6130-00-166-1332
Interrupter Vibrator
6130001661332 001661332 MILV5635PTAM4114-1 AN4114-1 VJR24B3X
An electromechanical device which uses a coil operated switching mechanism to convert a direct current input into a pulsating direct current output of the same value. The direct current input is periodically interrupted at the resonant frequency of a coil driven vibrating armature (reed). The resultant pulsating direct current output produces an inherent alternating current component necessary for ultimate purposes of transformation. It does not include a means of amplification or rectification. For items designed to operate over a wide and comparatively high frequency range and whose drive coil may be excited from either an alternating current or a direct current, see CHOPPER, ELECTRONIC. View more Interrupter Vibrator
May 2023
12
Marketplace 6130-00-166-1332
Request a Quotation from participating marketplace vendors
Related Documents 6130-00-166-1332 1+ Documents (More...)
AN4114-1 VIBRATOR,INTERRUPTER 4 EA NS Request Quotation VJR24B3X VIBRATOR,INTERRUPTER 46 EA NS Request
VJR24B3X VIBRATOR,INTERRUPTER 3 EA NS Request Quotation Updated Every Day 6130-00-166-1332 RQST NE Updated
Restrictions 6130-00-166-1332
6130-00-166-1332 is a Interrupter Vibrator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6130-00-166-1332
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6130-00-166-1332
- Portugal (ZP)
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR)
- Italy (ZR01)
- Effective Date:
- 1 Dec 2007
Approved Sources 6130-00-166-1332
- Part Number
- Manufacturer
- Status
- AN4114-1
- Manufacturer
- 88044 - Aeronautical Standards Group (Active)
- Definitive Standard
- Definitive Standard
- MILV5635PTAM4114-1
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- VJR24B3X
- 04998 - Adams Aircraft International Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- VJR24B3X
- 01843 - Ambac International Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6130-00-166-1332
- Characteristic
- Specifications
- FIIG
- Specifications
- T320-K
- Drive Voltage Relationship To Input Voltage [BGRB]
- Unequal
- Hermetically Sealed Feature [AXNN]
- Not Provided
- Output Frequency Rating [APTS]
- 0.9 Kilohertz Minimum And 1.0 Kilohertz Maximum
- Input Current Rating [AZSL]
- 3.0 Amperes Nominal
- Input Voltage Rating [APNX]
- 24.0 Dc Pounds Per Hour Wet
- Reed Type [BGRJ]
- Single
- Overall Height [ABKW]
- 3.453 Inches Nominal
- Overall Length [ABHP]
- 4.750 Inches Nominal
- Overall Width [ABMK]
- 4.688 Inches Nominal
- Special Features [FEAT]
- The Starting Vibrator Is A Current Regulating Device And Hence Its Reed Frequency Varies W/Operating Conditions And Particularly W/Applied Voltage; Frequency Increases W/Applied Voltage; Vibrator Works In Conjunction W/A Magneto,And Its Frequency Changes As The Magneto Contacts Open And Close
NATO Stock Numbers Related to 6130-00-166-1332
Freight Information 6130-00-166-1332
6130-00-166-1332 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061300. A Sub NMFC of X. It has a NMFC Description of CIRCUIT BREAKER/SWITCH NOI. 6130-00-166-1332 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 6130-00-166-1332 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34410 which rates the freight between FCL and LCL. 6130-00-166-1332 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 6130-00-166-1332 is not classified as a special type of cargo when transported by water. 6130-00-166-1332 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
