6150-01-319-4794
Branched Wiring Harness
6150013194794 013194794 12358894
An item conforming to the definition of WIRING HARNESS with branches (forks). See also CABLE ASSEMBLY, SPECIAL PURPOSE, ELECTRICAL, BRANCHED, Excludes LEAD ASSEMBLY, ELECTRICAL; and LEAD, TEST. View more Branched Wiring Harness
March 2025
7
Marketplace 6150-01-319-4794
Request a Quotation from participating marketplace vendors
Related Documents 6150-01-319-4794 3+ Documents (More...)
RQST NE Updated Every Day 6150-01-319-4794 RQST Updated Every Day 6150-01-319-4794 RQST NE Related
Documents 6150-01-319-4794 4+ Documents ( More... ) https//www.nsnlookup.com /fsg-61/fsc-6150/us 6150
Restrictions 6150-01-319-4794
6150-01-319-4794 is a Branched Wiring Harness that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6150-01-319-4794
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6150-01-319-4794
- US Army (A920)
- Effective Date:
- 1 May 2006
- Former MOE Rule:
- A183
- Supplementary Receivers:
- AZ
- United Kingdom (ZK01)
- Effective Date:
- 1 May 2011
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Mar 2004
Approved Sources 6150-01-319-4794
- Part Number
- Manufacturer
- Status
- 12358894
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 6150-01-319-4794
- Characteristic
- Specifications
- FIIG
- Specifications
- A077A0
- Special Features [FEAT]
- C/O Connector,Pn Ms3454w24-11S; Adapter,Pn 12293185-9;Boot,Pn 12293286-11;Connector,Cagec 80064,Pn 2590040-2;Boot,Pn 12295791-25;2 Terminals,Pn Ms26059-129;4 Terminals,Pn 12369825; Insulation Sleecing,As Required,Pn;S 12295791-28 And 12295791-22;Shim Underboot,Pn 12295791-23;2 Splice,Pn M81824/1-3;Wire As Required,See Dwg 12358894;Item Is 58.000 In O/A Lg,Connector End To Branches
- End Item Identification [AGAV]
- 2350-01-248-7619
Weapon Systems (WSDC) 6150-01-319-4794
DLA Procurement Analysis 6150-01-319-4794
- Last Stock Position:
- 26 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 6150-01-319-4794
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- MM
- Armored Carriers
Infantry Fighting Vehicle (M2, M2A1, M2A2), Cavalry Fighting Vehicle (M3, M3A1, M3A2)
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 6150-01-319-4794
Freight Information 6150-01-319-4794
6150-01-319-4794 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061130. A Sub NMFC of X. It has a NMFC Description of CABLE ASSEMBLY. 6150-01-319-4794 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34350 which rates the freight between FCL and LCL. 6150-01-319-4794 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 743 for ocean manifesting and military sealift. 6150-01-319-4794 is not classified as a special type of cargo when transported by water. 6150-01-319-4794 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6150-01-319-4794
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 6150-01-319-4794 December 2020
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
