6240-01-181-9565
Incandescent Lamp
6240011819565 011819565 530506-231 12311
An item whose principal purpose is to produce light from a glowing filament(s). It includes metal backed and reflecting types, seal beam and flood types. It may include an integral filament shield to control and/or modify its illumination pattern. View more Incandescent Lamp
November 2023
5
Marketplace 6240-01-181-9565
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 6240-01-181-9565 5+ Documents (More...)
(Identification) 1/2 NSN 6240-01-181-9565 (Identification) 2/2 - - 1.
... 12311 LAMP,INCANDESCENT 4 EA NS Request Quotation Updated Every Day 6240-01-181-9565 RQST NE Updated
/fsg-59/fsc-5995/fr
Incandescent Lamp 6240011819565 011819565 for $1 a day Upgrade your Account Upgrade 6240-01-181
-9565Incandescent Lamp6240011819565 011819565 530506 //www.nsnlookup.com /fsg-62/fsc-6240/us 6240-01-
Account Upgrade 7643-01-402-9365Topographic Geospatial Products7643014029365 014029365M711X12311M711 12311
00-074-9553 Electric Brush Assy 6610000749553 000749553 5725 Part NumberManufacturerStatus9599 607 12311
9599-607-12311 An item consisting of a conductor or a system of conductors specifically designed to
JavaScript in your web browser . 5826-14-313-5725Antenna5826143135725 1431357259599 607 123119599-607-12311
-625 12311-625 A deformable material which prevents the passage of matter through the joint formed when
https//www.nsnlookup.com /fsg-53/fsc-5330/fr 5330-14-489-3396 Gasket 5330144893396144893396 K7739-12311
Restrictions 6240-01-181-9565
6240-01-181-9565 is a Incandescent Lamp that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 6240-01-181-9565
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6240-01-181-9565
- US Army (A920)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- A186
- Supplementary Receivers:
- CL
- US Air Force (FXGI)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- FXKZ
- US Navy (N9BZ)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
Approved Sources 6240-01-181-9565
- Part Number
- Manufacturer
- Status
- 530506-231
- Manufacturer
- 06175 - Bausch & Lomb Inc (Active)
- Primary Buy
- Primary Buy
- 12311
- 62607 - Philips Electronics North America (Active)
- Secondary Buy
- Secondary Buy
Datasheet 6240-01-181-9565
- Characteristic
- Specifications
- FIIG
- Specifications
- A07900
- Base Style [CRPS]
- X511
- Bulb Style [CRSK]
- T (Tubular)
- Bulb Designator [CSJW]
- T-3
- Overall Length [ABHP]
- 31.0 Millimeters Nominal
- Bulb Light Transmission Characteristic [CSMC]
- Transparent
- Emitted Light Characteristic [AGDV]
- Colorless
- Wattage Rating [BDWW]
- 55.000 Watts
- Voltage Rating [AMSE]
- 12.000 Volts Nominal
- Current Rating For Which Designed [CTQM]
- 4.583 Amperes Nominal
- Light Output Rating [AFST]
- 1800.000 Lumens Nominal Single Rating
- Rated Average Life [CWBF]
- Hours
- Average Life Rating In Hours [AFSV]
- 150.0
- Burning Position [CWGK]
- Any Acceptable
- Filament Heavy Duty Service Rating [AFSX]
- Not Rated
- Special Features [FEAT]
- Low Voltage Halogen
DLA Procurement Analysis 6240-01-181-9565
- Last Stock Position:
- 11 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 6240-01-181-9565
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 6240-01-181-9565
Freight Information 6240-01-181-9565
6240-01-181-9565 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 109550. A Sub NMFC of X. It has a NMFC Description of LAMPS(BULBS) ELEC INCANDESCENT NOI. 6240-01-181-9565 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55910 which rates the freight between FCL and LCL. 6240-01-181-9565 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 761 for ocean manifesting and military sealift. 6240-01-181-9565 is not classified as a special type of cargo when transported by water. 6240-01-181-9565 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6240-01-181-9565
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- Fragile
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Procurement History 6240-01-181-9565 3 Records
Contracting Technical Data File (CTDF) 6240-01-181-9565 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
