6210-00-118-2749
Indicator Light Assembly
6210001182749 001182749 351-10182-006 4131-100-6 GL806AV5
An item designed to convey information of a specific nature concerning the circuit in which inserted. Consists of two or more LIGHT, INDICATOR. View more Indicator Light Assembly
May 2023
5
Marketplace 6210-00-118-2749
Request a Quotation from participating marketplace vendors
Related Documents 6210-00-118-2749 1+ Documents (More...)
/fsg-62/fsc-6210/us
BUY NE FedMall Updated Every Day 6210-00-118-2749 RQST NE Updated Every Day 6210-00-118-2749 RQST Updated
Every Day 6210-00-118-2749 RQST NE Related Documents 6210-00-118-2749 1+ Documents ( More... ) https
Restrictions 6210-00-118-2749
6210-00-118-2749 is a Indicator Light Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6210-00-118-2749
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6210-00-118-2749
- National Security Agency (DGX1)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- DKZ1
- Supplementary Receivers:
- CXKZ
Approved Sources 6210-00-118-2749
- Part Number
- Manufacturer
- Status
- 351-10182-006
- Manufacturer
- 96182 - Safran Electronics & Defense (Active)
- Primary Buy
- Primary Buy
- 4131-100-6
- 96182 - Safran Electronics & Defense (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GL806AV5
- 26512 - Northrop Grumman Systems Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6210-00-118-2749
- Characteristic
- Specifications
- FIIG
- Specifications
- A065A0
- Material [MATT]
- Aluminum Alloy Body
- Mounting Method [AXGY]
- Bracket
- Style Designator [STYL]
- Single Strip Type
- Lamp Base Type Accommodated [AEUJ]
- Midget Flanged
- Lamp Bulb Size Designator [AEWU]
- T-1 3/4
- Lamp Industry Number [AFAX]
- 327
- Lamp Type Accommodated And Quantity [CRHX]
- 4 Incandescent
- Lens Back Surface Condition [CTRM]
- Smooth Single Row 1St Position Vertical
- Lens Back Surface Condition [CTRM]
- Smooth Single Row 2Nd Position Vertical
- Lens Color [AEXD]
- Amber Single Row 1St Position Vertical
- Lens Color [AEXD]
- Amber Single Row 2Nd Position Vertical
- Lens Legend [CTCB]
- S/S-C Single Row 1St Position Vertical Full Display Division A
- Lens Legend [CTCB]
- No Go/Stby Single Row 2Nd Position Vertical Full Display Division A
- Lens Light Transmission Characteristic [CSKH]
- Translucent Single Row 1St Position Vertical
- Lens Light Transmission Characteristic [CSKH]
- Translucent Single Row 2Nd Position Vertical
- Lens Mounting Method [ATAS]
- Push In
- Lens Quantity [AEXC]
- 2
- Lens Type [CRQG]
- Flat, Rectangular Single Row 1St Position Vertical
- Lens Type [CRQG]
- Flat, Rectangular Single Row 2Nd Position Vertical
- Overall Height [ABKW]
- 0.722 Inches Nominal
- Overall Length [ABHP]
- 1.906 Inches Nominal
- Overall Width [ABMK]
- 1.000 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 6 Screw
- Transmitted Legend Color [CSTC]
- Amber Single Row 2Nd Position Vertical Full Display Division A
- Transmitted Legend Color [CSTC]
- Amber Single Row 1St Position Vertical Full Display Division A
- Transmitted Light Color [CTDS]
- Black Single Row 1St Position Vertical Full Display Division A
- Transmitted Light Color [CTDS]
- Black Single Row 2Nd Position Vertical Full Display Division A
DLA Procurement Analysis 6210-00-118-2749
Management Data 6210-00-118-2749
Similar Supply Items to 6210-00-118-2749
Freight Information 6210-00-118-2749
6210-00-118-2749 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 109700. A Sub NMFC of Z. It has a NMFC Description of LAMP OR LIGHTING FIXTURES. 6210-00-118-2749 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 55690 which rates the freight between FCL and LCL. 6210-00-118-2749 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 761 for ocean manifesting and military sealift. 6210-00-118-2749 is not classified as a special type of cargo when transported by water. 6210-00-118-2749 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 6210-00-118-2749 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
