6130-01-285-9151

Power Supply

6130012859151 012859151 6623A HP6623A

A component which converts available alternating current or direct current electrical power into a form required to operate another component or set. The item may consist of a combination of an INVERTOR, VIBRATOR; VIBRATOR, INTERRUPTER; VIBRATOR, SELF-RECTIFYING; INVERTOR, POWER, STATIC; with a transformer and rectifier(s) employing electron tubes, semiconductor diode or metallic (dry disc) type components, or the synchronized secondary contact(s) of a VIBRATOR, SELF-RECTIFYING; or may consist of electron tubes, semiconductor diode or metallic (dry disc) type rectifiers and capacitors in transformerless (alternating current-direct current type) circuits which may be of the voltage-multiplier type. The item may incorporate a FILTER, DIRECT CURRENT POWER and provisions for regulation of input and/or output voltage. The item may have special input, output, control or other facilities for applications in specialized environments such as medical, dental or other operations. Excludes battery chargers and rotating machinery types of items, such as motor generators and dynamotors. View more Power Supply

6130-01-285-9151 POWER SUPPLY 6130012859151 012859151

Managed by United States
NSN Created on 22 Sep 1988
Data Last Changed
May 2023
NATO Update Count
15
NATO Data Quality
6130-01-285-9151 POWER SUPPLY 6130012859151 012859151 1/1
6130-01-285-9151 Photo 1/1

6130-01-285-9151 Stock and Availability Marketplace 6130-01-285-9151

Need Help?
Request a Quotation from participating marketplace vendors

6130-01-285-9151 Related Documents Related Documents 6130-01-285-9151 5+ Documents (More...)

6623A HP6623A A component which converts available alternating current or direct current electrical
Updated Every Day 6130-01-285-9151 RQST NE Updated Every Day 6130-01-285-9151 RQST Updated Every Day
/fsg-61/fsc-6130/us 6130-01-285-9151 Power Supply 6130012859151 012859151,6623A 6623AHP6623A A component
enable JavaScript in your web browser . 5340-14-389-2527Jeu Brides Fixation5340143892527 143892527 6623A
Power Supply 6130012859151 012859151,6623A POWER SUPPLY 5 EA NS Request Quotation Subscribe to
Jeu Brides Fixation 5340143892527143892527 -9380 Power Supply 6130013379380013379380 6623A https for
597-9489 6130-01-303-4296 6130-00-291-0525 6130-01-451-3810 6130-01-618-4110 6130-01-588-5188 6130-01-285-9151
597-9489 6130-01-303-4296 6130-00-291-0525 6130-01-451-3810 6130-01-618-4110 6130-01-588-5188 6130-01-285-9151
597-9489 6130-01-303-4296 6130-00-291-0525 6130-01-451-3810 6130-01-618-4110 6130-01-588-5188 6130-01-285-9151

6130-01-285-9151 Demil Restrictions 6130-01-285-9151

DEMIL: A | DEMILI: 1 | CRITICALITY: X | HMIC: N | PMIC: A | EDC: | ADPEC: 0

6130-01-285-9151 is a Power Supply that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

6130-01-285-9151 HTS and ScheduleB Import and Export 6130-01-285-9151

6130-01-285-9151 End Users End Users 6130-01-285-9151

Spain (YB01)
Effective Date:
1 Mar 2000
France (ZF01)
Effective Date:
1 May 1995
Republic of Korea (ZH01)
Effective Date:
1 Nov 2009
United Kingdom (ZK01)
Effective Date:
1 Dec 1995
Italy (ZR01)
Effective Date:
1 Jul 1997

6130-01-285-9151 Manufacturers Approved Sources 6130-01-285-9151

6130-01-285-9151 Technical Data Datasheet 6130-01-285-9151

Characteristic
Specifications
FIIG
A39900
Electrical Power Source Relationship [AKWC]
Operating
Features Provided [CBBL]
Ground Wire Terminal And Input To Output Isolation And Input To Case Isolation And Output To Case Isolation And Over Voltage Protector And Over Current Protector
Output Connection Quantity [CWHF]
6 Single Power Output
Output Connection Type [CWHJ]
Terminal Strip Single Power Output
Output Current Rating [CWGH]
0.0 Dc Amperes Minimum 1St Power Output And 0.8 Dc Amperes Maximum 1St Power Output
Output Current Rating [CWGH]
0.0 Dc Amperes Minimum 2Nd Power Output And 4.0 Dc Amperes Maximum 2Nd Power Output
Output Current Rating [CWGH]
0.0 Dc Amperes Minimum 3Rd Power Output And 2.0 Dc Amperes Maximum 3Rd Power Output
Output Current Rating [CWGH]
0.0 Dc Amperes Minimum 4Th Power Output And 2.0 Dc Amperes Maximum 4Th Power Output
Output Current Rating [CWGH]
0.0 Dc Amperes Minimum 5Th Power Output And 10.0 Dc Amperes Maximum 5Th Power Output
Output Current Rating [CWGH]
0.0 Dc Amperes Minimum 6Th Power Output And 5.0 Dc Amperes Maximum 6Th Power Output
Output Voltage Rating [APPA]
0.0 Dc Volts Minimum 1St Power Output And 50.0 Dc Volts Maximum 1St Power Output
Output Voltage Rating [APPA]
0.0 Dc Volts Minimum 2Nd Power Output And 20.0 Dc Volts Maximum 2Nd Power Output
Output Voltage Rating [APPA]
0.0 Dc Volts Minimum 3Rd Power Output And 20.0 Dc Volts Maximum 3Rd Power Output
Output Voltage Rating [APPA]
0.0 Dc Volts Minimum 5Th Power Output And 7.0 Dc Volts Maximum 5Th Power Output
Output Voltage Rating [APPA]
0.0 Dc Volts Minimum 6Th Power Output And 7.0 Dc Volts Maximum 6Th Power Output
Output Voltage Rating [APPA]
0.0 Dc Volts Minimum 4Th Power Output And 20.0 Dc Volts Maximum 4Th Power Output
Input Phase [ANPM]
Single Single Operating Power Rqmt
Input Frequency Rating [APTQ]
47.0 Hertz Minimum Single Operating Power Rqmt And 66.0 Hertz Maximum Single Operating Power Rqmt
Input Voltage Rating [APNX]
120.0 Ac Volts Nominal Single Operating Power Rqmt
Overall Height [ABKW]
5.220 Inches Nominal
Overall Length [ABHP]
19.600 Inches Nominal
Overall Width [ABMK]
16.750 Inches Nominal
Ventilation Design Type [CWKG]
Single Fan

6130-01-285-9151 Similar Items Similar Supply Items to 6130-01-285-9151

6130-01-285-9151 Freight Data Freight Information 6130-01-285-9151

6130-01-285-9151 has freight characteristics.. 6130-01-285-9151 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
