6530-00-937-2204
Field Surgical Light
6530009372204 009372204 34643324D820-34 MILL36531
An item consisting of a light-head, standard, base and cables which is designed for illumination of the operative field. It may include batteries and is specially constructed for disassembly and storage in a carrying case. View more Field Surgical Light
May 2023
16
Marketplace 6530-00-937-2204
Request a Quotation from participating marketplace vendors
Related Documents 6530-00-937-2204 5+ Documents (More...)
RQST NE Updated Every Day 6530-00-937-2204 RQST Updated Every Day 6530-00-937-2204 RQST NE Related Documents
6530-00-937-2204 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-65/fsc-6530/us 6530-00-937-2204
Field Surgical Light 6530009372204 009372204 Day 6530-00-937-2204 RQST NE Related Documents https
(Active) Related Standard RNCC 2 RNVC 1 DAC 3 Similar Supply Items to 6530-27-007-1539 6530-00-937-2204
50306-Sfl2204-293Part Name Assigned By Controlling Agency [CXCY]Telescopic Assembly End Item Nsn 6530-00-937-2204
505-5306 6530-00-092-3118 6530-01-673-4063 6530-01-464-0267 6530-01-139-9467 6530-01-600-3142 6530-00-937-2204
-98-103-6814 6530014689892014689892 65/fsc-6530/no 6530-25-136-8470 https//www.nsnlookup.com 6530-00-937-2204
-6530/nz 6530-98-103-6814 Field Surgical Light 6530981036814981036814 6530251368470251368470 6530-00-937-2204
www.nsnlookup.com /fsg-65/fsc-6530/no 6530-25-136-8470 Field Surgical Light 6530251368470251368470 6530-00-937-2204
Apotek (Obsolete) Secondary Buy RNCC 5 RNVC 2 DAC 9 Similar Supply Items to 6530-25-136-8470 6530-00-937-2204
Restrictions 6530-00-937-2204
IUID Required
6530-00-937-2204 is a Field Surgical Light that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6530-00-937-2204
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6530-00-937-2204
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Oct 2009
Approved Sources 6530-00-937-2204
- Part Number
- Manufacturer
- Status
- MILL36531
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- 34643324D820-34
- 89875 - Defense Logistics Agency Directorate (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
Datasheet 6530-00-937-2204
- Characteristic
- Specifications
- FIIG
- Specifications
- A06300
- Battery Type And Quantity Required [CSGT]
- 1 Wet
- Furnished Items And Quantity [TMQY]
- 1 Carrying Case And 10 Fuse And 2 Lamp
- Features Provided [CBBL]
- Automatic Switching Relay And Switch
- Material [MATT]
- Aluminum Body
- Material [MATT]
- Aluminum Case
- Material [MATT]
- Aluminum Reflector
- Mounting Base Height [AEXX]
- 10.000 Inches Nominal
- Mounting Base Length [AEXV]
- 31.437 Inches Nominal
- Mounting Base Width [AEXW]
- 19.437 Inches Nominal
- Mounting Method [AXGY]
- Case
- Part Name Assigned By Controlling Agency [CXCY]
- Light Surgical Field: 110 Volt Ac Or 24 Volt Dc
- Lamp Base Type Accommodated [AEUJ]
- Medium Screw
- Lamp Type Accommodated And Quantity [CRHX]
- 1 Incandescent
- Light Adjustment Method [AEYR]
- Floating Arm
- Reflector Shape [AEYW]
- Terraced Cone
- Special Features [FEAT]
- 150 Watts; Equipped W/Heat Cylinder; W/Two Compression Clips; Portable; Packed In A Modified No. 3 Medical Chest As A Mounting Base; Vertical And Horizontal Supports; 24 Volt Power Supply Provides For Lamp Operation And Battery Charging,Without Battery; For Replacement Chest Seal,Order,5330-00-899-9662; For Replacement Lamp,Order According To Manufacturer And Model; With Two Spare 150 Watt,24 Volt Lamps
- Overall Diameter [ADAV]
- 17.000 Inches Nominal
- Voltage Rating In Volts [ASXH]
- 115.0 Ac Nominal Or 24.0 Dc Nominal
- Wiring Provision Length [AHHZ]
- 300.0 Inches Nominal Second Provision
- Wiring Provision Method [AEYB]
- Cable Assembly
- Wiring Provision Length [AHHZ]
- 96.0 Inches Nominal First Provision
- Surface Treatment [SFTT]
- Anodize Reflector
- Surface Treatment [SFTT]
- Enamel Case
- Surface Treatment [SFTT]
- Enamel Body
- Terminal Type And Quantity [TTQY]
- 1 Connector, Plug, External, Curved Blade, 3 Wire
DLA Procurement Analysis 6530-00-937-2204
Management Data 6530-00-937-2204
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2011
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Defense Logistics Agency (DS)
- I
- V
- Discontinued W/O Replacement
- V
Similar Supply Items to 6530-00-937-2204
Freight Information 6530-00-937-2204
6530-00-937-2204 has freight characteristics managed by the Bonneville Power Administration.It has a National Motor Freight Classification (NMFC) of 109700. A Sub NMFC of Z. It has a NMFC Description of LAMP OR LIGHTING FIXTURES. 6530-00-937-2204 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55690 which rates the freight between FCL and LCL. 6530-00-937-2204 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 761 for ocean manifesting and military sealift. 6530-00-937-2204 is not classified as a special type of cargo when transported by water. 6530-00-937-2204 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 6530-00-937-2204 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
