Premium Information is available for this item - Upgrade for $1 a day
6130-01-711-0104
Battery Power Supply
6130017110104 017110104 BT-70910CZ
An item designed to contain one or more batteries and other control parts. It may contain the battery(ies), but must contain the control parts, which are used for controlling the output voltage(s) and/or activation of the battery(ies). It is a self-contained unit that provides for a direct current (DC) output.The control parts include items, such a remote control units.Excludes CHARGER, RADIAC DETECTOR. View more Battery Power Supply
February 2025
1
Product Information 6130-01-711-0104
BB-2525/U Conformal Wearable Battery (CWB), 148 Wh
Military # BB-2525/U
Chemistry: Li-ion
The Bren-Tronics BT-70910CZ is the commercial equivalent of the BB-2525/U and is designed to meet MIL-PRF 32383. The CWB is a lightweight, thin, battery that conforms to the user and ballistic protective plates.
- Complies with SMBus v1.1 and SBData v1.1
- UN/DOT 38.3 Rating: 148Wh
- USB Type-A DCP
- Digital Display with Tactile Push Button Switch (TPBS)
- Designed to meet U.S. MIL-PRF-32383
Length 8.7" / Width 7.66" / Height 0.7" / Weight 2.6 lbs
| Nominal Voltage | 15.0V |
|---|---|
| Ah | 10.0 |
| Maximum Voltage | 17.0V |
| Case Materials/Colors | Tan |
| Operating Temperature | –30°C to +55°C (-22°F to +131°F) |
| Storage Temperature | –32°C to +71°C (-26°F to +160°F) |
| Connector | 7 PIN Nett Warrior Connector |
| State of Charge Indicator | Yes |
| US Gov Spec | Designed to meet MIL-PRF-32383/4X |
| Battery Type | Rechargeable |
| Smart Battery | SMBus |
| Brenergy | No |
Marketplace 6130-01-711-0104
Request a Quotation from participating marketplace vendors
Related Documents 6130-01-711-0104 5+ Documents (More...)
United States (US) 4. 6130-01-711-0104 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 6130-01-711-0104 RQST Updated Every Day 6130-01-711-0104 RQST NE Related Documents
Restrictions 6130-01-711-0104
6130-01-711-0104 is a Battery Power Supply that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Approved Sources 6130-01-711-0104
- Part Number
- Manufacturer
- Status
- BT-70910CZ
- Manufacturer
- 51828 - Bren-Tronics Defense Llc (Active)
- Primary Buy
- Primary Buy
Management Data 6130-01-711-0104
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2023
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
Similar Supply Items to 6130-01-711-0104
