6240-00-295-2668

Incandescent Lamp

6240002952668 002952668 A-A-52463 1691 27566 R2418 E-0569 HYL8585 397218-1 AA52463-B11 0707234 MS35478-1691 072601 024160 AA52463-2-11

An item whose principal purpose is to produce light from a glowing filament(s). It includes metal backed and reflecting types, seal beam and flood types. It may include an integral filament shield to control and/or modify its illumination pattern. View more Incandescent Lamp

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
November 2023

NATO Update Count
87

NATO Data Quality

CRPS Style A18B for 6240-00-295-2668 1/2 — NSN 6240-00-295-2668 (Identification) 1/2

CRSK Style B22 for 6240-00-295-2668 2/2 — NSN 6240-00-295-2668 (Identification) 2/2

Marketplace 6240-00-295-2668

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

1691 LAMP,INCANDESCENT 187 EA NS

Subscribe to View Vendor Details...

1691 LAMP,INCANDESCENT 29 EA NS

Subscribe to View Vendor Details...

MS35478-1691 LAMP,INCANDESCENT 10 EA NS

Subscribe to View Vendor Details...

1691 LAMP,INCANDESCENT 99 EA NS

Subscribe to View Vendor Details...

MS35478-1691 LAMP,INCANDESCENT 74 EA NS

Subscribe to View Vendor Details...

1691 LAMP,INCANDESCENT 116 EA NS

MS35478-1691 LAMP,INCANDESCENT RQST NS

Subscribe to View Vendor Details...

MS35478-1691 LAMP,INCANDESCENT 50 EA NS

1691 LAMP,INCANDESCENT 18 EA NS

Subscribe to View Vendor Details...

1691 LAMP,INCANDESCENT 125 EA NS

Subscribe to View Vendor Details...

AA52463-B11 LAMP 1 EA NS

1691 LAMP 123 EA NS

Subscribe to View Vendor Details...

1683 LAMP,INCANDESCENT 84 EA NS

Subscribe to View Vendor Details...

6240-00-295-2668 LIGHT 45 EA NS

Subscribe to View Vendor Details...

1691 LAMP,INCANDESCENT 5 EA NS

Subscribe to View Vendor Details...

MS354781691 LAMP,INCANDESCENT 153 EA NS

Subscribe to View Vendor Details...

MS35478-1691 LAMP,INCANDESCENT 2 EA NS

Subscribe to View Vendor Details...

16.9-1 LAMP,INCANDESCENT 2 EA NS

Subscribe to View Vendor Details...

002952668.6240 LAMP,INCANDESCENT 18 EA NS

1549159 LAMP,INCANDESCENT 45 EA NS

Subscribe to View Vendor Details...

MS35478-1691 LAMP,INCANDESCENT 19 EA NS

Updated Every 15 Minutes

6240-00-295-2668 BUY NE

Updated Every Day

072601 024160 RQST NE

Updated Every Day

6240-00-295-2668 RQST NE

Updated Every Day

6240-00-295-2668 RQST

Updated Every Day

6240-00-295-2668 RQST NE

Restrictions 6240-00-295-2668

6240-00-295-2668 is a Incandescent Lamp that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 6240-00-295-2668

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 6240-00-295-2668

US Army (A920)
Effective Date:: 1 May 2006
Former MOE Rule:: A186
Supplementary Receivers:: AZBFBD; AMC 1 AMSC G IMC Z IMCACTY CD

MOE Rule:: B031
Effective Date:: 1 Apr 1991; AMC 1 AMSC Z

MOE Rule:: BGX1
Effective Date:: 1 May 2006
Former MOE Rule:: BKZ1; AMC 1 AMSC G

US Air Force (FXGI)
Effective Date:: 1 May 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC G IMC Z IMCACTY SX

NASA (G26X)
Effective Date:: 1 May 2006
Former MOE Rule:: G26I; AMC 1 AMSC G

US Marine Corps (MC47)
Effective Date:: 1 May 2006
Former MOE Rule:: MC10; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BZ)
Effective Date:: 1 May 2006
Former MOE Rule:: N9ZD
Supplementary Collaborators:: GTKEHD; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Lithuania (WI01)
Effective Date:: 1 Jan 2002

Poland (WP01)
Effective Date:: 1 Aug 2006

Brazil (YA01)
Effective Date:: 1 Jan 2002

Spain (YB01)
Effective Date:: 1 Apr 1991

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Morocco (YP01)
Effective Date:: 1 Nov 2008

Malaysia (YW01)
Effective Date:: 1 Mar 1997

Thailand (YY01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Dec 2002

Canada (ZC01)
Effective Date:: 1 Apr 1998

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Apr 1991

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Aug 1993

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Apr 1991

Approved Sources 6240-00-295-2668

Part Number
Manufacturer
Status
AA52463-B11: 58536 - Federal Commercial Item Description (Active); Definitive Standard; RNCC 2 RNVC 2 DAC 4
A-A-52463: 58536 - Federal Commercial Item Description (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC 4
1691: Z0Z03 - Ge Lighting Australia (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
27566: Z0Z03 - Ge Lighting Australia (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
R2418: Z0645 - Hella Australia Pty Ltd (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
072601 024160: 64678 - Daimler Truck North America Llc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
E-0569: Z0054 - Bt Equipment Pty Ltd (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 9
HYL8585: Z5394 - Jaguar Land Rover Australia Pty Ltd (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
0707234: S3002 - General Dynamics European, (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
MS35478-1691: 96906 - Military Standards (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
072601 024160: D8046 - Daimler Ag (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 9
AA52463-2-11: 58536 - Federal Commercial Item Description (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
6240002952668: SCY13 - E.C.A Etablissement (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 9
6240002952668: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
397218-1: D9182 - Zf Industrieantriebe Witten Gmbh (Active); Advisory Reference; RNCC C RNVC 1 DAC 6

Datasheet 6240-00-295-2668

Characteristic
Specifications
FIIG: A07900
Emitted Light Characteristic [AGDV]: Colorless
Average Life Rating In Hours [AFSV]: 1000.0
Base Style [CRPS]: Single Contact Bayonet Candelabra
Bulb Designator [CSJW]: S-8
Bulb Light Transmission Characteristic [CSMC]: Transparent
Bulb Style [CRSK]: S (Straight Side)
Burning Position [CWGK]: Any Acceptable
Current Rating For Which Designed [CTQM]: 0.610 Amperes Nominal
Filament Designation [AFSP]: 2C-2R
Filament Heavy Duty Service Rating [AFSX]: Not Rated
Light Center Length [AGDW]: 1.130 Inches Nominal
Light Output Rating [AFST]: 15.000 Spherical Candlepower Nominal Single Rating
Rated Average Life [CWBF]: Hours
Overall Length [ABHP]: 2.000 Inches Maximum
Voltage Rating [AMSE]: 28.000 Volts Nominal
Wattage Rating [BDWW]: 17.080 Watts

Weapon Systems (WSDC) 6240-00-295-2668

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 6240-00-295-2668

Last Stock Position:: 5129 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 6240-00-295-2668

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Feb 2020: Department of the Army (DA); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
US Marine Corps (DM): M; 4; Reversal Of Phrase Code A 6240-01-440-7503

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SX: SICA RESIDUAL MMAC-OC-ALC

Price Validation Code:

V: The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

2: Non-Critical Repair Part

Echelon Management:

B2

Material Identification:

K: Reserved

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 6240-00-295-2668

6240-99-996-2405 6240-99-996-4441 6240-22-611-0249 6240-12-338-2074 6240-99-996-5391 6240-22-623-8958 6240-99-995-9167 6240-99-996-2502 6240-99-996-4865 6240-99-995-2272 6240-22-283-2065 6240-99-732-2730 6240-99-909-6302 6240-99-769-8616 6240-12-702-6353 6240-21-849-4701 6240-21-898-7720 6240-99-996-4618

Freight Information 6240-00-295-2668

6240-00-295-2668 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 109550. A Sub NMFC of X. It has a NMFC Description of LAMPS(BULBS) ELEC INCANDESCENT NOI. 6240-00-295-2668 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55910 which rates the freight between FCL and LCL. 6240-00-295-2668 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 761 for ocean manifesting and military sealift. 6240-00-295-2668 is not classified as a special type of cargo when transported by water. 6240-00-295-2668 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 6240-00-295-2668

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Electrical Instrument; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box; Fragile

Intermediate Pack Level

Quantity of Unit Packs
Container: --

Procurement History 6240-00-295-2668 13 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE4A723V1493: 24 Feb 2023; Subscribe; 3571; Subscribe; Subscribe
SPE4A422F0088: 22 Jun 2022; Subscribe; 3571; Subscribe; Subscribe
SPE4A422F0088: 22 Jun 2022; Subscribe; 3571; Subscribe; Subscribe
SPE4A621F313S: 15 Jul 2021; Subscribe; 3571; Subscribe; Subscribe
SPE4A621F313S: 15 Jul 2021; Subscribe; 3571; Subscribe; Subscribe
SPE4A619F6273: 20 Dec 2018; Subscribe; 900; Subscribe; Subscribe
SPE4A618F0294: 03 Oct 2017; Subscribe; 3571; Subscribe; Subscribe
SPE4A614D55260005: 08 Aug 2017; Subscribe; 3571; Subscribe; Subscribe
SPE4A614D55260004: 16 Oct 2016; Subscribe; 3571; Subscribe; Subscribe
SPE4A614D55260003: 06 Oct 2015; Subscribe; 3571; Subscribe; Subscribe
SPE4A614D55260002: 17 May 2015; Subscribe; 3571; Subscribe; Subscribe
SPE4A614D55260001: 09 Apr 2014; Subscribe; 720; Subscribe; Subscribe
SPE4A614M6206: 06 Jan 2014; Subscribe; 3571; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 6240-00-295-2668 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 6240-00-295-2668

Related Documents 6240-00-295-2668 5+ Documents (More...)

Restrictions 6240-00-295-2668

Import and Export 6240-00-295-2668

End Users 6240-00-295-2668

Approved Sources 6240-00-295-2668

Datasheet 6240-00-295-2668

Weapon Systems (WSDC) 6240-00-295-2668

DLA Procurement Analysis 6240-00-295-2668

Management Data 6240-00-295-2668

Army

Air Force

Navy

Marine Corps

NATO Stock Numbers Related to 6240-00-295-2668

Freight Information 6240-00-295-2668

Packaging Data 6240-00-295-2668

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 6240-00-295-2668 13 Records

Contracting Technical Data File (CTDF) 6240-00-295-2668 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
