6640-00-264-4996
Laboratory Filtering Funnel
6640002644996 002644996 36290HCIEZ
An item with an integral porous or perforated plate, or with slits on the inside of a double wall. View more Laboratory Filtering Funnel
May 2023
5
Marketplace 6640-00-264-4996
Request a Quotation from participating marketplace vendors
Related Documents 6640-00-264-4996 1+ Documents (More...)
Updated Every Day 6640-00-264-4996 RQST NE Related Documents 6640-00-264-4996 1+ Documents ( More...
) https//www.nsnlookup.com /fsg-66/fsc-6640/us 6640-00-264-4996 Laboratory Filtering Funnel 6640002644996
Restrictions 6640-00-264-4996
6640-00-264-4996 is a Laboratory Filtering Funnel that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
End Users 6640-00-264-4996
- US Army (A910)
- Effective Date:
- 1 Mar 2007
- Former MOE Rule:
- A923
Approved Sources 6640-00-264-4996
- Part Number
- Manufacturer
- Status
- 36290HCIEZ
- Manufacturer
- 14674 - Corning Glass Works (Active)
- Primary Buy
- Primary Buy
Datasheet 6640-00-264-4996
- Characteristic
- Specifications
- FIIG
- Specifications
- A24200
- Distance From Disk To Top [CQZY]
- 38.00 Millimeters Nominal
- Capacity Rating [BBLT]
- 3.000 Milliliters Nominal
- Disk Diameter [ARDP]
- 10.00 Millimeters Nominal
- Filtering Disk Type And Size [CSND]
- 5.0 Microns Fixed Porous
- Primary Container Type [CQCT]
- Carton
- Primary Container Unit Quantity [CQTF]
- 1
- Overall Outside Diameter [ADGA]
- 11.00 Millimeters Nominal
- Special Features [FEAT]
- Fire Polished Rim And Lip,Neck Accommodates A No. 00 Rubber Stopper
- Stem Length [ALZD]
- 90.00 Millimeters Nominal
- Style Designator [STYL]
- Tube Type
- Total Primary Container Quantity [CSCW]
- 1
DLA Procurement Analysis 6640-00-264-4996
Management Data 6640-00-264-4996
Army
- Materiel Category and Inventory Manager:
- C
- Medical/Dental Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
NATO Stock Numbers Related to 6640-00-264-4996
Freight Information 6640-00-264-4996
6640-00-264-4996 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 014500. A Sub NMFC of X. It has a NMFC Description of APPARATUS CHEMICAL LABORATORY. 6640-00-264-4996 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 06350 which rates the freight between FCL and LCL. 6640-00-264-4996 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 651 for ocean manifesting and military sealift. 6640-00-264-4996 is not classified as a special type of cargo when transported by water. 6640-00-264-4996 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 6640-00-264-4996 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
