6210-00-269-3799
Indicator Light
6210002693799 002693799 3B90081-153 351-10423-015 6002-100-15 351-10423-15
A light, with mounting facilities furnished, designed to convey information of a specific nature concerning the circuit in which inserted. Must include or provide for the use of a lens as a part of it. For items without a lens, see LAMPHOLDER, and also see LIGHT (1), PANEL. View more Indicator Light
May 2023
6
Marketplace 6210-00-269-3799
Request a Quotation from participating marketplace vendors
Related Documents 6210-00-269-3799 5+ Documents (More...)
Photo 1/2 NSN 6210-00-269-3799 (Identification) 2/2 - - 1.
BUY NE FedMall Updated Every Day 6210-00-269-3799 RQST NE Updated Every Day 6210-00-269-3799 RQST
Indicator Light 6210002693799 002693799 Upgrade your Account Upgrade 6210-00-269-3799Indicator
Light6210002693799 002693799 3B90081-153 351-10423-015 RQST NE Updated Every Day 6210-00-269-3799 RQST
Indicator Light 6210002693799 002693799 www.nsnlookup.com /fsg-62/fsc-6210/us 6210-00-269-3799
Restrictions 6210-00-269-3799
6210-00-269-3799 is a Indicator Light that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6210-00-269-3799
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6210-00-269-3799
- US Air Force (FXGI)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- FXKZ
Approved Sources 6210-00-269-3799
- Part Number
- Manufacturer
- Status
- 3B90081-153
- Manufacturer
- 98897 - Lockheed Martin Corp (Active)
- Primary Buy
- Primary Buy
- 351-10423-015
- 96182 - Safran Electronics & Defense (Active)
- Secondary Buy
- Secondary Buy
- 6002-100-15
- 96182 - Safran Electronics & Defense (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 351-10423-15
- 96182 - Safran Electronics & Defense (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6210-00-269-3799
- Characteristic
- Specifications
- FIIG
- Specifications
- A065A0
- Style Designator [STYL]
- Rectangular Frame Type
- Overall Length [ABHP]
- 2.656 Inches Nominal
- Overall Height [ABKW]
- 0.688 Inches Maximum
- Overall Width [ABMK]
- 2.250 Inches Nominal
- Lamp Type Accommodated And Quantity [CRHX]
- 2 Incandescent
- Lamp Bulb Size Designator [AEWU]
- T-1 3/4
- Lamp Base Type Accommodated [AEUJ]
- Midget Flanged
- Lens Quantity [AEXC]
- 1
- Lens Mounting Method [ATAS]
- Flange
- Lens Type [CRQG]
- Display Screen Single Light 1St Position Horizontal
- Lens Light Transmission Characteristic [CSKH]
- Translucent Single Light 1St Position Horizontal
- Lens Face Surface Condition [CWJJ]
- Smooth Single Light 1St Position Horizontal
- Lens Back Surface Condition [CTRM]
- Smooth Single Light 1St Position Horizontal
- Lens Color [AEXD]
- Gray Single Light 1St Position Horizontal
- Filter Quantity [AEYC]
- 1
- Filter Color [AETM]
- Amber Single Light 1St Position Horizontal Full Display Division A
- Transmitted Light Color [CTDS]
- Gray Single Light 1St Position Horizontal Full Display Division A
- Lens Legend [CTCB]
- Gen Out Single Light 1St Position Horizontal Full Display Division A
- Transmitted Legend Color [CSTC]
- Amber Single Light 1St Position Horizontal Full Display Division A
- Mounting Method [AXGY]
- Bracket
- Terminal Type And Quantity [TTQY]
- 6 Solder Lug
- Multilamp Circuit Type [AEZS]
- Two Lamp Common
DLA Procurement Analysis 6210-00-269-3799
Management Data 6210-00-269-3799
Similar Supply Items to 6210-00-269-3799
Freight Information 6210-00-269-3799
6210-00-269-3799 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 109700. A Sub NMFC of Z. It has a NMFC Description of LAMP OR LIGHTING FIXTURES. 6210-00-269-3799 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55690 which rates the freight between FCL and LCL. 6210-00-269-3799 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 761 for ocean manifesting and military sealift. 6210-00-269-3799 is not classified as a special type of cargo when transported by water. 6210-00-269-3799 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6210-00-269-3799
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 6210-00-269-3799 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
