6210-01-124-5276
Indicator Light
6210011245276 011245276 10648EL11-5
A light, with mounting facilities furnished, designed to convey information of a specific nature concerning the circuit in which inserted. Must include or provide for the use of a lens as a part of it. For items without a lens, see LAMPHOLDER, and also see LIGHT (1), PANEL. View more Indicator Light
May 2023
3
Marketplace 6210-01-124-5276
Request a Quotation from participating marketplace vendors
Related Documents 6210-01-124-5276 5+ Documents (More...)
Updated Every Day 6210-01-124-5276 RQST NE Updated Every Day 6210-01-124-5276 RQST Updated Every Day
/fsg-62/fsc-6210/us 6210-01-124-5276 Indicator Light 6210011245276011245276 Photo 1/3 6210-01-124-5276
Indicator Light 6210011245276 011245276 for $1 a day Upgrade your Account Upgrade 6210-01-124-5276Indicator
Light6210011245276 011245276 10648EL11 Request a Quotation from participating marketplace vendors Request
Restrictions 6210-01-124-5276
6210-01-124-5276 is a Indicator Light that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6210-01-124-5276
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6210-01-124-5276
- National Security Agency (DGX1)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- DKZ1
- Supplementary Receivers:
- CXKZ
Approved Sources 6210-01-124-5276
- Part Number
- Manufacturer
- Status
- 10648EL11-5
- Manufacturer
- 08719 - Ducommun Labarge Technologies, Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 6210-01-124-5276
- Characteristic
- Specifications
- FIIG
- Specifications
- A065A0
- Furnished Items And Quantity [TMQY]
- 1 Mounting Sleeve
- Filter Color [AETM]
- Red Single Light 1St Position Horizontal Full Display Division A
- Filter Quantity [AEYC]
- 1
- Hazardous Locations/Environmental Protection [ABFE]
- Electromagnetic Radiation Suppressive
- Material [MATT]
- Steel Corrosion Resisting Body
- Mounting Method [AXGY]
- Panel
- Multilamp Circuit Type [AEZS]
- Four Lamp Common
- Lamp Base Type Accommodated [AEUJ]
- Midget Flanged
- Lamp Bulb Size Designator [AEWU]
- T-1 3/4
- Lamp Type Accommodated And Quantity [CRHX]
- 4 Incandescent
- Lens Back Surface Condition [CTRM]
- Smooth Single Light 1St Position Horizontal
- Lens Color [AEXD]
- White Single Light 1St Position Horizontal
- Lens Face Surface Condition [CWJJ]
- Smooth Single Light 1St Position Horizontal
- Lens Legend [CTCB]
- Hot Single Light 1St Position Horizontal Full Display Division A
- Lens Light Transmission Characteristic [CSKH]
- Translucent Single Light 1St Position Horizontal
- Lens Mounting Method [ATAS]
- Push In
- Lens Quantity [AEXC]
- 1
- Lens Type [CRQG]
- Flat, Rectangular Single Light 1St Position Horizontal
- Overall Height [ABKW]
- 0.750 Inches Nominal
- Overall Length [ABHP]
- 2.436 Inches Maximum
- Overall Width [ABMK]
- 0.750 Inches Nominal
- Panel Accommodation Hole Height [CRXT]
- 0.680 Inches Minimum And 0.690 Inches Maximum
- Panel Accommodation Hole Width [CQQK]
- 0.680 Inches Minimum And 0.690 Inches Maximum
- Panel Thickness For Which Designed [BZWG]
- 0.194 Inches Nominal
- Transmitted Legend Color [CSTC]
- Black Single Light 1St Position Horizontal Full Display Division A
- Transmitted Light Color [CTDS]
- Red Single Light 1St Position Horizontal Full Display Division A
- Style Designator [STYL]
- Rectangular Frame Type
- Terminal Type And Quantity [TTQY]
- 5 Solder Stud
DLA Procurement Analysis 6210-01-124-5276
Management Data 6210-01-124-5276
Similar Supply Items to 6210-01-124-5276
Freight Information 6210-01-124-5276
6210-01-124-5276 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 109700. A Sub NMFC of Z. It has a NMFC Description of LAMP OR LIGHTING FIXTURES. 6210-01-124-5276 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55690 which rates the freight between FCL and LCL. 6210-01-124-5276 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 761 for ocean manifesting and military sealift. 6210-01-124-5276 is not classified as a special type of cargo when transported by water. 6210-01-124-5276 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6210-01-124-5276
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- No Requirement
- Not Applicable
- --
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
