6630-01-044-0334

Color Comparator

6630010440334 010440334 6630-044-0334 U25337 WIU20486-2-2

An instrument used to determine hydrogen ion concentration, residual chlorine content, phosphate content and/or other characteristics of water by visually comparing a sample, to which a specified quantity of an appropriate indicator solution has been added, with a color standard. The color standards used for these tests are mounted in a suitable holder and graded to represent the indicator colors for various pH values, concentration of chlorine, phosphate, or other substance. View more Color Comparator

6630-01-044-0334 COMPARATOR,COLOR 6630010440334 010440334

Managed by United States
NSN Created on 6 Jul 1977
Data Last Changed
May 2023
NATO Update Count
25
NATO Data Quality
6630-01-044-0334 COMPARATOR,COLOR 6630010440334 010440334 1/1
6630-01-044-0334 Photo 1/1

6630-01-044-0334 Stock and Availability Marketplace 6630-01-044-0334

Need Help?
Request a Quotation from participating marketplace vendors
eBay Updated Every Day
6630-01-044-0334 RQST NE eBay
eBay Updated Every Day
6630-01-044-0334 RQST eBay
Amazon Updated Every Day
6630-01-044-0334 RQST NE Amazon

6630-01-044-0334 Related Documents Related Documents 6630-01-044-0334 5+ Documents (More...)

(CAGE Code 5RMR6) Jan 1962 6630-01-044-0334 Color Comparator 6630-044-0334RNCC: C | RNVC: 1 | DAC: 4
(CAGE Code 90767) Jan 1962 6630-01-044-0334 Color Comparator 6630-044-0334RNCC: 5 | RNVC: 9 | DAC: 4
011523511 386-1017 6630-00-952-0039 6630-00-589-0122 6630-01-582-8381 044-0334 Color Comparator 6630010440334
183-4712 Color Comparator 6630121834712 121834712 6630-01-582-8381 6630-12-183-4712 Comparator 6630010440334
Color Comparator 6630011523511 011523511 386-1017 6630-00-952-0039 6630-00-589-0122 -6630/us 6630-01-044-0334
4610-01-276-2738 4610012762738 012762738 TUBING https//www.nsnlookup.com /fsg-66/fsc-6630/us 6630-01-044-0334
Color Comparator 6630010440334 010440334 6630-01-044-0334 6630010440334 010440334 is an instrument
011523511 386-1017 6630-00-952-0039 6630-00-589-0122 6630-01-582-8381 044-0334 Color Comparator 6630010440334
010440334 386-1017 6630-00-952-0039 6630-00-589-0122 6630-01-582-8381 307-8510 Color Comparator 6630013078510
011523511 386-1017 6630-00-952-0039 6630-00-589-0122 6630-01-582-8381 6630-12-183-4712 Comparator 6630010440334
Navy (DN)NZDiscontinued-Use 6630-01-044-0334Defense Logistics Agency (DS)IZDiscontinued-Use 6630-01-044-0334

6630-01-044-0334 Demil Restrictions 6630-01-044-0334

DEMIL: A | DEMILI: 1 | CRITICALITY: X | HMIC: N | PMIC: A | EDC: | ADPEC: 0

6630-01-044-0334 is a Color Comparator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

6630-01-044-0334 HTS and ScheduleB Import and Export 6630-01-044-0334

6630-01-044-0334 End Users End Users 6630-01-044-0334

US Army (A911)
Effective Date:
1 Dec 2006
Former MOE Rule:
A111
US Air Force (FSGM)
Effective Date:
1 Dec 2006
Former MOE Rule:
FSKX
US Marine Corps (MC46)
Effective Date:
1 Dec 2006
Former MOE Rule:
MC09
US Navy (N9BL)
Effective Date:
1 Dec 2006
Former MOE Rule:
N9LM
Supplementary Collaborators:
GTHDJN
Canada (ZC01)
Effective Date:
1 Apr 1991
Republic of Korea (ZH01)
Effective Date:
1 Apr 1991
Turkey (ZW01)
Effective Date:
1 Nov 2009

6630-01-044-0334 Manufacturers Approved Sources 6630-01-044-0334

6630-01-044-0334 Technical Data Datasheet 6630-01-044-0334

Characteristic
Specifications
FIIG
T149-B
Accessory Components And Quantity [AKYD]
4-Rectangular Cells,Optically Clear,15 Ml Cap.,Inside Dim: 26Mm Deep X 13Mm Wide X 77Mm Long; 1-Empty,0.5 Oz. Cap. Ph Reagent Bottle; 1-Dpd Chlorine Color Disk; 1-Ph Color Disk; 1-Carrying Case
Carrying Case [AFJU]
Provided
Color Graduation [ATNT]
0.1 And 0.4 And 0.7 And 1.0 And 1.5 And 2.0 And 3.0 And 5.0 And 10.0 And 3.0 And 4.0 And 5.0 And 6.0 And 7.0 And 8.0 And 9.0 And 10.0 And 11.0
Color Range [ATNS]
+3.0/+11.0 Ph And +0.1/+10.0 Ppm Residual Chlorine
Holder Type For Which Designed [ATNR]
Disk
Housing Material [AJLF]
Plastic Or Glass
Indicator Solution Type [ATNX]
N,N-Diethyl-P-Phenylenediamine
Integral Light [AWPQ]
Not Provided
Light Type For Which Designed [ATNW]
Artificial Light And Daylight
Primary Container Type [CQCT]
Package
Primary Container Unit Quantity [CQTF]
1
Overall Length [ABHP]
3.750 Inches Nominal
Overall Thickness [ADUM]
1.500 Inches Nominal
Overall Width [ABMK]
3.750 Inches Nominal
Part Name Assigned By Controlling Agency [CXCY]
Comparator Color Hydrogen Ion & Residual Chlorine 3.75"L W/Case
Viewing System Type [ATNY]
Prism
Supplementary Features [SUPP]
Hydrogen Ion And Residual Chlorine; For Dpd Tablet Order 6810-01-044-0315 For Detection Of Free Chlorine In Drinking Water

6630-01-044-0334 Stock, Inventory and Procurement DLA Procurement Analysis 6630-01-044-0334

DLA Administrative Lead Time:
Subscribe
DLA Production Lead Time:
Subscribe
Subscribe to View DLA Inventory and Forecast...

6630-01-044-0334 Management Data Management Data 6630-01-044-0334

Effective Date
Organization
Unit of Issue
Unit Price
Qty Unit Pack
Dec 2015
Defense Logistics Agency (DS)
EA
Subscribe
1
MOE
USC
Code
Statement
Order of Use
Jump To Code
Qty Per Assy
UOM
Technical Document
Quantative Expression
Defense Logistics Agency (DS)
I
V
Discontinued W/O Replacement

6630-01-044-0334 Related Items NATO Stock Numbers Related to 6630-01-044-0334

6630-01-044-0334 Freight Data Freight Information 6630-01-044-0334

6630-01-044-0334 has freight characteristics managed by the Bonneville Power Administration.It has a National Motor Freight Classification (NMFC) of 058280. A Sub NMFC of X. It has a NMFC Description of SCIENTIFIC INSTRUMENTS NOI. 6630-01-044-0334 is rated as class 200 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 33190 which rates the freight between FCL and LCL. 6630-01-044-0334 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 652 for ocean manifesting and military sealift. 6630-01-044-0334 is not classified as a special type of cargo when transported by water. 6630-01-044-0334 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

6630-01-044-0334 Packaging Data Packaging Data 6630-01-044-0334

Responsible Activity
Packaging Data Source
Primary Inventory Control Activity (PICA)
--

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation
--
--
--
Over 10lb
Less than 85G
Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying
1
8.0" H x 5.0" W x 4.8" L
--
--
--
Special Requirements
Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking
Special Requirement
Special Requirements – see Specific Instructions or Drawings provided
Special Requirements. See Specific Instructions or Drawings Provided
Special Requirements. See Specific Instructions or Drawings Provided
Special requirement – See specific instructions or drawings provided
Special requirements

Intermediate Pack Level

Quantity of Unit Packs
Container
--

6630-01-044-0334 Contracting Technical Data File (CTDF) Contracting Technical Data File (CTDF) 6630-01-044-0334 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):
N

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
Y
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:
