6680-00-507-9992
Flexible Shaft Assembly
6680005079992 005079992 MIL-DTL-10215 MIL-S-10215 M10215-1F116 11614155-2 MIL-DTL-10215K 7954735 8340481 MS51071-16 1582106 M102151F1 M10215-1F1156 446125-156
An item consisting of a casing with fittings and attachments on each end and a spirally wound wire core with formed end(s) and/or crimped on end fittings. It is designed to transmit rotary motion around bends from a motor or other power source to drive various types of equipment, such as tachometers, speedometers, remote controls, instruments, and the like, which are located at an angle and/or distance from the power source. See also CONTROL ASSEMBLY, PUSH-PULL. View more Flexible Shaft Assembly
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
July 2025
July 2025
NATO Update Count
41
41
NATO Data Quality
Marketplace 6680-00-507-9992
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 6680-00-507-9992 5+ Documents (More...)
MIL-DTL-10215 MIL-S-10215 M10215-1F116 11614155-2 MIL-DTL-10215K 7954735 8340481 MS51071-16 1582106
M102151F1 M10215-1F1156 446125-156 An item consisting of a casing with fittings and attachments on each
M10215-1F116 SHAFT ASSEMBLY,FLEXIBLE 74 EA NS Request Quotation Subscribe to View Vendor Details... 6680
M102151F1 M10215-1F1156 446125-156 An item consisting of a casing with fittings and attachments on each
M10215-1F116 SHAFT ASSEMBLY,FLEXIBLE 74 EA NS Request Quotation Subscribe to View Vendor Details... 6680
Upgrade 6680-00-880-1880Flexible Shaft Assembly6680008801880 008801880 Cancelled - Replaced by NSN 6680-00-507-9992
a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 11614155-2
6680-00-880-1880 2+ Documents ( More... ) https https//www.nsnlookup.com /fsg-66/fsc-6680/us 6680-00-507-9992
a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 11614155-2
6680-00-880-1880 2+ Documents ( More... ) https https//www.nsnlookup.com /fsg-66/fsc-6680/us 6680-00-507-9992
https//www.nsnlookup.com
/fsg-66/fsc-6680/us
/fsg-66/fsc-6680/us
6680-01-017-8567 Flexible Shaft Assembly 6680010178567,
M10215-1F917 MIL-DTL-10215K MS52116-17 MIL-S-10215 An item consisting of a casing with fittings
-11 MIL-S-10215 Flexible Shaft Assembly 6680010178567, M10215-1F917MIL-DTL-10215KMS52116-17MIL-S
M10215-1B103 MIL-PRF-10215 MIL-S-10215 MS51071-3 7983060 M10215-1F103 An item consisting MIL-S
-11 MIL-S-10215 Flexible Shaft Assembly 6680010178567, M10215-1F917MIL-DTL-10215KMS52116-17MIL-S
M10215-1B103 MIL-PRF-10215 MIL-S-10215 MS51071-3 7983060 M10215-1F103 An item consisting MIL-S
M10215-1F907 MIL-DTL-10215K MIL-S-10215 MS52116-7 An item consisting of a casing with fittings
MIL-S-10215 SHAFT ASSEMBLY,FLEXIBLE 7 EA NS Request Quotation Subscribe to View Vendor Details...
Flexible Shaft Assembly 6680005079992 MIL-S-10215 M10215-1F116 11614155-2 MIL-DTL-10215K 7954735
MIL-S-10215 SHAFT ASSEMBLY,FLEXIBLE 7 EA NS Request Quotation Subscribe to View Vendor Details...
Flexible Shaft Assembly 6680005079992 MIL-S-10215 M10215-1F116 11614155-2 MIL-DTL-10215K 7954735
M10215-1F114 446125-107 1-2 MS51071-14 3040007983213 M10215-1A114 0624A0394 MIL-S-10215 446125
-107 MIL-DTL-10215K 7983213 An item consisting of a casing with fittings and attachments on each end
MS52116-17 MIL-S-10215 An item consisting of a casing with fittings -11 MIL-S-10215 Flexible Shaft
-107 MIL-DTL-10215K 7983213 An item consisting of a casing with fittings and attachments on each end
MS52116-17 MIL-S-10215 An item consisting of a casing with fittings -11 MIL-S-10215 Flexible Shaft
Restrictions 6680-00-507-9992
6680-00-507-9992 is a Flexible Shaft Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6680-00-507-9992
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6680-00-507-9992
- US Army (A920)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- A183
- Supplementary Receivers:
- AZCTBD
- US Air Force (FXGG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- FXCX
- US Marine Corps (MC41)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- MC04
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GGGT
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Jul 2002
- Columbia (YC01)
- Effective Date:
- 1 Jul 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 6680-00-507-9992
- Part Number
- Manufacturer
- Status
- M10215-1F116
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-DTL-10215
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-S-10215
- 81349 - Military Specifications (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 6680005079992
- A00AM - E.C.A Etablissement Central Des (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-DTL-10215K
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7954735
- 19207 - U S Army Tank Automotive Command (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 8340481
- 19207 - U S Army Tank Automotive Command (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MS51071-16
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1582106
- 24617 - General Motors Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- M102151F1
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- M10215-1F1156
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 446125-156
- 57733 - Stewart-Warner Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1582106
- 70040 - General Motors Llc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 11614155-2
- 19207 - U S Army Tank Automotive Command (Active)
- Transferred
- Transferred
Datasheet 6680-00-507-9992
- Characteristic
- Specifications
- FIIG
- Specifications
- T246-E
- End Connection Type [AWZY]
- Threaded Internal Both Ends
- Casing Length Between Ferrules [CFRP]
- 156.000 Inches Nominal
- Casing Outside Diameter [CFRQ]
- 0.300 Inches Minimum And 0.500 Inches Maximum
- Casing Surface Treatment [CFRN]
- Galvanized
- Casing Protective Device Type [CFRR]
- Plastic Cover Or Rubber Cover
- Core Diameter [AKMH]
- 0.150 Inches Nominal
- Core Material [AJXJ]
- Steel
- Core Overall Length [CFRZ]
- 157.188 Inches Nominal
- Core Removability [CFSL]
- Removable
- Core Rotation Direction [CFSB]
- Clockwise
- Core Surface Treatment [AKMF]
- Zinc Coated
- Cross Section Size And Location [CFQW]
- 0.101 Inches Minimum Across Flats And 0.104 Inches Maximum Across Flats Second End
- Cross Section Size And Location [CFQW]
- 0.150 Inches Minimum Diameter And 0.153 Inches Maximum Diameter First End
- End Overall Diameter [CFRW]
- 0.875 Inches Nominal Second End
- End Overall Diameter [CFRW]
- 1.188 Inches Nominal First End
- End Type [APTD]
- Round Keyed First End
- End Type [APTD]
- Square Male Second End
- Casing Material [BJPS]
- Rubber And Steel
- Minimum Operating Radius [CGDN]
- 5.000 Inches
- Lubrication Fitting [CFRY]
- Not Provided Both Ends
- Screw Thread Series Designator [AJYP]
- Unf Second End
- Screw Thread Series Designator [AJYP]
- Uns First End
- Setscrew [BDRL]
- Not Included Both Ends
- Overall Length [ABHP]
- 157.188 Inches Nominal
- Special Features [FEAT]
- Counterclockwise Core Rotation Direction
- Width Across Flats [ASDB]
- 0.750 Inches Nominal Second End
- Width Across Flats [ASDB]
- 1.000 Inches Nominal First End
- Wrenching Facility Type [BPPL]
- Hexagon Both Ends
- Swivel End [CFRT]
- Not Provided Both Ends
- Thread Class [AAJD]
- 2B Both Ends
- Thread Depth [AECT]
- 0.375 Inches Nominal Second End
- Thread Depth [AECT]
- 0.327 Inches Nominal First End
- Thread Direction [AAJF]
- Right-Hand Both Ends
- Thread Location [APJC]
- Internal Both Ends
- Tip Length [AEDN]
- 1.018 Inches Minimum And 1.022 Inches Maximum First End
- Tip Length [AEDN]
- 0.950 Inches Minimum And 1.010 Inches Maximum Second End
Weapon Systems (WSDC) 6680-00-507-9992
DLA Procurement Analysis 6680-00-507-9992
- Last Stock Position:
- 12 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 6680-00-507-9992
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 6680-00-880-1880
- 0
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 6680-00-507-9992
Freight Information 6680-00-507-9992
6680-00-507-9992 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 129920. A Sub NMFC of X. It has a NMFC Description of SHAFTS/SHAFTING,FLEX NOI STL. 6680-00-507-9992 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 65750 which rates the freight between FCL and LCL. 6680-00-507-9992 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 652 for ocean manifesting and military sealift. 6680-00-507-9992 is not classified as a special type of cargo when transported by water. 6680-00-507-9992 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6680-00-507-9992
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- ASTM - D5118, Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 6680-00-507-9992 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
