6625-01-083-9773
Spectrum Analyzer
6625010839773 010839773 IE-33 IE-30A
An instrument specifically designed to measure the amplitude and frequency of the constituents of a complex electrical wave form. May include transducer mechanism for converting sound pressure into electrical energy. View more Spectrum Analyzer
May 2023
11
Marketplace 6625-01-083-9773
Request a Quotation from participating marketplace vendors
Related Documents 6625-01-083-9773 1+ Documents (More...)
United States (US) 4. 6625-01-083-9773 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 6625-01-083-9773 RQST Updated Every Day 6625-01-083-9773 RQST NE Related Documents
Restrictions 6625-01-083-9773
6625-01-083-9773 is a Spectrum Analyzer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 6625-01-083-9773
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6625-01-083-9773
- US Air Force (FGG5)
- Effective Date:
- 1 Sep 2000
- Former MOE Rule:
- FEE5
- NASA (G510)
- Effective Date:
- 1 Apr 1991
Approved Sources 6625-01-083-9773
- Part Number
- Manufacturer
- Status
- IE-33
- Manufacturer
- 57604 - Ivie Technologies Inc (Active)
- Primary Buy
- Primary Buy
- IE-30A
- 57604 - Ivie Technologies Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6625-01-083-9773
- Characteristic
- Specifications
- FIIG
- Specifications
- A532P0
- Ac Voltage Rating [ACYN]
- 115.0 Volts Nominal And 230.0 Volts Nominal
- Furnished Items And Quantity [AKYN]
- Instruction Manual 1; Ac Adaptor/Charger 1; Microphone 1; Preamplifier,Microphone 1; Probe,Test 1; Carrying Case 1
- Frequency Range Rating [AFGQ]
- +0.025/+20.000 Kilohertz
- Frequency Rating [ACZB]
- 50.0 Hertz Minimum And 60.0 Hertz Maximum
- Meter Scale Range [BHZH]
- M3-149 Dbuv; 3-149 Dba
- Mounting Method [AXGY]
- Case Mounted Portable
- Overall Depth [ABFY]
- 54.0 Millimeters Nominal
- Overall Height [ABKW]
- 98.0 Millimeters Nominal
- Overall Width [ABMK]
- 203.0 Millimeters Nominal
Management Data 6625-01-083-9773
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2018
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Similar Supply Items to 6625-01-083-9773
Freight Information 6625-01-083-9773
6625-01-083-9773 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 6625-01-083-9773 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 6625-01-083-9773 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 738 for ocean manifesting and military sealift. 6625-01-083-9773 is not classified as a special type of cargo when transported by water. 6625-01-083-9773 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
