6130-01-546-4492
Uninterruptible Power Supply
6130015464492 015464492 SC1000
An item that provides continuous backup power to electronic devices in the event of a utility power dip or blackout. It generally contains a battery and a power inverter that provides the necessary backup power in the event of a loss of normal input utility power. It may also contain a power line filter or power line conditioning devices. Excludes power supplies without standby power, electrical power inverers, and batteries. View more Uninterruptible Power Supply
June 2023
4
Marketplace 6130-01-546-4492
Request a Quotation from participating marketplace vendors
Related Documents 6130-01-546-4492 5+ Documents (More...)
Uninterruptible Power Supply 6130015464492 SC1000 POWER SUPPLY,UNINTERRUPTIBLE 1 EA NS Request Quotation
3433-4321-1830 Power Supply 6130015464492 RNVC 2 DAC 4 GDHF SC1000 https//www.nsnlookup.com /fsg-34/
www.nsnlookup.com /fsg-58/fsc-5830/us 5830-01-525-6077 Public Address Set 5830015256077 015256077 SC1000
3433-4321-1830 Power Supply 6130015464492 RNVC 2 DAC 4 GDHF SC1000 https//www.nsnlookup.com /fsg-34/
Part NumberManufacturerStatusAPC SMART-UPS SC1000 https//www.nsnlookup.com /fsg-66/fsc-6665/nl 6665-
-61/fsc-6130/us 6130-01-546-4492 Uninterruptible Power Supply 6130015464492 SUPPLY,UNINTERRUPTIBLE 1
SC1000 VACUUM DISPOSITION SYSTEM 2 EA NS Request Quotation Subscribe to View Vendor Details...
SC1000 VACUUM DISPOSITION SYSTEM 1 EA NS Request Quotation Updated Every Day 3433-00-227-4547 RQST NE
3433-4321-1830 Power Supply 6130015464492 RNVC 2 DAC 4 GDHF SC1000 https//www.nsnlookup.com /fsg-34/
Restrictions 6130-01-546-4492
6130-01-546-4492 is a Uninterruptible Power Supply that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 6130-01-546-4492
- Canada (ZC01)
- Effective Date:
- 1 Dec 2006
Approved Sources 6130-01-546-4492
- Part Number
- Manufacturer
- Status
- SC1000
- Manufacturer
- 0MG77 - Schneider Electric It Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 6130-01-546-4492
- Characteristic
- Specifications
- FIIG
- Specifications
- A39900
- Battery Feature And Type [CWHY]
- Rechargeable Lead Acid Cell
- Battery Power Supply Emergency Operating Time [CXMX]
- 7.4
- Battery Quantity [AEXR]
- 1
- Maximum Operating Altitude Rating [AKAE]
- 10000.0 Feet
- Operating Ambient Temp Range [AYNH]
- +0.0/+40.0 Deg Celsius
- Output Connection Quantity [CWHF]
- 6 Single Power Output
- Output Connection Type [CWHJ]
- Connector, Plug Single Power Output
- Output Current Rating [CWGH]
- 1000.0 Ac Volt-Ampere Nominal Single Power Output
- Output Phase [CWGN]
- Single Single Power Output
- Output Frequency Rating [APTS]
- 47.0 Hertz Minimum Single Power Output And 63.0 Hertz Maximum Single Power Output
- Output Wattage Rating [BGQR]
- 600.0 Watts Nominal Single Power Output
- Output Voltage Rating [APPA]
- 120.0 Ac Volts Nominal Single Power Output
- Input Frequency Rating [APTQ]
- 47.0 Hertz Minimum Single Operating Power Rqmt And 63.0 Hertz Maximum Single Operating Power Rqmt
- Input Connection Type [CWHQ]
- Connector, Plug Single Operating Power Rqmt
- Input Voltage Rating [APNX]
- 120.0 Ac Pounds Per Hour Wet Single Operating Power Rqmt
- Input Phase [ANPM]
- Single Single Operating Power Rqmt
- Overall Height [ABKW]
- 3.500 Inches Nominal
- Overall Length [ABHP]
- 18.240 Inches Maximum
- Overall Width [ABMK]
- 17.000 Inches Maximum
Management Data 6130-01-546-4492
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- May 2023
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
NATO Stock Numbers Related to 6130-01-546-4492
Freight Information 6130-01-546-4492
6130-01-546-4492 has freight characteristics managed by the Department of the Air Force.. 6130-01-546-4492 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
