6680-01-114-8796
Liquid Level Switch
6680011148796 011148796 3876015-2 A4773 A4473 A-4473 10173021
A switch which is actuated by a float or sensing device(s) to control liquid level and/or actuate visual or audible warning systems. It may include a relay controlled by the switch element. Excludes TRANSMITTER,LIQUID QUANTITY. View more Liquid Level Switch
November 2023
13
Product Information 6680-01-114-8796
Float Switch
Used on Boeing F/A-18E/F “Super Hornet” Strike Fighter
Eaton’s float switch provides remote indication of low oil levels in the F/A-18’s Auxiliary Power Unit (APU).
Marketplace 6680-01-114-8796
Request a Quotation from participating marketplace vendors
Related Documents 6680-01-114-8796 5+ Documents (More...)
A4773 SWITCH,LIQUID LEVEL 215 EA NS Request Quotation Updated Every Day 6680-01-114-8796 RQST NE Updated
Every Day 6680-01-114-8796 RQST Updated Every Day 6680-01-114-8796 RQST NE Related Documents 6680-01
Liquid Level Switch 6680011148796 011148796, 6680-01-114-8796 6680011148796 011148796 is a switch
JavaScript in your web browser . 5905-12-169-2636Film Fixed Resistor5905121692636 121692636 B54321-A4473
-193-2729Film Fixed Resistor5905121932729 121932729 MBC 0309-50-BX 47KOHM+/-1% REP 225 45/4 B54322-A4473
Liquid Level Switch 6680011148796 011148796, Related Documents 6680-01 https//www.nsnlookup.com
12/fsc-1280/us 1280-00-488-0409 1280004880409 004880409 0309-50-BX 47KOHM+/-1% REP 225 45/4 B54322-A4473
-193-2729 Film Fixed Resistor 5905121932729121932729 MBC 0309-50-BX 47KOHM+/-1% REP 225 45/4B54322-A4473
-193-2729Film Fixed Resistor5905121932729 121932729 MBC 0309-50-BX 47KOHM+/-1% REP 225 45/4 B54322-A4473
Restrictions 6680-01-114-8796
6680-01-114-8796 is a Liquid Level Switch that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 6680-01-114-8796
- US Air Force (FXGG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- FXCX
- US Navy (N9BG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- GTKE
- Finland (WF01)
- Effective Date:
- 1 Jul 2009
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 6680-01-114-8796
- Part Number
- Manufacturer
- Status
- 3876015-2
- Manufacturer
- 99193 - Honeywell International Inc. (Active)
- Source Control
- Source Control
- A4773
- 97484 - Eaton Aerospace Llc (Active)
- Primary Buy
- Primary Buy
- A4473
- 97484 - Eaton Aerospace Llc (Active)
- Primary Buy
- Primary Buy
- A-4473
- 97484 - Eaton Aerospace Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 10173021
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
Datasheet 6680-01-114-8796
- Characteristic
- Specifications
- FIIG
- Specifications
- T109-D
- Electrical Connection Type [AGBD]
- Connector Receptacle
- Contact Arrangement [BJKD]
- Dpst
- Float Effective Travel [BJKN]
- 0.180 Inches Nominal
- Float Quantity [AWAE]
- 1
- Mounting Dimensions [BJKP]
- 7/8-14 Unf-3A Thd Body
- Mounting Method [AXGY]
- Thread
- Mounting Position [BBJX]
- Vertical
- Liquid Type For Which Designed [BJKH]
- Lubricating Oil
- Overall Length [ABHP]
- 5.540 Inches Maximum
- Overall Width [ABMK]
- 1.090 Inches Minimum And 1.150 Inches Maximum
- Special Features [FEAT]
- Float Position:Down
- Tank Insertion Length [BJKQ]
- 4.000 Inches Maximum
Weapon Systems (WSDC) 6680-01-114-8796
DLA Procurement Analysis 6680-01-114-8796
- Last Stock Position:
- 7 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 6680-01-114-8796
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
- Special Material ID:
- GF
- Fighter Support Aircraft (F/A-18)
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
NATO Stock Numbers Related to 6680-01-114-8796
Freight Information 6680-01-114-8796
6680-01-114-8796 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 6680-01-114-8796 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 6680-01-114-8796 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 6680-01-114-8796 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 6680-01-114-8796 is not classified as a special type of cargo when transported by water. 6680-01-114-8796 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6680-01-114-8796
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 6680-01-114-8796 6 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7M422P3526
- 15 Jun 2022
- Subscribe
- 12
- Subscribe
- Subscribe
- Subscribe
- SPE7M322P2358
- 08 Apr 2022
- Subscribe
- 13
- Subscribe
- Subscribe
- Subscribe
- SPE4A517P5827P00001
- 14 Apr 2017
- Subscribe
- 5
- Subscribe
- Subscribe
- Subscribe
- SPE4A517P2818P00003
- 13 Jan 2017
- Subscribe
- 2
- Subscribe
- Subscribe
- Subscribe
- SPE4A516M8862
- 02 Sep 2016
- Subscribe
- 4
- Subscribe
- Subscribe
- Subscribe
- SPE4A516M2284P00001
- 13 Jan 2016
- Subscribe
- 8
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 6680-01-114-8796 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
