6680-01-383-7933
Indicator Test Set
6680013837933 013837933 H8224-837837
A test set specifically designed for use in making examinations of indicators. View more Indicator Test Set
May 2023
7
Marketplace 6680-01-383-7933
Request a Quotation from participating marketplace vendors
Related Documents 6680-01-383-7933 3+ Documents (More...)
RQST NE Updated Every Day 6680-01-383-7933 RQST Updated Every Day 6680-01-383-7933 RQST NE Related Documents
6680-01-383-7933 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-66/fsc-6680/us 6680-01-383-7933
Indicator Test Set 6680013837933 013837933 www.nsnlookup.com /fsg-66/fsc-6680/us 6680-01-383-7933
AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Air Force (DF)LFWhen Exhausted Use 6680-01-383-7933
Indicator Test Set 6680013837933 013837933 Force (DF)LFWhen Exhausted Use 6680-01-383-7933 https
Restrictions 6680-01-383-7933
IUID Required
6680-01-383-7933 is a Indicator Test Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6680-01-383-7933
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6680-01-383-7933
- US Army (A390)
- Effective Date:
- 1 Sep 2000
- Former MOE Rule:
- A319
- US Air Force (FGG4)
- Effective Date:
- 1 Sep 2000
Approved Sources 6680-01-383-7933
- Part Number
- Manufacturer
- Status
- H8224-837837
- Manufacturer
- 06433 - General Electrodynamics Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 6680-01-383-7933
- Characteristic
- Specifications
- FIIG
- Specifications
- T228-A
- Electrical Power Source Relationship [AKWC]
- Operating
- Accessory Component Quantity [AFHS]
- 8
- Ac Voltage Rating [ACYN]
- 115.0 Volts Nominal Or 230.0 Volts Nominal
- Depth [AEJZ]
- 18.000 Inches Nominal
- Frequency Rating [ACZB]
- 60.0 Hertz Nominal
- Functional Description [FTLD]
- Tachometer Calibrator Will Provide Pmels With An Improved Capability To Calibrate All Known Types Of Tachometers Used By The Usaf
- Height [HGTH]
- 19.000 Inches Nominal
- Operating Test Capability [AQXZ]
- Revolutions Per Minute In Ranges Of 0-100, 0-500, 0-1000, 0-5000, 0-10000, 0-20000, 0-30000, And 0-40000 Rpm
- Inclosure Feature [ANPZ]
- Multiple Item W/Carrying Case
- Length [ABRY]
- 17.000 Inches Nominal
- Major Components [AEAS]
- Front Panel Assy Which Consists Of 16 Button Keypad And 2 Line X 16 Character Display, High Speed Motor, Speed Feedback Sensor Sys, 1000 Watt Dc Power Supply
- Relationship To Similar Equipment [RTSE]
- Replaces Nsn 6680-00-757-3743 And Nsn 6680-00-436-7571
- Phase [FAAZ]
- Single
- Special Features [FEAT]
- Rotational Speed 55 To 40,000 Rpm Both Cw And Ccw; Linear Rate Variable; Accuracy +/- 0.005 Percent Of Reading +/- One Digit; Torque 40 In-Oz At 5000 Rpm; Installation And Unpacking Should Be Performed By Pmel
- Test Type For Which Designed [AQXY]
- Tachometer Tester For All Known Tachometers Used By The U.S.A.F.
Management Data 6680-01-383-7933
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Sep 2000
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- 7
- Substitute For 6680-00-436-7571
- AAA
- 7
- Department of the Air Force (DF)
- L
- Dod I&S Family Master Nsn - - -
- ABA
Army
- Materiel Category and Inventory Manager:
- L
- Missiles, Missile Materiel
- Appropriation and Budget Activity:
- N
- Communications and Electronics Equipment(Safeguard)
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- FQ
- Other Missile Related Materiel
Calibration
- Accounting Requirements:
- N
- Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.
Air Force
- Budget:
- M
- 57X3080 - Other Base Maintenance and Support Equipment
- Aggregation Code:
- RN
- GROUND SUPPORT EQUIPMENT (FSC RESIDUAL MMAC)
- Price Validation Code:
- E
- The current standard price is an estimated price.
Estimated Price challenges are allowed but follow procedures in para 60.b. (3) of section L of this manual.
This code will be changed to a P code upon notification of a contract price or this code will be changed to an updated code upon determination of a valid price.
- Expendability
Recoverability
Repairability: - S
- Reparable. Condemn at Depot. AF Equipment Management System (AFEMS).
Similar Supply Items to 6680-01-383-7933
Freight Information 6680-01-383-7933
6680-01-383-7933 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 121570. A Sub NMFC of X. It has a NMFC Description of GAGES AIR LIQUID LEVEL PRESSURE. 6680-01-383-7933 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. 6680-01-383-7933 is rated as class 100 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 61770 which rates the freight between FCL and LCL. 6680-01-383-7933 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 652 for ocean manifesting and military sealift. 6680-01-383-7933 is not classified as a special type of cargo when transported by water. 6680-01-383-7933 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
