6220-00-577-3434

Clearance Marker Light

6220005773434 005773434 MIL-DTL-3976E MS35423-1 12338610-1 1309590 483036 5590273 29A32-71 MILL3976 11M56 2231-12-7 7261919 0624A0406 BG26988 25774 4391 9000-822 4551-01 36593 1069-8-136 11420F 747966-4 928570 6220PL0651531

A light specifically designed to indicate clearance and/or the general outline of a ground vehicle. View more Clearance Marker Light

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
November 2023

NATO Update Count
88

NATO Data Quality

6220-00-577-3434 LIGHT,MARKER,CLEARANCE 6220005773434 005773434 1/1 — 6220-00-577-3434 Photo 1/1

Marketplace 6220-00-577-3434

Need Help?
Request a Quotation from participating marketplace vendors

FinditParts

25774 Power Products 25-774 - Spring Seat,5"Round,1 1/4"Sh,Overslung STK NE $65.33 Distributor Buy Now

Subscribe to View Vendor Details...

3659-#3 LIGHT,MARKER,CLEARANCE 10 EA NS

Subscribe to View Vendor Details...

4391 LIGHT,MARKER,CLEARANCE 1 EA NS

36593 LIGHT,MARKER,CLEARANCE 1 EA NS

Subscribe to View Vendor Details...

MS35423-1 LIGHT,MARKER,CLEARANCE 1 EA NS

0624A0406 LIGHT,MARKER,CLEARANCE 1 EA NS

Subscribe to View Vendor Details...

MS-35423-1 LIGHT,MARKER,CLEARANCE 5 EA NS

MIL-L-3976 LIGHT,MARKER,CLEARANCE 8 EA NS

25774 LIGHT,MARKER,CLEARANCE 4 EA NS

Subscribe to View Vendor Details...

MS35423-1 LIGHT,MARKER,CLEARANCE RQST NS

Subscribe to View Vendor Details...

6220-00-577-3434 LIGHT,MARKER,AMBER 831 EA NS

Subscribe to View Vendor Details...

MS35423-1 LIGHT,MARKER,CLEARANCE 1 EA NS

Subscribe to View Vendor Details...

1549159 LIGHT,MARKER,CLEARANCE 839 EA NS

005773434.6220 LIGHT,MARKER,CLEARANCE 185 EA NS

6220-00-577-3434 RQST NE

Updated Every Day

6220-00-577-3434 RQST

Updated Every Day

6220-00-577-3434 RQST NE

Restrictions 6220-00-577-3434

6220-00-577-3434 is a Clearance Marker Light that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 6220-00-577-3434

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 6220-00-577-3434

US Army (A920)
Effective Date:: 1 Sep 2006
Former MOE Rule:: A186
Supplementary Receivers:: AJCTCLBFBDAZ; AMC 1 AMSC G IMC Z IMCACTY CD

US Air Force (FXGI)
Effective Date:: 1 Sep 2006
Former MOE Rule:: FXKZ; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC47)
Effective Date:: 1 Sep 2006
Former MOE Rule:: MC10; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BZ)
Effective Date:: 1 Sep 2006
Former MOE Rule:: N9ZD
Supplementary Collaborators:: GTKEHD; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Poland (WP01)
Effective Date:: 1 Apr 2006

Spain (YB01)
Effective Date:: 1 Apr 1991

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Feb 2015

Morocco (YP01)
Effective Date:: 1 Nov 2008

Australia (ZA01)
Effective Date:: 1 Sep 2012

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Jan 1995

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 2005

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Apr 1991

Approved Sources 6220-00-577-3434

Part Number
Manufacturer
Status
12338610-1: 19207 - U S Army Tank Automotive Command (Active); Primary Buy; RNCC 3 RNVC 2 DAC A
MIL-DTL-3976E: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
MS35423-1: 96906 - Military Standards (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC E
1309590: 75Q65 - Oshkosh Defense Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
483036: 02280 - American Hoist And Derrick Co (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
5590273: 34623 - Am General Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
29A32-71: 60528 - Trailmobile Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
MILL3976: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
11M56: 05643 - Barber-Greene Co (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
2231-12-7: 34640 - La Crosse Trailer Corp (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
7261919: 99832 - Scott Huber Essick A Co Of Figgie (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
0624A0406: 55207 - Arrow-Master, Incorporated (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
6220005773434: SCY13 - E.C.A Etablissement (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 9
BG26988: 18990 - Eagle Crusher Co Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
25774: 12472 - Lockwood Corp (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
4391: 23834 - Elliott Machine Works Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
483036: 49185 - Terex American Crane Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
9000-822: 31245 - Terex Usa, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 2
4551-01: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
36593: 51387 - Victor Fluid Power Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
36593: 62410 - Hampton Hydraulics, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
7261919: 19207 - U S Army Tank Automotive Command (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
1069-8-136: 23834 - Elliott Machine Works Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
11420F: 45152 - Oshkosh Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
747966-4: 49671 - Lockheed Martin Corporation (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
4551-01: 73331 - General Motors Corp Fisher Guide Div (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
7261919: 73331 - General Motors Corp Fisher Guide Div (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
1309590: 45152 - Oshkosh Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
928570: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
928570: 73331 - General Motors Corp Fisher Guide Div (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
6220PL0651531: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
11M56: 0MKW7 - Minnpar, Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 5

Datasheet 6220-00-577-3434

Characteristic
Specifications
FIIG: A06300
End Item Identification [AGAV]: Airborne Mobile Dir Air Spt Ctl (21D), (02M Jul83) (An/Uyq-3A); Aircraft, T-39; Shop Equipment, Organizational Repair Light, Truck-Mounted; Trailer, Semi (M172a1); Truck, Fire/Crash P2; Shop Equipment, General Purpose Repair, Trlr, Semi-Mounted; Trailer, Semi (M870); Trailer, Semi (M860a1); Trailer, Semi (M986) & Chassis, Trailer, Semi (M999);2320-01-097-0260 Hiab Crane (Hemt);Hemtt Family (Heavy Expanded Mobility Tactical Trucks);Rg-33 Mrap
Hazardous Locations/Environmental Protection [ABFE]: Watertight
Material [MATT]: Steel Body
Mounting Method [AXGY]: Unthreaded Hole
Lamp Type Accommodated And Quantity [CRHX]: 1 Incandescent
Lamp Base Type Accommodated [AEUJ]: Single Contact Bayonet Candelabra
Lens Color [AEXD]: Amber
Lens Surface Condition [CTXJ]: Smooth Back
Lens Surface Condition [CTXJ]: Smooth Face
Lens Transparency [AEXK]: Transparent
Lens Type And Quantity [CRLP]: 1 Dome, Half, Flanged
Overall Height [ABKW]: 3.312 Inches Nominal
Overall Length [ABHP]: 5.125 Inches Nominal
Overall Width [ABMK]: 2.437 Inches Nominal
Voltage Rating In Volts [ASXH]: 24.0 Dc Nominal
Wiring Provision Length [AHHZ]: 6.0 Inches Nominal Single Provision
Wiring Provision Method [AEYB]: Individual Wire
Terminal Type And Quantity [TTQY]: 1 Wire Lead

Weapon Systems (WSDC) 6220-00-577-3434

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 6220-00-577-3434

Last Stock Position:: 350 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 6220-00-577-3434

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Nov 2019: Department of the Army (DA); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Air Force (DF): F; 9; When Exhausted Use Nsn And Nsn 6220-00-299-7425
Department of the Air Force (DF): F; 9; When Exhausted Use Nsn And Nsn 6220-00-729-9295
Department of the Air Force (DF): F; 9; When Exhausted Use Nsn And Nsn 6240-00-019-0877
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 6220-00-299-5841
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 6220-00-091-9286
US Marine Corps (DM): M; 4; Reversal Of Phrase Code A 6220-00-726-1919

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SX: SICA RESIDUAL MMAC-OC-ALC

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

K: Reserved

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 6220-00-577-3434

6220-12-348-2906 6220-12-337-1160 6220-33-106-7506 6220-21-910-4924 6220-66-043-0013 6220-66-125-4406 6220-99-500-8997 6220-21-885-7927 6220-14-354-8030 6220-14-560-6223 6220-34-031-2734 6220-16-003-3184 6220-14-368-9684 6220-99-660-9903 6220-12-383-0013 6220-01-513-7186 6220-01-513-7192 6220-01-513-7242

Freight Information 6220-00-577-3434

6220-00-577-3434 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 017870. A Sub NMFC of Z. It has a NMFC Description of AUTO ASSEMBLIES/DEVICE LIGHT. 6220-00-577-3434 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 08820 which rates the freight between FCL and LCL. 6220-00-577-3434 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 585 for ocean manifesting and military sealift. 6220-00-577-3434 is not classified as a special type of cargo when transported by water. 6220-00-577-3434 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 6220-00-577-3434

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Electrical Instrument; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning; --; MIL-DTL-117, Type III, Class B, Style 2, Heavy Duty, Waterproof, Transparent Bag; Fragile

Intermediate Pack Level

Quantity of Unit Packs
Container: ASTM - D5118, Fiberboard Box

Procurement History 6220-00-577-3434 32 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE4A423F0527: 22 Sep 2023; Subscribe; 1014; Subscribe; Subscribe
SPE4A423F0527: 22 Sep 2023; Subscribe; 1014; Subscribe; Subscribe
SPE4A723F094H: 07 Sep 2023; Subscribe; 1485; Subscribe; Subscribe
SPE4A723F094H: 07 Sep 2023; Subscribe; 1485; Subscribe; Subscribe
SPE4A423F0200: 01 Feb 2023; Subscribe; 990; Subscribe; Subscribe
SPE4A423F0200P00001: 01 Feb 2023; Subscribe; 990; Subscribe; Subscribe
SPE4A423F0200P00001: 01 Feb 2023; Subscribe; 990; Subscribe; Subscribe
SPE4A422F0054: 15 May 2022; Subscribe; 1328; Subscribe; Subscribe
SPE4A422F0054: 15 May 2022; Subscribe; 1328; Subscribe; Subscribe
SPE4A622F8382: 23 Feb 2022; Subscribe; 1166; Subscribe; Subscribe
SPE4A622F8382: 23 Feb 2022; Subscribe; 1166; Subscribe; Subscribe
SPE4A621F517U: 24 Sep 2021; Subscribe; 1188; Subscribe; Subscribe
SPE4A621F517U: 24 Sep 2021; Subscribe; 1188; Subscribe; Subscribe
SPE4A621F497SP00001: 22 Sep 2021; Subscribe; 1188; Subscribe; Subscribe
SPE4A621F497SP00001: 22 Sep 2021; Subscribe; 1188; Subscribe; Subscribe
SPE4A621F069S: 16 Apr 2021; Subscribe; 1401; Subscribe; Subscribe
SPE4A621F069S: 16 Apr 2021; Subscribe; 1401; Subscribe; Subscribe
SPE4A619F7553: 21 Dec 2018; Subscribe; 881; Subscribe; Subscribe
SPE4A619F3136: 08 Nov 2018; Subscribe; 881; Subscribe; Subscribe
SPE4A618F0749: 10 Oct 2017; Subscribe; 1592; Subscribe; Subscribe
SPE4A615D01050009: 29 Aug 2017; Subscribe; 881; Subscribe; Subscribe
SPE4A615D01050008: 08 Aug 2017; Subscribe; 1315; Subscribe; Subscribe
SPE4A615D01050007: 10 May 2017; Subscribe; 1399; Subscribe; Subscribe
SPE4A615D01050006: 12 Dec 2016; Subscribe; 1252; Subscribe; Subscribe
SPE4A615D01050005: 08 Nov 2016; Subscribe; 1636; Subscribe; Subscribe
SPE4A615D01050004: 12 Feb 2016; Subscribe; 1761; Subscribe; Subscribe
SPE4A615D01050003: 07 Dec 2015; Subscribe; 1186; Subscribe; Subscribe
SPE4A615D01050002: 18 Sep 2015; Subscribe; 1590; Subscribe; Subscribe
SPE4A615D01050001: 09 Mar 2015; Subscribe; 881; Subscribe; Subscribe
SPE4A414V0400: 04 Oct 2013; Subscribe; 1779; Subscribe; Subscribe
SPE4A613VC480: 09 May 2013; Subscribe; 2037; Subscribe; Subscribe
SPE4A613MB308P00002: 11 Mar 2013; Subscribe; 1932; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 6220-00-577-3434 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: Y
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 6220-00-577-3434

Related Documents 6220-00-577-3434 5+ Documents (More...)

Restrictions 6220-00-577-3434

Import and Export 6220-00-577-3434

End Users 6220-00-577-3434

Approved Sources 6220-00-577-3434

Datasheet 6220-00-577-3434

Weapon Systems (WSDC) 6220-00-577-3434

DLA Procurement Analysis 6220-00-577-3434

Management Data 6220-00-577-3434

Army

Air Force

Navy

Marine Corps

NATO Stock Numbers Related to 6220-00-577-3434

Freight Information 6220-00-577-3434

Packaging Data 6220-00-577-3434

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 6220-00-577-3434 32 Records

Contracting Technical Data File (CTDF) 6220-00-577-3434 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
