6210-00-299-4068
Panel Light
6210002994068 002994068 262-0237-00 262-0237-000
A light specifically designed to be mounted on, near, or through a panel, switchboard, bulletin board, cowl, dashboard, and the like, and specifically designed to provide direct or indirect illumination thereon. It must include a shade, reflector, or other special device to direct illumination or to provide for the direction of illumination through the inherent design of the item, as in lights for edge lighted panels. It may include filters, dimming features, switches, and/or flexible gooseneck. For aircraft installed items prviding illumination for map reading or general utility illumination, in addition to panel illumination, see LIGHT (1), COCKPIT, AIRCRAFT. For items conforming to this basic definition with the additional feature of providing illuminated indication of a specific nature concerning the circuit in which it is inserted, see LIGHT (1), INDICATOR. View more Panel Light
May 2023
18
Marketplace 6210-00-299-4068
Request a Quotation from participating marketplace vendors
Related Documents 6210-00-299-4068 1+ Documents (More...)
Photo 1/2 NSN 6210-00-299-4068 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 6210-00-299-4068 RQST Updated Every Day 6210-00-299-4068 RQST NE Related Documents
Restrictions 6210-00-299-4068
6210-00-299-4068 is a Panel Light that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6210-00-299-4068
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6210-00-299-4068
- Brazil (YA01)
- Effective Date:
- 1 Jan 2002
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 6210-00-299-4068
- Part Number
- Manufacturer
- Status
- 262-0237-00
- Manufacturer
- 13499 - Rockwell Collins, Inc. (Active)
- Primary Buy
- Primary Buy
- 262-0237-000
- 13499 - Rockwell Collins, Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 6210-00-299-4068
- Characteristic
- Specifications
- FIIG
- Specifications
- A065A0
- Style Designator [STYL]
- Trap Type
- Overall Length [ABHP]
- 1.188 Inches Nominal
- Overall Diameter [ADAV]
- 0.562 Inches Nominal
- Material [MATT]
- Copper Alloy Body
- Material [MATT]
- Copper Alloy Illumination Directing Device
- Surface Treatment [SFTT]
- Cadmium Body
- Surface Treatment [SFTT]
- Cadmium Illumination Directing Device
- Lamp Type Accommodated And Quantity [CRHX]
- 1 Incandescent
- Lamp Bulb Size Designator [AEWU]
- T-1 3/4
- Lamp Base Type Accommodated [AEUJ]
- Midget Flanged
- Mounting Method [AXGY]
- Panel
- Panel Accommodation Hole Diameter [AEXZ]
- 0.469 Inches Nominal
- Panel Thickness For Which Designed [BZWG]
- 0.125 Inches Maximum
- Terminal Type And Quantity [TTQY]
- 1 Wire Lead
Similar Supply Items to 6210-00-299-4068
Freight Information 6210-00-299-4068
6210-00-299-4068 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 109700. A Sub NMFC of Z. It has a NMFC Description of LAMP OR LIGHTING FIXTURES. 6210-00-299-4068 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55690 which rates the freight between FCL and LCL. 6210-00-299-4068 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 6210-00-299-4068 is not classified as a special type of cargo when transported by water. 6210-00-299-4068 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
