6140-01-490-4316

Storage Battery

6140014904316 014904316 MIL-PRF-32052/1 33FBB2590U BT-70791BK 1BT022-1 2011-5315 EL6586-001 8126108 SMU-00000049 117197SMB 60050000085 MGL8701 8001069 BB-2590/U BT-70791CK 20-0288 BT-7091CK 32052/1-BB2590/U MIL-PRF-32052 MIL-PRF-32052/1-BB2590/U BT-70791A BT-70791 BB-2590 1BT0000017 061392

A battery, composed of two or more cells forming a single unit, which may or may not be readily separable and which may be efficiently recharged by sending an electric current through the cells in a direction opposite that of the discharging current.The item may be furnished with integral charging facilities.For items which are composed of a single cell see CELL, BATTERY. View more Storage Battery

Managed by United States

NSN Created on 27 Sep 2001

Data Last Changed
February 2025

NATO Update Count
95

NATO Data Quality

6140-01-490-4316 BATTERY,STORAGE 6140014904316 014904316 1/1 — 6140-01-490-4316 Photo 1/1

Product Information 6140-01-490-4316

BB-2590/U, 251Wh Battery

Military # BB-2590/U
Chemistry: Li-ion

7.5 Ah, Rechargeable Lithium-Ion Battery

Length 4.4" / Width 2.4" / Height 5" / Weight 3.1 lbs

Typically used in over 71 different devices such as Communications gear (SINCGARS, AN/PRC-117, etc.), Robots, and Jammers.

Designed to meet MIL-PRF-32052/1 (note: while meeting this spec MIL-PRF-32052/1 is no longer an active specification for the BB-2590/U which has been replaced by the BB-2590A/U under MIL-PRF 32383/3)

Designed and manufactured in the USA.

Complies with SMBus v1.1 and SBData v1.1
• UN/DOT 38.3 Rating: 225 Wh
• Certified by US Army to MIL-PRF-32052/1
• Comparable to: BB-2590A/U, BT-70701Bx, BT-70791Cx and BT-70791Jx
• Visit: www.bren-tronics.com/patents for patent information
• CE Compliant

Typically used in:
• Robots
• Surveillance / Sensors
• SINCGARS & ASIP (AN/PRC-119) Radios
• FALCON (AN/PRC-150, 117) Radios

Nominal Voltage	14.4V, 28.8V
Ah	In 24V Mode: 7.5 Ah, In 12V Mode: 15
Maximum Voltage	16.8V
Operating Temperature	-20°C to +60°C (-4°F to +140°F)
Storage Temperature	-40°C to +40°C (-40°F to +104°F)
Connector	Floating type per U.S. Army DWG # SC-C-179495
State of Charge Indicator	Yes
US Gov Spec	MIL-PRF-32052/1
Battery Type	Rechargeable
Smart Battery	SMBus
Brenergy	No

Marketplace 6140-01-490-4316

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

BB-2590U BATTERY,STORAGE RQST NS

Updated Every Day

6140-01-490-4316 RQST NE

Updated Every Day

6140-01-490-4316 RQST

Updated Every Day

6140-01-490-4316 RQST NE

Restrictions 6140-01-490-4316

6140-01-490-4316 is a Storage Battery that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.

Import and Export 6140-01-490-4316

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 6140-01-490-4316

US Army (A918)
Effective Date:: 1 Sep 2006
Former MOE Rule:: A178
Supplementary Receivers:: AJCLBF; AMC 1 AMSC G IMC Z IMCACTY CD

US Air Force (FXGG)
Effective Date:: 1 Sep 2006
Former MOE Rule:: FXCX; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC41)
Effective Date:: 1 Sep 2006
Former MOE Rule:: MC04; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BG)
Effective Date:: 1 Sep 2006
Former MOE Rule:: N9GD
Supplementary Collaborators:: GTHD; AMC 1 AMSC G IMC Z IMCACTY GH

Latvia (VD01)
Effective Date:: 1 Jan 2012

Austria (WB01)
Effective Date:: 1 Jun 2011

Estonia (WE01)
Effective Date:: 1 Oct 2010

Finland (WF01)
Effective Date:: 1 Sep 2008

Hungary (WH01)
Effective Date:: 1 May 2008

Lithuania (WI01)
Effective Date:: 1 Mar 2011

Slovenia (WL01)
Effective Date:: 1 Jan 2008

Poland (WP01)
Effective Date:: 1 Jun 2009

Slovakia (WS01)
Effective Date:: 1 Aug 2014

Bulgaria (WU01)
Effective Date:: 1 May 2006

Czech Republic (WZ01)
Effective Date:: 1 Jun 2005

Brazil (YA01)
Effective Date:: 1 Jun 2009

Spain (YB01)
Effective Date:: 1 Mar 2007

Israel (YD01)
Effective Date:: 1 Oct 2016

Singapore (YJ01)
Effective Date:: 1 Aug 2009

Australia (ZA01)
Effective Date:: 1 Jan 2009

Belgium (ZB01)
Effective Date:: 1 Jun 2007

Canada (ZC01)
Effective Date:: 1 Oct 2010

France (ZF01)
Effective Date:: 1 Sep 2003

Germany (ZG01)
Effective Date:: 1 May 2005

Republic of Korea (ZH01)
Effective Date:: 1 Apr 2008

United Kingdom (ZK01)
Effective Date:: 1 Apr 2007

Netherlands (ZN01)
Effective Date:: 1 Feb 2005

Italy (ZR01)
Effective Date:: 1 Jul 2010

Denmark (ZS01)
Effective Date:: 1 Sep 2004

Norway (ZT01)
Effective Date:: 1 Sep 2004

Turkey (ZW01)
Effective Date:: 1 Nov 2009

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Feb 2010

Approved Sources 6140-01-490-4316

Part Number
Manufacturer
Status
BB-2590/U: 81349 - Military Specifications (Active); Definitive Standard; RNCC 2 RNVC 2 DAC E
MIL-PRF-32052/1: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC E
33FBB2590U: U6311 - Trl Technology Limited (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
BT-70791BK: FB2Y7 - Bren-Tronics International Solutions (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
1BT022-1: U3999 - Marlborough Communications Limited (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
2011-5315: U3999 - Marlborough Communications Limited (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 6
EL6586-001: T0587 - Roketsan A.S. (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
8126108: F6235 - Compagnie Industrielle Des Lasers (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 2
SMU-00000049: C3002 - Esg Elektroniksystem- Und (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 3
117197SMB: F2980 - Aglo Developpement (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 3
60050000085: T0507 - Aspilsan Enerji Sanayi Ve Ticaret (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 3
MGL8701: FARF2 - Upergy (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
BT-70791BK: U0SA5 - Bren-Tronics, Inc. (Uk Office) (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
8001069: Z7067 - Epe Oceania Pty Ltd Esps (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 3
117197SMB: P4596 - Belimex, Unipessoal, Lda (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
BB-2590/U: 005VU - Miltech Ltd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
BT-70791CK: 51828 - Bren-Tronics Defense Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
BT-70791CK: D7182 - Fey Elektronik Gmbh (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
BB-2590/U: F0057 - Thales Six Gts France Sas (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
20-0288: C5621 - Elp Gmbh European Logistic Partners (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
BB-2590/U: A8547 - Tecnodife Srl (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
BB-2590/U: 0451H - Wojskowe Zaklady Lacznosci Nr 2 S.A. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
BT-7091CK: 51828 - Bren-Tronics Defense Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
MIL-PRF-32052: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
MIL-PRF-32052/1-BB2590/U: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
BT-70791A: 51872 - Unit Portions Inc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
BT-70791: 51828 - Bren-Tronics Defense Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
BB-2590: 80063 - Us Army Communications & Electronics (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
BT-70791CK: U0SA5 - Bren-Tronics, Inc. (Uk Office) (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
BT-70791A: FB2Y7 - Bren-Tronics International Solutions (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
1BT0000017: 0727A - Netline Communication Technologies (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
061392: 51828 - Bren-Tronics Defense Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
BT-70791A: 51828 - Bren-Tronics Defense Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
BB-2590/U: 80063 - Us Army Communications & Electronics (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
TRCECOMBB01: 80063 - Us Army Communications & Electronics (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
10103572: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
655461910110: 0000V - Ncb Hungary (Honvedsegi Egyseges (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
6140PL0295985: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
32052/1-BB2590/U: 81349 - Military Specifications (Active); Transferred; RNCC E RNVC 8 DAC E

Datasheet 6140-01-490-4316

Characteristic
Specifications
FIIG: T139-A
Special Features [FEAT]: Lbattery Output= 16.5/33 Volts(Ocv) & 12/24 Volts(Nom); Cutoff Voltage= 8.0 Volts; Battery Capacity= 5.6 Amp Hours At 2 Amps Discharge; Battery Chemistry Is Lithium Ion; Operating Temps=-20C To +50C (-4F To 122F)

Weapon Systems (WSDC) 6140-01-490-4316

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 6140-01-490-4316

Last Stock Position:: 6 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 6140-01-490-4316

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Apr 2023: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2022: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Jun 2021: US Marine Corps (DM); EA; Subscribe; 1
Mar 2021: Department of the Army (DA); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 6140-01-602-1777

Army

Materiel Category and Inventory Manager:

Q: Electronics Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Special Material Content:

E: Lithium Battery

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

0: Non-combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

0

Physical Category:

1: Bin

Similar Supply Items to 6140-01-490-4316

Freight Information 6140-01-490-4316

6140-01-490-4316 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 060680. A Sub NMFC of Z. It has a NMFC Description of BATTERIES OR CELL. 6140-01-490-4316 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34100 which rates the freight between FCL and LCL. 6140-01-490-4316 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 582 for ocean manifesting and military sealift. 6140-01-490-4316 is classified as a Miscellaneous Hazardous Material, UN Class 9, when transported by water. 6140-01-490-4316 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 6140-01-490-4316

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Non-Metallic Item; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; Special requirement – See specific instructions or drawings provided; Type II, shelf life

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Procurement History 6140-01-490-4316 22 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7L718C0004: 17 Jan 2018; Subscribe; 60000; Subscribe; Subscribe
SPE7L717P5684: 18 Sep 2017; Subscribe; 1050; Subscribe; Subscribe
SPE7L717P3405: 22 Jun 2017; Subscribe; 4800; Subscribe; Subscribe
SPE7L717C0005: 19 Apr 2017; Subscribe; 6390; Subscribe; Subscribe
SPE7L717P1980: 04 Apr 2017; Subscribe; 4800; Subscribe; Subscribe
SPE7L717P1083: 05 Jan 2017; Subscribe; 2000; Subscribe; Subscribe
SPE7L717P1079: 22 Dec 2016; Subscribe; 1000; Subscribe; Subscribe
SPE7L717P0750P00001: 06 Dec 2016; Subscribe; 1000; Subscribe; Subscribe
SPE7L716M4510: 07 Sep 2016; Subscribe; 1000; Subscribe; Subscribe
SPE7L716M3624: 15 Jun 2016; Subscribe; 1000; Subscribe; Subscribe
SPE7L716M3516: 09 Jun 2016; Subscribe; 1000; Subscribe; Subscribe
SPE7L716M2529: 12 Apr 2016; Subscribe; 1000; Subscribe; Subscribe
SPM7LX10D7153001001: 16 Sep 2015; Subscribe; 4405; Subscribe; Subscribe
SPM7LX10D7154001001: 09 Sep 2015; Subscribe; 3345; Subscribe; Subscribe
SPM7LX10D71540009: 06 Aug 2015; Subscribe; 2193; Subscribe; Subscribe
SPM7LX10D71530009: 06 Jul 2015; Subscribe; 1121; Subscribe; Subscribe
SPM7LX10D71530008: 12 May 2015; Subscribe; 1450; Subscribe; Subscribe
SPM7LX10D71530007: 13 Mar 2015; Subscribe; 618; Subscribe; Subscribe
SPM7LX10D7154000701: 09 Feb 2015; Subscribe; 4000; Subscribe; Subscribe
SPM7LX10D71530006: 16 Dec 2014; Subscribe; 501; Subscribe; Subscribe
SPM7LX10D7154000502: 25 Sep 2014; Subscribe; 1787; Subscribe; Subscribe
SPM7LX10D7153000504: 20 Feb 2013; Subscribe; 3058; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 6140-01-490-4316 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Product Information 6140-01-490-4316

Marketplace 6140-01-490-4316

Related Documents 6140-01-490-4316 5+ Documents (More...)

Restrictions 6140-01-490-4316

Import and Export 6140-01-490-4316

End Users 6140-01-490-4316

Approved Sources 6140-01-490-4316

Datasheet 6140-01-490-4316

Weapon Systems (WSDC) 6140-01-490-4316

DLA Procurement Analysis 6140-01-490-4316

Management Data 6140-01-490-4316

Army

Air Force

Navy

Marine Corps

Similar Supply Items to 6140-01-490-4316

Freight Information 6140-01-490-4316

Packaging Data 6140-01-490-4316

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 6140-01-490-4316 22 Records

Contracting Technical Data File (CTDF) 6140-01-490-4316 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
