6140-00-454-8261

Battery Assembly

6140004548261 004548261 BB-287 10189465 BB287 433-0254

Two or more batteries on a common mounting or mounted on each other. They must be separable and each item must be capable of functioning in accordance with its given item name. View more Battery Assembly

Managed by United States

NSN Created on 23 Apr 1969

Data Last Changed
February 2025

NATO Update Count
43

NATO Data Quality

6140-00-454-8261 BATTERY ASSEMBLY 6140004548261 004548261 1/1 — 6140-00-454-8261 Photo 1/1

Product Information 6140-00-454-8261

TOW BB-287 Battery

Military # BB-287/U
Chemistry: Ni-Cd

Rechargeable Nickel Cadmium Battery

Typically Used in: TOW, Anti-Tank Guided Missile System

Charging note: charger at constant current of 1 Amp for 5-6 hours

Length 15.5" / Width 4.8" / Height 8.5"

Nominal Voltage	24.0V, 50.4V
Ah	Section 1: 4.5 Ah, Section 2 & 3 (each): 1.4
Operating Temperature	-20°C to +55°C (-4°F to +131°F)
Storage Temperature	-40°C to +40°C (-40°F to 104°F)
Connector	Per U.S. Missile DWG # 10084532
State of Charge Indicator	No
Battery Type	Rechargeable
Brenergy	No

Marketplace 6140-00-454-8261

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

6140-00-454-8261 BATTERY ASSEMBLY 5 EA NS

Updated Every Day

6140-00-454-8261 RQST NE

Updated Every Day

6140-00-454-8261 RQST

Updated Every Day

6140-00-454-8261 RQST NE

Restrictions 6140-00-454-8261

6140-00-454-8261 is a Battery Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.

Import and Export 6140-00-454-8261

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 6140-00-454-8261

US Army (A918)
Effective Date:: 1 Apr 2010
Former MOE Rule:: A303
Supplementary Receivers:: BDCN; AMC 1 AMSC G IMC Z IMCACTY CD

US Air Force (FXGG)
Effective Date:: 1 Apr 2010
Former MOE Rule:: FXBD; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC41)
Effective Date:: 1 Apr 2010
Former MOE Rule:: MA37; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BG)
Effective Date:: 1 Apr 2010
Former MOE Rule:: N9S5
Supplementary Collaborators:: GT; AMC 1 AMSC G IMC Z IMCACTY GH

Finland (WF01)
Effective Date:: 1 Nov 2008

Spain (YB01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Jan 2015

Morocco (YP01)
Effective Date:: 1 Sep 2010

Canada (ZC01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Aug 1995

Turkey (ZW01)
Effective Date:: 1 Oct 1995

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Apr 1991

Approved Sources 6140-00-454-8261

Datasheet 6140-00-454-8261

Characteristic
Specifications
FIIG: T139-B
Battery Quantity [AEXR]: 3
Component Controlling Agency [AQHK]: Army Missile Command
Component Identifying Number [AQHM]: 10189433 Drawing No. And 10189441 Drawing No.
Component Name [AQHL]: Storage Battery
Mounting Method [ADJH]: Plate
Overall Height [ABKW]: 7.100 Inches Nominal
Overall Length [ABHP]: 15.300 Inches Nominal
Overall Width [ABMK]: 4.810 Inches Nominal

Weapon Systems (WSDC) 6140-00-454-8261

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 6140-00-454-8261

Last Stock Position:: 0 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 6140-00-454-8261

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe; 1
Oct 2021: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
US Marine Corps (DM): M; 9; Reversal Of Phrase Code P 6140-00-455-9383

Army

Materiel Category and Inventory Manager:

Q: Electronics Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

E2: Surface-to-Surface Missiles
Tube - Launched, Optically- Tracked, Wire Guided (TOW-2) Missile

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SX: SICA RESIDUAL MMAC-OC-ALC

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Special Material Content:

H: Item that is hazardous under typical use or handling

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

T: Maintenance Float Secondary Non-depot Reparables

Operational Test:

2: Special Procedures | Not MOWASP Controlled

Similar Supply Items to 6140-00-454-8261

Freight Information 6140-00-454-8261

6140-00-454-8261 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 060680. A Sub NMFC of Z. It has a NMFC Description of BATTERIES OR CELL. 6140-00-454-8261 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 6140-00-454-8261 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34100 which rates the freight between FCL and LCL. 6140-00-454-8261 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 582 for ocean manifesting and military sealift. 6140-00-454-8261 is not classified as a special type of cargo when transported by water. 6140-00-454-8261 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 6140-00-454-8261

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"; 85 to 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; Special requirement – See specific instructions or drawings provided; Type I, shelf life

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Procurement History 6140-00-454-8261 31 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7MX16D0003001201: 02 May 2016; Subscribe; 14; Subscribe; Subscribe
SPE7MX16D0003001101: 25 Feb 2016; Subscribe; 127; Subscribe; Subscribe
SPE7MX16D0003001001: 22 Feb 2016; Subscribe; 16; Subscribe; Subscribe
SPE7MX16D0003000901: 10 Feb 2016; Subscribe; 45; Subscribe; Subscribe
SPE7MX16D00030008: 09 Feb 2016; Subscribe; 93; Subscribe; Subscribe
SPE7MX16D00030007: 20 Nov 2015; Subscribe; 27; Subscribe; Subscribe
SPE7MX16D00030006: 19 Nov 2015; Subscribe; 27; Subscribe; Subscribe
SPE7MX16D00030005: 18 Nov 2015; Subscribe; 2; Subscribe; Subscribe
SPE7MX16D00030004: 17 Nov 2015; Subscribe; 217; Subscribe; Subscribe
SPE7MX16D00030003: 04 Nov 2015; Subscribe; 93; Subscribe; Subscribe
SPE7MX16D00030002: 03 Nov 2015; Subscribe; 93; Subscribe; Subscribe
SPE7MX16D00030001: 26 Oct 2015; Subscribe; 213; Subscribe; Subscribe
SPM7LX13D00630019: 10 Jun 2015; Subscribe; 60; Subscribe; Subscribe
SPM7LX13D00630018: 06 Apr 2015; Subscribe; 62; Subscribe; Subscribe
SPM7LX13D00630017: 12 Mar 2015; Subscribe; 89; Subscribe; Subscribe
SPM7LX13D00630016: 06 Mar 2015; Subscribe; 90; Subscribe; Subscribe
SPM7LX13D00630015: 23 Feb 2015; Subscribe; 66; Subscribe; Subscribe
SPM7LX13D00630014: 11 Feb 2015; Subscribe; 48; Subscribe; Subscribe
SPM7LX13D00630013: 31 Oct 2014; Subscribe; 15; Subscribe; Subscribe
SPM7LX13D00630012: 02 Jun 2014; Subscribe; 92; Subscribe; Subscribe
SPM7LX13D00630011: 30 May 2014; Subscribe; 57; Subscribe; Subscribe
SPM7LX13D00630010: 16 May 2014; Subscribe; 40; Subscribe; Subscribe
SPM7LX13D00630009: 13 May 2014; Subscribe; 19; Subscribe; Subscribe
SPM7LX13D00630008: 08 May 2014; Subscribe; 93; Subscribe; Subscribe
SPM7LX13D00630007: 08 Apr 2014; Subscribe; 13; Subscribe; Subscribe
SPM7LX13D00630006: 24 Mar 2014; Subscribe; 90; Subscribe; Subscribe
SPM7LX13D00630005: 27 Feb 2014; Subscribe; 15; Subscribe; Subscribe
SPM7LX13D00630004: 08 Jan 2014; Subscribe; 10; Subscribe; Subscribe
SPM7LX13D0063000301: 10 Dec 2013; Subscribe; 74; Subscribe; Subscribe
SPM7LX13D00630002: 08 Aug 2013; Subscribe; 17; Subscribe; Subscribe
SPM7LX13D0063000101: 19 Jun 2013; Subscribe; 120; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 6140-00-454-8261 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F
