6625-00-643-2586
Ammeter
6625006432586 006432586 MR26W500DCUA
An instrument which measures electric current and is calibrated and marked in amperes or any multiple and/or submultiple thereof. The value may be expressed by means of a pointer and calibrated dial or a digital readout display. For current detecting type of devices, see GALVANOMETER. View more Ammeter
May 2023
16
Marketplace 6625-00-643-2586
Request a Quotation from participating marketplace vendors
Related Documents 6625-00-643-2586 3+ Documents (More...)
6625-00-643-2586 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-66/fsc-6625/us 6625-00-643-2586
Ammeter 6625006432586006432586 Photo 1/3 NSN 6625-00-643-2586 (Identification) 2/3 NSN 6625-00-643-2586
Restrictions 6625-00-643-2586
6625-00-643-2586 is a Ammeter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 6625-00-643-2586
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6625-00-643-2586
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 6625-00-643-2586
- Part Number
- Manufacturer
- Status
- MR26W500DCUA
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
Datasheet 6625-00-643-2586
- Characteristic
- Specifications
- FIIG
- Specifications
- A310A0
- Accuracy In Percent [APPN]
- -2.5/+2.5 At Full Scale Single Indicator Single Range
- Background Color [AQFY]
- White Single Indicator Single Range
- Circuit Attachment Method And Quantity [CTTD]
- 2 Threaded Stud
- Circuit Current For Which Designed [AACT]
- Dc
- Dial Scale Marking Color [APMM]
- Black Single Indicator Single Range
- Dielectric Withstanding Voltage In Volts [AAPB]
- 3000.0
- Measurement Range [BHMW]
- +0.0/+500.0 Microamperes, Dc Single Indicator Single Range
- Meter Depth Behind Mounting Flange [APST]
- 1.600 Inches Nominal
- Meter Body Diameter Behind Mounting Flange [APSW]
- 2.210 Inches Nominal
- Mounting Arrangement Style [ANRL]
- Three Hole/Stud Bolt Circle
- Mounting Bolt Circle Diameter [AFFL]
- 2.440 Inches Nominal
- Mounting Facility Type And Quantity [AXHR]
- 3 Flange
- Movement Type [AQEC]
- Moving Iron Vane
- Installation Design [AMQY]
- Panel
- Sensitivity Rating [ANTG]
- 150.0 Millivolts
- Overall Diameter [ADAV]
- 2.695 Inches Nominal
- Overall Length [ABHP]
- 2.000 Inches Nominal
- Style Designator [STYL]
- Round Flush Mtg
Similar Supply Items to 6625-00-643-2586
Freight Information 6625-00-643-2586
6625-00-643-2586 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 136740. A Sub NMFC of Z. It has a NMFC Description of METERS ELEC/PARTS. 6625-00-643-2586 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 68820 which rates the freight between FCL and LCL. 6625-00-643-2586 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 657 for ocean manifesting and military sealift. 6625-00-643-2586 is not classified as a special type of cargo when transported by water. 6625-00-643-2586 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
