6625-00-079-3676
Oscilloscope
6625000793676 000793676 MIL09970
A test instrument which is designed to give visual indications on an LCD display or a cathode ray tube of instantaneous values and variations in electrical voltage. It can also be used to indicate any quantity which can be converted into terms of electrical potential. It may include an integral pulse generator, the output of which can be used to trigger an external component; be triggered by pulses from an external source, or it may utilize an LCD display or a special type of multigun cathode ray tube and circuitry which permits a trace(s) to be sustained and displayed indefinitely, and the trace(s) may be erased when desired. For items which are not separable and operable when detached from equipment of which they are a part (built into operational equipment), see INDICATOR (2) (as modified); MONITOR (as modified); and RECORDER (as modified). See also OSCILLOGRAPH. View more Oscilloscope
May 2023
13
Marketplace 6625-00-079-3676
Request a Quotation from participating marketplace vendors
Related Documents 6625-00-079-3676 1+ Documents (More...)
6625-00-079-3676 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-66/fsc-6625/us 6625-00-079-3676
Oscilloscope 6625000793676000793676,MIL09970 MIL09970 A test instrument which is designed to give visual
Restrictions 6625-00-079-3676
6625-00-079-3676 is a Oscilloscope that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 6625-00-079-3676
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6625-00-079-3676
- Italy (ZR01)
- Effective Date:
- 1 Dec 2007
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 6625-00-079-3676
- Part Number
- Manufacturer
- Status
- MIL09970
- Manufacturer
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 6625-00-079-3676
- Characteristic
- Specifications
- FIIG
- Specifications
- T320-G
- Accessory Components And Quantity [AKYD]
- Adapter 2,Cable Assy 1,Cord,Power 1,Filter,Light 1,Lead,Ground 1,Lead,Test 1,Probe,Test 1,Tip,Test 1
- Accuracy Range In Percent [BDJD]
- +0.0 To 3.0
- Amplifier Deflection Sensitivity Provision [BHDD]
- Not Provided
- Amplifier Input Impedance Rating Provision [BHDT]
- Provided
- Amplitude Calibrating Voltage Waveform [BHDZ]
- Square Wave
- Beam Quantity [ATES]
- 1
- Camera Recording Device Accommodation [BHFT]
- Not Provided
- Calibrated Screen Scale [BHFF]
- Not Included
- Calibrating Peak To Peak Amplitude [BHFB]
- 1.0 Volts Nominal
- Current Type [ACDC]
- Ac
- Expanded Sweep [BGSD]
- Provided
- Frequency Rating [ACZB]
- 50.0 Hertz Minimum And 400.0 Hertz Maximum
- Fsc Application Data [ZZZV]
- 1. Oscilloscope,Except,Specially Designed
- Frequency Response Rating [BHDP]
- Provided
- Measurement Range Steps [BHFD]
- 0.05 To 20 V Per Cm
- Measurement Range Quantity [BHFC]
- 3
- Input Intensity Modulation Feature [BHDH]
- Not Provided
- Plate Direct Connection Deflection Sensitivity Provision [BHDL]
- Not Provided
- Screen Size [BGQK]
- 5 In.
- Phase [FAAZ]
- Single
- Trace Storage Tube [BHFH]
- Not Included
- Voltage Rating [AMSE]
- 105.0 Volts Minimum And 125.0 Volts Maximum
- X-Axis Frequency Response Rating [BHDQ]
- 0.0 Megahertz Minimum And 15.0 Megahertz Maximum
- X-Axis Input Impedance Rating [BHDW]
- 1.0 Megohms Nominal
- Y-Axis Input Impedance Rating [BHDX]
- 1.0 Megohms Nominal
Similar Supply Items to 6625-00-079-3676
Freight Information 6625-00-079-3676
6625-00-079-3676 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 6625-00-079-3676 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 6625-00-079-3676 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 6625-00-079-3676 is not classified as a special type of cargo when transported by water. 6625-00-079-3676 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6625-00-079-3676
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-1672, Type III, Telescoping Encapsulated Cushioning in Reusable Box
- Method 50
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- No Requirement
