more Dial Indicating Pressure Gage
November 2023
13
Marketplace 6685-00-079-6427
Request a Quotation from participating marketplace vendors
Related Documents 6685-00-079-6427 5+ Documents (More...)
G-2228 GAGE,PRESSURE,DIAL INDICATING 1 EA NS Request Quotation Updated Every Day 6685-00-079-6427 RQST
NE Updated Every Day 6685-00-079-6427 RQST Updated Every Day 6685-00-079-6427 RQST NE Related Documents
Restrictions 6685-00-079-6427
6685-00-079-6427 is a Dial Indicating Pressure Gage that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 6685-00-079-6427
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6685-00-079-6427
- US Coast Guard (C911)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- C006
- Supplementary Receivers:
- XH
- US Navy (N9BG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- GTKE
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 2000
Approved Sources 6685-00-079-6427
- Part Number
- Manufacturer
- Status
- G-2228
- Manufacturer
- 04192 - Rogerson Aircraft Equipment Group (Active)
- Primary Buy
- Primary Buy
- G2228
- 34830 - Rogerson Kratos (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 123SCH114-1
- 26512 - Northrop Grumman Systems Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 123SCH114-1
- 79RG9 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 6685-00-079-6427
- Characteristic
- Specifications
- FIIG
- Specifications
- T179-B
- Actuating Element Material [BGKY]
- Beryllium Copper
- Actuation Type [APCM]
- Single Bourdon Tube
- Adjustability [APCS]
- Nonadjustable
- Case Material [ADTV]
- Aluminum
- Case Surface Treatment [ADTY]
- Anodized Black
- Connection Location [BGRY]
- Back
- Connection Quantity [ASMM]
- 1
- Connection Size [BHMG]
- 0.438 In. Npt Dia
- Connection Type [AWLS]
- External
- Connector Type Vent [BHMK]
- Not Provided
- Dial Size [ARCH]
- 1 Inch Diameter
- Graduation Unit [ANBJ]
- 1000.0 Pounds
- End Item Identification [AGAV]
- Aircraft,Hawkeye E-2C; Aircraft,Greyhound C-2
- Mounting Method [AXGY]
- Rigid Stem
- Pointer Color [ASSS]
- Black
- Pointer Type [ASST]
- Indicating
- Protective Crystal Material [BHMF]
- Plastic
- Scale Inscription/Background Color [BGKZ]
- Black Figures On White Background
- Scale Accuracy [BGKS]
- Porm 50 Psi,0 To 3200 Psi Range
- Scale Marking [ASTW]
- Psi X 1000
- Scale Name [AQFZ]
- Pressure
- Scale Range [APSK]
- +0.0 To 5000.0 Pounds Pressure Per Square Inch
- Scale Smallest Increment [AWAG]
- 500.0 Pounds
- Scale Type [ATEQ]
- Single
- Overall Depth [ABFY]
- 2.296 Inches Nominal
- Overall Diameter [ADAV]
- 1.250 Inches Nominal
Weapon Systems (WSDC) 6685-00-079-6427
DLA Procurement Analysis 6685-00-079-6427
- Last Stock Position:
- 15 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 6685-00-079-6427
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 6685-00-079-6427
Freight Information 6685-00-079-6427
6685-00-079-6427 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 121570. A Sub NMFC of X. It has a NMFC Description of GAGES AIR LIQUID LEVEL PRESSURE. 6685-00-079-6427 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 61770 which rates the freight between FCL and LCL. 6685-00-079-6427 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 653 for ocean manifesting and military sealift. 6685-00-079-6427 is not classified as a special type of cargo when transported by water. 6685-00-079-6427 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6685-00-079-6427
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- Delicate instrument
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 6685-00-079-6427 17 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A624F0834
- 13 Oct 2023
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A624F0834
- 13 Oct 2023
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F9888
- 17 Mar 2023
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F9888
- 17 Mar 2023
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F7609
- 17 Feb 2023
- Subscribe
- 5
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F7609
- 17 Feb 2023
- Subscribe
- 5
- Subscribe
- Subscribe
- Subscribe
- SPE4A722F013J
- 22 Jun 2022
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A722F013J
- 22 Jun 2022
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A722F6818
- 20 Mar 2022
- Subscribe
- 15
- Subscribe
- Subscribe
- Subscribe
- SPE4A722F6818
- 20 Mar 2022
- Subscribe
- 15
- Subscribe
- Subscribe
- Subscribe
- SPE4A722F3256
- 30 Nov 2021
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A722F3256
- 30 Nov 2021
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A418V099U
- 25 Sep 2018
- Subscribe
- 25
- Subscribe
- Subscribe
- Subscribe
- SPE4A618V481SP00001
- 31 Aug 2018
- Subscribe
- 12
- Subscribe
- Subscribe
- Subscribe
- SPE4A618V5603
- 03 Jan 2018
- Subscribe
- 14
- Subscribe
- Subscribe
- Subscribe
- SPE4A617P0720
- 14 Oct 2016
- Subscribe
- 12
- Subscribe
- Subscribe
- Subscribe
- SPE4A415VJ854
- 01 Sep 2015
- Subscribe
- 12
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 6685-00-079-6427 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
