6620-00-232-2048
Pressure Indicator
6620002322048 002322048 6300A15A1A2
An indicator which indicates the pressure of a gas or liquid in a given system. View more Pressure Indicator
May 2023
18
Marketplace 6620-00-232-2048
Request a Quotation from participating marketplace vendors
Related Documents 6620-00-232-2048 4+ Documents (More...)
RQST NE Updated Every Day 6620-00-232-2048 RQST Updated Every Day 6620-00-232-2048 RQST NE Related
Documents 6620-00-232-2048 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-66/fsc-6620/us 6620
Restrictions 6620-00-232-2048
6620-00-232-2048 is a Pressure Indicator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6620-00-232-2048
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6620-00-232-2048
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 6620-00-232-2048
- Part Number
- Manufacturer
- Status
- 6300A15A1A2
- Manufacturer
- 96774 - Honeywell International Inc. (Active)
- Primary Buy
- Primary Buy
- 6300A15A1A2
- 55972 - Honeywell Intl Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6620-00-232-2048
- Characteristic
- Specifications
- FIIG
- Specifications
- A533Y0
- Electrical Connection Identifying Number [ASKZ]
- An3102c16s1p
- Electrical Connection Quantity [ASKX]
- 1
- Accuracy Rating [BNHZ]
- 2.0 Pounds Single Indicator Single Scale
- Contact Quantity [AFRA]
- 7
- Contact Type [AKSF]
- Pin
- Current Type [ACDC]
- Ac
- Dc Voltage Rating [ACYR]
- 26.0 Volts Nominal
- Features Provided [CBBL]
- Encapsulated
- Frequency Rating [ACZB]
- 400.0 Hertz Nominal
- Height [HGTH]
- 3.250 Inches Nominal
- Mounting Stud Diameter [BLKZ]
- 0.144 Inches Nominal
- Nondefinitive Spec/Std Data [ZZZT]
- 0-4-12 Type
- Illumination Color Generation Method [AWHH]
- Fluorescence
- Individual Marking [ASKN]
- One Marked 1 And One Marked 2
- Length [ABRY]
- 5.609 Inches Nominal
- Scale Marking And Surface Finish [ABFN]
- Letters Fluorescent And Lined Increments Fluorescent And Numerals Fluorescent
- Phase [FAAZ]
- Three
- Width [ABGL]
- 3.250 Inches Nominal
Similar Supply Items to 6620-00-232-2048
Freight Information 6620-00-232-2048
6620-00-232-2048 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 121570. A Sub NMFC of X. It has a NMFC Description of GAGES AIR LIQUID LEVEL PRESSURE. 6620-00-232-2048 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. 6620-00-232-2048 is rated as class 100 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 61770 which rates the freight between FCL and LCL. 6620-00-232-2048 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 652 for ocean manifesting and military sealift. 6620-00-232-2048 is not classified as a special type of cargo when transported by water. 6620-00-232-2048 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
