6625-01-289-0854

Spectrum Analyzer

6625012890854 012890854 PD16WRGUEAB11 A-A-59130 PD88MMTRGACID161 PD10WRGBGBEC39 PD13WRGRUEEA07

An instrument specifically designed to measure the amplitude and frequency of the constituents of a complex electrical wave form. May include transducer mechanism for converting sound pressure into electrical energy. View more Spectrum Analyzer

Managed by United States

NSN Created on 17 Nov 1988

Data Last Changed
May 2023

NATO Update Count
28

NATO Data Quality

6625-01-289-0854 ANALYZER,SPECTRUM 6625012890854 012890854 1/1 — 6625-01-289-0854 Photo 1/1

Marketplace 6625-01-289-0854

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

N9070A-002 ANALYZER,SPECTRUM RQST NS

A-A-59130 ANALYZER,SPECTRUM RQST NS

Updated Every 15 Minutes

6625-01-289-0854 BUY NE

Updated Every Day

6625-01-289-0854 RQST NE

Updated Every Day

6625-01-289-0854 RQST

Updated Every Day

6625-01-289-0854 RQST NE

Restrictions 6625-01-289-0854

IUID Required

6625-01-289-0854 is a Spectrum Analyzer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 6625-01-289-0854

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 6625-01-289-0854

US Air Force (FGG4)
Effective Date:: 1 Sep 2000
Former MOE Rule:: FEE4; AMC 1 AMSC G AMSC F IMC D DSOR FR

US Navy (NAGS)
Effective Date:: 1 Oct 2002
Supplementary Receivers:: GG; AMC 1 AMSC G AMSC 3 IMC D DSOR FR

Spain (YB01)
Effective Date:: 1 Jun 2004

France (ZF01)
Effective Date:: 1 Apr 2000

Republic of Korea (ZH01)
Effective Date:: 1 Jun 2004

Italy (ZR01)
Effective Date:: 1 Jul 2010

Greece (ZU01)
Effective Date:: 1 Jun 2004

Turkey (ZW01)
Effective Date:: 1 Jun 2004

Approved Sources 6625-01-289-0854

Part Number
Manufacturer
Status
PD16WRGUEAB11: 98752 - Warner Robins Air Logistics Center (Active); Incomplete Reference; RNCC 3 RNVC 1 DAC E
A-A-59130: 58536 - Federal Commercial Item Description (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
PD88MMTRGACID161: 98752 - Warner Robins Air Logistics Center (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
PD10WRGBGBEC39: 98752 - Warner Robins Air Logistics Center (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
PD13WRGRUEEA07: 98752 - Warner Robins Air Logistics Center (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4

Datasheet 6625-01-289-0854

Characteristic
Specifications
FIIG: A532P0
Furnished Items And Quantity [AKYN]: Spare Fuses,Power Cable And Clamp 1; Manuals 6; 18 To 26.5 Ghz Mixer 1; 26.5 To 40 Ghz Mixer 1; Mixer Amplifier If Required 1
Frequency Range Rating [AFGQ]: +10.000/+40000000.000 Kilohertz
Functional Classification [FCLS]: Aa-3.3
Plug-In Unit Quantity [BHGJ]: 1
Overall Height [ABKW]: 11.000 Inches Nominal
Overall Length [ABHP]: 17.000 Inches Nominal
Overall Width [ABMK]: 17.000 Inches Nominal
Supplementary Features [SUPP]: Solid-State; Programmable; 10Hz Resolution Bandwidth; Type Bnc Female Female Connectors For Frequency To 4Ghz,N Type To 18 Ghz And Apc 3.5 Mm Type To 26.5 Ghz; Capable Of Continuous Operation For 24 Hours At 55 Deg C; Non-Operating Temp M40deg C To P75deg C; Frequency Range With Internal Mixers 10 Khz To 21 Ghz; Input Impedance 50 Ohms Nominal; Signal Input Range M115 Dbm To P30 Dbm; Sweep Time Accuracy Porm 10Pct; Digital Storage; Flat,Aluminized Crt Display With Usage Scan 10 Divisions Wide By 8 High And Utilizes Type P31 Phosphor; Ieee Standard 488 Interface Function And Connector; Mosular Design Contruction
