6140-01-677-2619
Storage Battery
6140016772619 016772619 BT-70791JV 117197 10483630
A battery, composed of two or more cells forming a single unit, which may or may not be readily separable and which may be efficiently recharged by sending an electric current through the cells in a direction opposite that of the discharging current.The item may be furnished with integral charging facilities.For items which are composed of a single cell see CELL, BATTERY. View more Storage Battery
February 2025
16
Product Information 6140-01-677-2619
BB-2590/U, 298 Wh Battery
Chemistry: Li-ion
10.3 Ah, Rechargeable Lithium-Ion Battery
Designed for high capacity and an increased temperature range. Typically used in over 71 different devices such as Communications gear (SINCGARS, AN/PRC-117, etc.), Robots, and Jammers.
- Complies with SMBus v1.1 and SBData v1.1
- UN/DOT 38.3 Rating: 298 Wh
- Comparable to: BB-2590A/U, BT-70701Bx, BT-70791Cx and BT-70791Jx
- Designed, manufactured, and tested to MIL-PRF-32052/1
- CB Test Certificate for compliance with battery safety standard IEC 62133
- CE Compliant
Typically used in:
- Robots
- Surveillance / Sensors
- SINCGARS & ASIP (AN/PRC-119) Radios
- FALCON (AN/PRC-150, 117) Radios
Length 4.369" / Width 2.4" / Height 4.969"
| Nominal Voltage | 14.4V, 28.8V |
|---|---|
| Ah | In 24V Mode: 10.3 Ah, In 12V Mode: 20.6 |
| Maximum Voltage | 16.8V |
| Operating Temperature | -32°C to +60°C (-25.6°F to +140°F) |
| Storage Temperature | -40°C to +40°C (-40°F to +104°F) |
| Connector | Floating type per U.S. Army DWG # SC-C-179495 |
| State of Charge Indicator | Yes |
| US Gov Spec | MIL-PRF-32052/1 |
| Battery Type | Rechargeable |
| Smart Battery | SMBus |
| Brenergy | No |
Marketplace 6140-01-677-2619
Request a Quotation from participating marketplace vendors
Related Documents 6140-01-677-2619 5+ Documents (More...)
United States (US) 4. 6140-01-677-2619 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 6140-01-677-2619 RQST Updated Every Day 6140-01-677-2619 RQST NE Related Documents
//www.nsnlookup.com /fsg-51/fsc-5140/dk 5140-22-606-5461 Portable Tool Box 5140226065461226065461 117197
//www.nsnlookup.com /fsg-51/fsc-5140/dk 5140-22-606-5461 Portable Tool Box 5140226065461226065461 117197
Storage Battery 6140016772619 016772619 day Upgrade your Account Upgrade 6140-01-677-2619Storage
Battery6140016772619 016772619 BT-70791JV 117197 enable JavaScript in your web browser . 5140-22-606
$1 a day Upgrade your Account Upgrade 6605-01-219-1783Collecto Insulation6605012191783 012191783 117197
enable JavaScript in your web browser . 5140-22-606-5461Portable Tool Box5140226065461 226065461 117197
www.nsnlookup.com /fsg-61/fsc-6140 Batteries, Rechargeable from United States (US) : E 10 Dec 2014 6140-01-677-2619
Restrictions 6140-01-677-2619
6140-01-677-2619 is a Storage Battery that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 6140-01-677-2619
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
Approved Sources 6140-01-677-2619
- Part Number
- Manufacturer
- Status
- BT-70791JV
- Manufacturer
- 51828 - Bren-Tronics Defense Llc (Active)
- Primary Buy
- Primary Buy
- 117197
- F2980 - Aglo Developpement (Active)
- Secondary Buy
- Secondary Buy
- 117197
- P4596 - Belimex, Unipessoal, Lda (Active)
- Secondary Buy
- Secondary Buy
- 10483630
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
Management Data 6140-01-677-2619
Army
- Materiel Category and Inventory Manager:
- G
- Communications and Electronics Equipment, Electronics Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 54
- Communications Systems Equipment
SATCOM On the Move (SOTM)
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 6140-01-677-2619
