6635-00-822-7296
Spring Resiliency Tester
6635008227296 008227296 DG500 W/MT500HS2B2 MST-500 EL6-500 BTC-FR2.5TN.D09 200135717 DG500 W/MT500HS1B2 PB5A500 6635PL0915776
An apparatus, device, or instrument which is specifically designed for testing spring resiliency by subjection to the desired strain and indicating this force in units of weight. Indication may be by means of a dial, graduated scale, a pressure gage, a weighing scale, or by the graduated scale of a torque indicator wrench. The force may be applied mechanically, hydraulically, or manually. May have a fixed or adjustable platform load receiver. Excludes SCALE (as modified). View more Spring Resiliency Tester
August 2023
38
Marketplace 6635-00-822-7296
Request a Quotation from participating marketplace vendors
Related Documents 6635-00-822-7296 3+ Documents (More...)
/fsg-66/fsc-6635/us
... ) https//www.nsnlookup.com /fsg-66/fsc-6635/us 6635-00-822-7296 Spring Resiliency Tester 6635008227296
RQST NE Updated Every Day 6635-00-822-7296 RQST Updated Every Day 6635-00-822-7296 RQST NE Related
https//www.nsnlookup.com /fsg-53/fsc-5330/ca 5330-21-896-7428 Nonmetallic Strip Seal 5330218967428 MST 500
Spring Resiliency Tester 6635008227296 Primary Buy RNCC 3 RNVC 2 DAC 5 SS6-1-7-EL6-500 https//www.nsnlookup.com
Restrictions Approved Sources Datasheet Management https//www.nsnlookup.com /fsg-66/fsc-6635/us 6635-00-822-7296
Spring Resiliency Tester 6635008227296 Documents 6635-00-822-7296 3+ Documents ( More https//www.nsnlookup.com
Restrictions 6635-00-822-7296
IUID Required
6635-00-822-7296 is a Spring Resiliency Tester that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6635-00-822-7296
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6635-00-822-7296
- US Air Force (FGG4)
- Effective Date:
- 1 Sep 2000
- Former MOE Rule:
- FEE4
- US Navy (NAGS)
- Effective Date:
- 1 Sep 2000
- Former MOE Rule:
- NAES
- Supplementary Receivers:
- GG
- Poland (WP01)
- Effective Date:
- 1 Jun 2011
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Sep 2016
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Jan 2014
Approved Sources 6635-00-822-7296
- Part Number
- Manufacturer
- Status
- DG500 W/MT500HS2B2
- Manufacturer
- 9S016 - Willrich Precision Instrument (Active)
- Primary Buy
- Primary Buy
- MST-500
- 11710 - Ametek Inc. (Active)
- Secondary Buy
- Secondary Buy
- EL6-500
- 36403 - Link Engineering Co (Active)
- Secondary Buy
- Secondary Buy
- BTC-FR2.5TN.D09
- 3X4R5 - Zwickroell, Lp (Active)
- Secondary Buy
- Secondary Buy
- DG500 W/MT500HS1B2
- 92456 - Amtek Inc (Active)
- Secondary Buy
- Secondary Buy
- DG500 W/MT500HS1B2
- 9S016 - Willrich Precision Instrument (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- PB5A500
- 36403 - Link Engineering Co (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6635PL0915776
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 200135717
- 98752 - Warner Robins Air Logistics Center (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 6635-00-822-7296
- Characteristic
- Specifications
- FIIG
- Specifications
- T398-H
- Entry Date [NTRD]
- 74-09-01
- Functional Classification [FCLS]
- Aa-8.8
- Functional Description [FTLD]
- Portable,Quick Action,High Readability; Used For Testing Tensile Or Compression Str Of Fabric,Paper,String,Plastic,& Rubber,Up To Breaking Pt Or For Pill Crushing Or Piercing Appl; Constr To Withstand Constant Use At Full Loads
- Measurement Unit [ANSX]
- Pound
- Operation Method [APHE]
- Manual
- Mounting Method [AXGY]
- Portable
- Load Receiver Type [ATHC]
- Platform
- Reference Data And Literature [RDAL]
- Na 17-15Bu-3 & 17-20Mf-05
- Scale Range [BBHK]
- 0 T0 500 Lb
- Scale Smallest Increment Graduation [BBHL]
- 1.00 Lb Smallest Increment
- Special Features [FEAT]
- Extension Spring Max Extension Lg 10 In.; Accessories- 12 In.Rule Graduated By 1/64 In.W/Pointer & Magnifier,Two Clevis W/0.375 In.Pins,0.250 In.Dia Core Rod,& Brkt
- Torque Indicating Wrench Usage Feature [BNKY]
- Not Included
- Unit Type [APQB]
- Weighing Scale
- Spring Maximum Outside Diameter Accommodated [BNLC]
- 4.875 Inches
- Spring Maximum Overall Free Length Accommodated [BNLD]
- 12.000 Inches
- Spring Travel Gage [BNLB]
- Not Included
- Spring Type For Which Designed [BNKX]
- Compression And Tension
Management Data 6635-00-822-7296
Navy
- Cognizance:
- 1R
- Aeronautical, photographic, and meteorological material (consumable or expense type material)
Naval Inventory Control Point, Philadelphia
- Special Material ID:
- GA
- Attack Aircraft (A7)
- Issue, Repair, Requisition Restriction Code:
- 00
- No Restriction
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 6635-00-822-7296
Freight Information 6635-00-822-7296
6635-00-822-7296 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 058280. A Sub NMFC of X. It has a NMFC Description of SCIENTIFIC INSTRUMENTS NOI. 6635-00-822-7296 is rated as class 200 when transported by Less-Than Truckload (LTL) freight. 6635-00-822-7296 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 33190 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 6635-00-822-7296 is not classified as a special type of cargo when transported by water. 6635-00-822-7296 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6635-00-822-7296
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Preserve with Normal Operating Lubricant
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- Cushion, Anchor, Block or Brace as Required
- --
- ASTM-D6251, Type III, Class 1, Wood Cleated Plywood Box, Domestic
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- No Requirement
