6210-01-148-4617
Indicator Light
6210011484617 011484617 10HA2C5J3L(A)N1R1
A light, with mounting facilities furnished, designed to convey information of a specific nature concerning the circuit in which inserted. Must include or provide for the use of a lens as a part of it. For items without a lens, see LAMPHOLDER, and also see LIGHT (1), PANEL. View more Indicator Light
May 2023
4
Marketplace 6210-01-148-4617
Request a Quotation from participating marketplace vendors
Related Documents 6210-01-148-4617 5+ Documents (More...)
BUY NE FedMall Updated Every Day 6210-01-148-4617 RQST NE Updated Every Day 6210-01-148-4617 RQST
Updated Every Day 6210-01-148-4617 RQST NE Related Documents 6210-01-148-4617 1+ Documents ( More...
Restrictions 6210-01-148-4617
6210-01-148-4617 is a Indicator Light that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6210-01-148-4617
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6210-01-148-4617
- US Navy (N9BZ)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- N9ZD
- Supplementary Collaborators:
- HD
Approved Sources 6210-01-148-4617
- Part Number
- Manufacturer
- Status
- 10HA2C5J3L(A)N1R1
- Manufacturer
- 96182 - Safran Electronics & Defense (Active)
- Primary Buy
- Primary Buy
Datasheet 6210-01-148-4617
- Characteristic
- Specifications
- FIIG
- Specifications
- A065A0
- Filter Color [AETM]
- Amber Single Light 1St Position Horizontal Full Display Division A
- Filter Quantity [AEYC]
- 4
- Material [MATT]
- Steel Corrosion Resisting Body
- Mounting Method [AXGY]
- Panel
- Multilamp Circuit Type [AEZS]
- Four Lamp Common
- Lamp Base Type Accommodated [AEUJ]
- Midget Flanged
- Lamp Bulb Size Designator [AEWU]
- T-1 3/4
- Lamp Industry Number [AFAX]
- 327
- Lamp Type Accommodated And Quantity [CRHX]
- 4 Incandescent
- Lens Back Surface Condition [CTRM]
- Smooth Single Light 1St Position Horizontal
- Lens Color [AEXD]
- Colorless Single Light 1St Position Horizontal
- Lens Face Surface Condition [CWJJ]
- Smooth Single Light 1St Position Horizontal
- Lens Light Transmission Characteristic [CSKH]
- Transparent Single Light 1St Position Horizontal
- Lens Mounting Method [ATAS]
- Flange
- Lens Quantity [AEXC]
- 1
- Lens Type [CRQG]
- Display Screen Single Light 1St Position Horizontal
- Overall Height [ABKW]
- 0.950 Inches Minimum And 0.970 Inches Maximum
- Overall Length [ABHP]
- 1.812 Inches Maximum
- Overall Width [ABMK]
- 1.190 Inches Minimum And 1.210 Inches Maximum
- Panel Accommodation Hole Height [CRXT]
- 0.870 Inches Nominal
- Panel Accommodation Hole Width [CQQK]
- 1.110 Inches Nominal
- Panel Thickness For Which Designed [BZWG]
- 0.031 Inches Minimum And 0.250 Inches Maximum
- Transmitted Light Color [CTDS]
- Amber Single Light 1St Position Horizontal Full Display Division A
- Style Designator [STYL]
- Rectangular Frame Type
- Terminal Type And Quantity [TTQY]
- 2 Solder Lug
DLA Procurement Analysis 6210-01-148-4617
Management Data 6210-01-148-4617
Navy
- Cognizance:
- 3B
Similar Supply Items to 6210-01-148-4617
Freight Information 6210-01-148-4617
6210-01-148-4617 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 109700. A Sub NMFC of Z. It has a NMFC Description of LAMP OR LIGHTING FIXTURES. 6210-01-148-4617 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55690 which rates the freight between FCL and LCL. 6210-01-148-4617 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 761 for ocean manifesting and military sealift. 6210-01-148-4617 is not classified as a special type of cargo when transported by water. 6210-01-148-4617 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
