6625-00-068-5564
Voltmeter
6625000685564 000685564 1531 S04488-25R 1531-261014 1531-0-8VDC
An instrument which measures electrical potential and is calibrated in volts or any multiple and/or submultiple thereof. The value may be expressed by means of a pointer and calibrated dial or a digital readout display. View more Voltmeter
May 2023
11
Marketplace 6625-00-068-5564
Request a Quotation from participating marketplace vendors
Related Documents 6625-00-068-5564 5+ Documents (More...)
/fsg-66/fsc-6625/us
( More... ) https//www.nsnlookup.com /fsg-66/fsc-6625/us 6625-00-068-5564 Voltmeter 6625000685564 000685564,1531
6625-00-068-5564 Voltmeter 6625000685564 https// https// https//www.nsnlookup.com https//www.nsnlookup.com
Voltmeter 6625000685564 000685564,1531 6625000685564 https// https// https//www.nsnlookup.com https
Restrictions 6625-00-068-5564
6625-00-068-5564 is a Voltmeter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 6625-00-068-5564
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6625-00-068-5564
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 6625-00-068-5564
- Part Number
- Manufacturer
- Status
- S04488-25R
- Manufacturer
- 55026 - Simpson Electric Company, Inc. (Active)
- Original Design
- Original Design
- 1531
- 65092 - Solartron Electronics Inc (Obsolete)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 1531-261014
- 65092 - Solartron Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 1531-0-8VDC
- 65092 - Solartron Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6625-00-068-5564
- Characteristic
- Specifications
- FIIG
- Specifications
- A310A0
- Accuracy In Percent [APPN]
- -2.0 To 2.0 At Full Scale Single Indicator Single Range
- Background Color [AQFY]
- White Single Indicator Single Range
- Circuit Attachment Method And Quantity [CTTD]
- 2 Threaded Stud
- Circuit Current For Which Designed [AACT]
- Dc
- Dial Scale Marking Color [APMM]
- Black Single Indicator Single Range
- Furnished Items And Quantity [AKYN]
- Screw 3; Nut 5; Washer 5
- Environmental Protection [ADZC]
- Shock Proof And Waterproof
- Features Provided [CBBL]
- Zero Adjuster
- Material [MATT]
- Steel
- Measurement Range [BHMW]
- +0.0 To 8.0 Volts, Dc Single Indicator Single Range
- Meter Body Diameter Behind Mounting Flange [APSW]
- 2.800 Inches Nominal
- Meter Depth Behind Mounting Flange [APST]
- 1.405 Inches Maximum
- Mounting Arrangement Style [ANRL]
- Three Hole/Stud Bolt Circle
- Mounting Bolt Circle Diameter [AFFL]
- 3.160 Inches Nominal
- Mounting Hole Diameter [ABTB]
- 0.138 Inches Nominal
- Mounting Facility Type And Quantity [AXHR]
- 3 Unthreaded Hole
- Movement Suspension Method [CTQL]
- Jewel Pivot Base
- Movement Type [AQEC]
- Moving Coil, Permanent Magnet
- Nuclear Hardness Critical Feature [NHCF]
- Nonhardened
- Fsc Application Data [ZZZV]
- Test Set,Elect. Equip.
- Installation Design [AMQY]
- Panel
- Indicator Type [AMKD]
- Dial W/Pointer
- Pointer Color [ASSS]
- Black Single Indicator Single Range
- Power Source [AWZJ]
- External
- Scale Division Quantity [ABWG]
- 40 Single Indicator Single Range
- Scale Graduation Type [BHDC]
- Linear Single Indicator Single Range
- Sensitivity Rating [ANTG]
- 1000.0 Ohms Per Volt
- Overall Diameter [ADAV]
- 3.500 Inches Maximum
- Overall Length [ABHP]
- 1.785 Inches Nominal
- Special Features [FEAT]
- Ruggedized
- Style Designator [STYL]
- Round Flush Mtg
Similar Supply Items to 6625-00-068-5564
Freight Information 6625-00-068-5564
6625-00-068-5564 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 136740. A Sub NMFC of Z. It has a NMFC Description of METERS ELEC/PARTS. 6625-00-068-5564 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 68820 which rates the freight between FCL and LCL. 6625-00-068-5564 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 657 for ocean manifesting and military sealift. 6625-00-068-5564 is not classified as a special type of cargo when transported by water. 6625-00-068-5564 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6625-00-068-5564
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
