6645-00-420-5072
Time Totalizing Meter
6645004205072 004205072 11640392 CV 18565
An instrument that automatically measured, and cumulatively registers the total operating or idle time of any circuit, machine or system, to which it is connected. See METER, FREQUENCY AND TIME TOTALIZING, ELECTRICAL. View more Time Totalizing Meter
November 2023
29
Product Information 6645-00-420-5072
Time Meter, 24V, used on the AVDS-1790-2D and AVDS-1790-2D for the M48 Tank and AVLB as well as the AVDS-1790-2C and AVDS-1790-2CA of the M60 Tank and the AVDS-1790-2DR of the M88 Recovery Vehicle engines. Also used in the M109 Howitzer and the M992 FAASV Ammunition Carrier. This time meter can be "re-wound" to zero with the appropriate tool.
Marketplace 6645-00-420-5072
Request a Quotation from participating marketplace vendors
Related Documents 6645-00-420-5072 5+ Documents (More...)
19207 11640392 METER,TIME TOTALIZI ............................. 1 END OF FIGURE 0080 00 0080 00
6645-00-420-5072 83 1 19207 11640861-1 5310-00-168-2906 5 22 19207 11641744 46 7 19207 11641745 46 6
6645-00-420-5072 79 1 19207 11641745 44 17 19207 11641746 44 10 19207 11641867 44 11 19207 11641868
19207 11640392 80 1 4730-00-933-3138 19207 8761555 80 2 5310-00-275-3683 96906 MS35335-40 80 3
6645-00-420-5072 83 1 19207 11640861-1 5310-00-168-2906 5 22 19207 https//www.nsnlookup.com /equipment-intelligence
00-150-7407 9 20 19207 11610232 5330-01-102-4685 44 6 16128 11612239 4710-01-296-0469 19 42 19207 11640392
Restrictions 6645-00-420-5072
6645-00-420-5072 is a Time Totalizing Meter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6645-00-420-5072
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6645-00-420-5072
- US Army (A921)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- A182
- Supplementary Receivers:
- AZBFBD
- US Air Force (FXGG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- FXCX
- US Marine Corps (MC41)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- MC04
- US Navy (N9BG)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- General Services Administration (TGM1)
- Effective Date:
- 2 Nov 1999
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Mar 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Sep 2000
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Jul 2015
Approved Sources 6645-00-420-5072
- Part Number
- Manufacturer
- Status
- 11640392
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- CV 18565
- K2709 - Perkins Engines Company Ltd (Active)
- Secondary Buy
- Secondary Buy
- 6645004205072
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 6645004205072
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 6645-00-420-5072
- Characteristic
- Specifications
- FIIG
- Specifications
- T134-R
- Indicator Type [AMKD]
- Drum Register
- Measurement Unit [ANSX]
- Hours
- Maximum Measurement [BHLN]
- 999.90
- Smallest Increment Indicated [AXEA]
- 0.10
- Marking Color [BHLP]
- White Numerals
- Background Color [BHLQ]
- Black
- Reset Feature [BHCH]
- Not Provided
- Movement Type [AQEC]
- Electrical
- Electrical Movement Type [BHLR]
- Electronically
- Current Type [ACDC]
- Dc
- Voltage Rating [AMSE]
- 24.0 Volts Nominal
- Terminal Quantity [AARA]
- 3
- Terminal Type [AARB]
- Connector, Receptacle
- Case Material [ADTV]
- Metal
- Hermetic Protection [AQCS]
- Provided
- Unit Type [APQB]
- Mounted
- Mounting Type [AAXX]
- Engine
- Mounting Flange Width [ADMH]
- 2.620 Inches Nominal
- Flange Height [AHGD]
- 4.500 Inches Nominal
- Body Length [ADAQ]
- 2.120 Inches Nominal
- Body Width [ADAT]
- 2.440 Inches Nominal
- Body Depth [ARBR]
- 2.220 Inches Nominal
- Mounting Configuration [ALGC]
- Mounting Dimensions
- Special Features [FEAT]
- High Impact And Vibration Resistant
Weapon Systems (WSDC) 6645-00-420-5072
DLA Procurement Analysis 6645-00-420-5072
- Last Stock Position:
- 55 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 6645-00-420-5072
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- JT
- Tanks
Recovery Vehicle, M51/M74/M88
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- T
- Maintenance Float Secondary Non-depot Reparables
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 6645-00-420-5072
Freight Information 6645-00-420-5072
6645-00-420-5072 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 136740. A Sub NMFC of A. It has a NMFC Description of METERS ELEC/PARTS SUB1. 6645-00-420-5072 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. 6645-00-420-5072 is rated as class 100 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 68820 which rates the freight between FCL and LCL. 6645-00-420-5072 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 657 for ocean manifesting and military sealift. 6645-00-420-5072 is not classified as a special type of cargo when transported by water. 6645-00-420-5072 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6645-00-420-5072
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- Delicate instrument
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 6645-00-420-5072 4 Records
Contracting Technical Data File (CTDF) 6645-00-420-5072 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
