6240-00-866-4143
Incandescent Lamp
6240008664143 008664143 MS17231PC11 4546 A-A-2042 GE4546 624000131 P44099 MS16524-2 34567 EL59-001-123 6240PL1376384
An item whose principal purpose is to produce light from a glowing filament(s). It includes metal backed and reflecting types, seal beam and flood types. It may include an integral filament shield to control and/or modify its illumination pattern. View more Incandescent Lamp
Managed by United States
NSN Created on 1 Jan 1962
Data Last Changed
November 2023
November 2023
NATO Update Count
55
55
NATO Data Quality
Product Information 6240-00-866-4143
2.3W 4.7V PAR36 Incandescent Bulb - Screw Terminals
- Base: Screw Terminals
- Specifications: 2.3 Watts, 4.7 Volts, PAR36 Incandescent Lamp
- Bulb Finish: Clear Glass
Marketplace 6240-00-866-4143
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 6240-00-866-4143 5+ Documents (More...)
MS17231PC11 4546 A-A-2042 GE4546 624000131 P44099 MS16524-2 34567 EL59-001-123 6240PL1376384 An item
Quotation GE4546 LAMP,INCANDESCENT 6 EA NS Request Quotation Subscribe to View Vendor Details... 4546
Subscribe to View Vendor Details... 4546 GE4546 LAMP,INCANDESCENT 1 EA NS Request Quotation MS16524-
Quotation GE4546 LAMP,INCANDESCENT 6 EA NS Request Quotation Subscribe to View Vendor Details... 4546
Subscribe to View Vendor Details... 4546 GE4546 LAMP,INCANDESCENT 1 EA NS Request Quotation MS16524-
8 EA NS Request Quotation GE4546 LAMP,INCANDESCENT 6 EA NS Request Quotation Subscribe to View Vendor
Details... 4546 LAMP,INCANDESCENT 2 EA NS Request Quotation 34567 LAMP,INCANDESCENT 2 EA NS Request
to View Vendor Details... 34567 LAMP,INCANDESCENT 220 EA NS Request Quotation Subscribe to View Vendor
Details... 4546 LAMP,INCANDESCENT 2 EA NS Request Quotation 34567 LAMP,INCANDESCENT 2 EA NS Request
to View Vendor Details... 34567 LAMP,INCANDESCENT 220 EA NS Request Quotation Subscribe to View Vendor
GE4546 LAMP,INCANDESCENT 6 EA NS Request Quotation 4546 LAMP,INCANDESCENT 8 EA NS Request Quotation Subscribe
to View Vendor Details... 34567 LAMP,INCANDESCENT 2 EA NS Request Quotation 4546 LAMP,INCANDESCENT 2
EA NS Request Quotation Subscribe to View Vendor Details... 4546 LAMP,INCANDESCENT 36 EA NS Request
to View Vendor Details... 34567 LAMP,INCANDESCENT 2 EA NS Request Quotation 4546 LAMP,INCANDESCENT 2
EA NS Request Quotation Subscribe to View Vendor Details... 4546 LAMP,INCANDESCENT 36 EA NS Request
JavaScript in your web browser . 9510-99-571-0323Metal Bar9510995710323 995710323 DNCS2A BS970 0212-34567
DNCS2A JavaScript in your web browser . 9510-99-571-0323Metal Bar9510995710323 995710323DNCS2ABS9700212-34567
And Barrel Assembly,438234567 Bkos7035221262180 https//www.nsnlookup.com /fsg-62/fsc-6240/us 6240-00-866-4143
DNCS2A JavaScript in your web browser . 9510-99-571-0323Metal Bar9510995710323 995710323DNCS2ABS9700212-34567
And Barrel Assembly,438234567 Bkos7035221262180 https//www.nsnlookup.com /fsg-62/fsc-6240/us 6240-00-866-4143
https//www.nsnlookup.com /fsg-62/fsc-6240/us 6240-00-866-4143 Incandescent Lamp 6240008664143 008664143
,SL-34567 ,SL-34567 January 221262180221262180,SL-34567 Bkos7035221262180 221262180SL-34567 https//www.nsnlookup.com
/fsg-70/fsc-7035/dk Bkos 7035221262180 221262180,SL-34567 Bkos 7035221262180221262180,SL-34567 ,SL-34567
,SL-34567 ,SL-34567 January 221262180221262180,SL-34567 Bkos7035221262180 221262180SL-34567 https//www.nsnlookup.com
/fsg-70/fsc-7035/dk Bkos 7035221262180 221262180,SL-34567 Bkos 7035221262180221262180,SL-34567 ,SL-34567
Restrictions 6240-00-866-4143
6240-00-866-4143 is a Incandescent Lamp that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 6240-00-866-4143
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6240-00-866-4143
- US Army (A920)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- A186
- Supplementary Receivers:
- AZ
- US Coast Guard (C918)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- C003
- US Air Force (FXGI)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- FXKZ
- NASA (G280)
- Effective Date:
- 1 Apr 1991
- NASA (G860)
- Effective Date:
- 1 Apr 1991
- NASA (G940)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC47)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- MC10
- US Navy (N9BZ)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- GTJBHXHD
- Poland (WP01)
- Effective Date:
- 1 May 2006
- Brazil (YA01)
- Effective Date:
- 1 Jan 2002
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Sep 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Jun 1996
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Jan 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Philippines (ZM01)
- Effective Date:
- 1 Feb 2015
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 6240-00-866-4143
- Part Number
- Manufacturer
- Status
- 4546
- Manufacturer
- 08108 - Lamp Industry (Active)
- Incomplete Reference
- Incomplete Reference
- MS17231PC11
- 96906 - Military Standards (Active)
- Incomplete Standard
- Incomplete Standard
- 4546
- 62607 - Philips Electronics North America (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 4546
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 4546
- 08805 - General Electric Company (Active)
- Secondary Buy
- Secondary Buy
- A-A-2042
- 58536 - Federal Commercial Item Description (Active)
- Secondary Buy
- Secondary Buy
- 4546
- 80204 - American National Standards (Active)
- Secondary Buy
- Secondary Buy
- GE4546
- 08808 - General Electric Co Lamp Glass And (Active)
- Secondary Buy
- Secondary Buy
- 624000131
- 094BB - Gauzon Iberica Sl (Active)
- Secondary Buy
- Secondary Buy
- 4546
- 0KH33 - Bulbtronics (Active)
- Secondary Buy
- Secondary Buy
- 4546
- 9F443 - Jay Moulding Corp (Active)
- Secondary Buy
- Secondary Buy
- 4546
- 94988 - Cooper Industries Inc Champion (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- P44099
- 16783 - Delta Electric Div Halle Industries (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- MS16524-2
- 96906 - Military Standards (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 34567
- 75175 - Concord Instruments Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- EL59-001-123
- 93568 - Harsco Corp Bmy-Combat Systems Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 6240PL1376384
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 4546
- 82146 - Naval Supply Systems Command (Active)
- Advisory Reference
- Advisory Reference
Datasheet 6240-00-866-4143
- Characteristic
- Specifications
- FIIG
- Specifications
- A07900
- Emitted Light Characteristic [AGDV]
- Colorless
- Average Life Rating In Hours [AFSV]
- 100.0
- Base Style [CRPS]
- Two Screw Terminals
- Bulb Designator [CSJW]
- Par-36
- Bulb Light Transmission Characteristic [CSMC]
- Transparent
- Bulb Style [CRSK]
- Par (Parabolic, Aluminized Reflector)
- Burning Position [CWGK]
- Any Acceptable
- Current Rating For Which Designed [CTQM]
- 0.500 Amperes Nominal
- End Item Identification [AGAV]
- Ws: Navigation Radio Set; Fire Pumps; Landing Craft, Utility, 115 Ft; Landing Craft Air Cushion (Lcac); Los Angeles Class Cgn (688); Sturgeon Class Ssn (637); Ticonderoga Class Cg (47); Virginia Class Cgn (41); Spruance Class Dd (963); Forrestal Class Cv
- Filament Designation [AFSP]
- C-2R
- Filament Heavy Duty Service Rating [AFSX]
- Not Rated
- Light Intensity Distribution Feature [CSRJ]
- Parabolic Reflector
- Light Output Rating [AFST]
- 6300.000 Beam Candlepower Nominal Single Rating
- Rated Average Life [CWBF]
- Hours
- Overall Length [ABHP]
- 2.750 Inches Maximum
- Voltage Rating [AMSE]
- 4.700 Volts Nominal
- Wattage Rating [BDWW]
- 2.350 Watts
- Specification/Standard Data [ZZZK]
- 08108-4546 Manufacturers Standard
Weapon Systems (WSDC) 6240-00-866-4143
DLA Procurement Analysis 6240-00-866-4143
- Last Stock Position:
- 6168 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 6240-00-866-4143
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Material Identification:
- B
- Consumable Repair Parts
- Operational Test:
- No Special Procedures
Similar Supply Items to 6240-00-866-4143
Freight Information 6240-00-866-4143
6240-00-866-4143 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 109550. A Sub NMFC of X. It has a NMFC Description of LAMPS(BULBS) ELEC INCANDESCENT NOI. 6240-00-866-4143 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55910 which rates the freight between FCL and LCL. 6240-00-866-4143 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 761 for ocean manifesting and military sealift. 6240-00-866-4143 is not classified as a special type of cargo when transported by water. 6240-00-866-4143 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6240-00-866-4143
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Procurement History 6240-00-866-4143 14 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A623F6936
- 06 Feb 2023
- Subscribe
- 1441
- Subscribe
- Subscribe
- Subscribe
- SPE4A623F6936
- 06 Feb 2023
- Subscribe
- 1441
- Subscribe
- Subscribe
- Subscribe
- SPE4A622F6349
- 10 Jan 2022
- Subscribe
- 1441
- Subscribe
- Subscribe
- Subscribe
- SPE4A622F6349
- 10 Jan 2022
- Subscribe
- 1441
- Subscribe
- Subscribe
- Subscribe
- SPE4A622F5626
- 17 Dec 2021
- Subscribe
- 1596
- Subscribe
- Subscribe
- Subscribe
- SPE4A622F5626
- 17 Dec 2021
- Subscribe
- 1596
- Subscribe
- Subscribe
- Subscribe
- SPE4A616D50500001
- 24 Nov 2015
- Subscribe
- 4000
- Subscribe
- Subscribe
- Subscribe
- SPE4A615MC160
- 08 Jul 2015
- Subscribe
- 129
- Subscribe
- Subscribe
- Subscribe
- SPE4A615VG160
- 15 Jun 2015
- Subscribe
- 1383
- Subscribe
- Subscribe
- Subscribe
- SPE4A615MA730
- 03 Jun 2015
- Subscribe
- 5518
- Subscribe
- Subscribe
- Subscribe
- SPE4A613D01720023
- 14 Oct 2014
- Subscribe
- 571
- Subscribe
- Subscribe
- Subscribe
- SPE4A613D0172001201
- 26 Mar 2014
- Subscribe
- 4571
- Subscribe
- Subscribe
- Subscribe
- SPE4A613MN501
- 06 Aug 2013
- Subscribe
- 4794
- Subscribe
- Subscribe
- Subscribe
- SPM4A411D5L90000802
- 29 Jan 2013
- Subscribe
- 516
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 6240-00-866-4143 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
