6140-01-673-9017
Storage Battery
6140016739017 016739017 BT-70915-1/3AV 65115201AA
A battery, composed of two or more cells forming a single unit, which may or may not be readily separable and which may be efficiently recharged by sending an electric current through the cells in a direction opposite that of the discharging current.The item may be furnished with integral charging facilities.For items which are composed of a single cell see CELL, BATTERY. View more Storage Battery
February 2025
1
Product Information 6140-01-673-9017
CES 1/3, 3.4 Ah Battery
Chemistry: Li-ion
3.4 Ah, Rechargeable Lithium-Ion Battery
Typically used to power portable optical devices.
- Complies with SMBus v1.1 and SBData v1.1
- Comparable to: BT-70915Ax, BT-70915-1/3Ax and BT-70915-2/3Ax
- Enhanced cold temperature performance
- Absolute state of charge indicator
- Tested and certified to meet requirements of battery safety standard IEC 62133
- CE Compliant
Length 1.748" / Width 1.748" / Height 3.45" / Weight 0.5 lbs
| Nominal Voltage | 10.8V |
|---|---|
| Ah | 6.4 |
| Maximum Voltage | 12.6V |
| Operating Temperature | -32°C to +60°C (-25.6°F to +140°F) |
| Storage Temperature | -40°C to +55°C (-40°F to +131°F) |
| Connector | BT Designed Mating Connector |
| State of Charge Indicator | Yes |
| Battery Type | Rechargeable |
| Brenergy | No |
Marketplace 6140-01-673-9017
Request a Quotation from participating marketplace vendors
Related Documents 6140-01-673-9017 5+ Documents (More...)
United States (US) 4. 6140-01-673-9017 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 6140-01-673-9017 RQST Updated Every Day 6140-01-673-9017 RQST NE Related Documents
Storage Battery 6140016739017 016739017 JavaScript in your web browser . 6140-01-673-9017Storage
Battery6140016739017 016739017 BT-70915-1/3AV www.nsnlookup.com /fsg-61/fsc-6140/us 6140-01-673-9017
/www.nsnlookup.com /fsg-61/fsc-6140 Batteries, Rechargeable from United States (US) Jan 2016 6140-01-673-9017
Restrictions 6140-01-673-9017
6140-01-673-9017 is a Storage Battery that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilization requirements of this item are currently unknown as insufficent technical data is available. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 6140-01-673-9017
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
Approved Sources 6140-01-673-9017
- Part Number
- Manufacturer
- Status
- BT-70915-1/3AV
- Manufacturer
- 51828 - Bren-Tronics Defense Llc (Active)
- Primary Buy
- Primary Buy
- 65115201AA
- F6170 - Thales Las France Sas (Active)
- Secondary Buy
- Secondary Buy
