6115-01-256-1059

Diesel Engine Generator Set

6115012561059 012561059 A/E37U-22 0015-70029 YDG3000E-LAF 30D36R YDG3000E-L

A generator set using a diesel engine as the prime mover. Excludes GENERATOR SET, DIESEL ENGINE, TRAILER MOUNTED. View more Diesel Engine Generator Set

6115-01-256-1059 GENERATOR SET,DIESEL ENGINE 6115012561059 012561059

Managed by United States
NSN Created on 31 May 1987
Data Last Changed
May 2023
NATO Update Count
8
NATO Data Quality
6115-01-256-1059 GENERATOR SET,DIESEL ENGINE 6115012561059 012561059 1/1
6115-01-256-1059 Photo 1/1

6115-01-256-1059 Stock and Availability Marketplace 6115-01-256-1059

Need Help?
Request a Quotation from participating marketplace vendors
eBay Updated Every Day
6115-01-256-1059 RQST NE eBay
eBay Updated Every Day
6115-01-256-1059 RQST eBay
Amazon Updated Every Day
6115-01-256-1059 RQST NE Amazon

6115-01-256-1059 Related Documents Related Documents 6115-01-256-1059 2+ Documents (More...)

A/E37U-22 0015-70029 YDG3000E-LAF 30D36R YDG3000E-L A generator set using a diesel engine as the prime
RQST NE Updated Every Day 6115-01-256-1059 RQST Updated Every Day 6115-01-256-1059 RQST NE Related Documents
6115-01-256-1059 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-61/fsc-6115/us 6115-01-256-1059
Filter Element2940144843391 144843391 228-32801-07 https//www.nsnlookup.com /fsg-61/fsc-6115/us 6115-01-256-1059
Diesel Engine Generator Set 6115012561059 www.nsnlookup.com /fsg-61/fsc-6115/us 6115-01-256-1059
EssentialCriticality Code Justification [CRTL]FeatEnd Item Identification [AGAV]Generator Set,Diesel Engine-Nsn-6115-01-256-1059

6115-01-256-1059 Demil Restrictions 6115-01-256-1059

DEMIL: A | DEMILI: 7 | CRITICALITY: X | HMIC: Y | PMIC: A | EDC: | ADPEC: 0

IUID Required

6115-01-256-1059 is a Diesel Engine Generator Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. The DCMO has forced the Demilization requirements for this item as the ICP has not collaborated. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.

6115-01-256-1059 HTS and ScheduleB Import and Export 6115-01-256-1059

6115-01-256-1059 End Users End Users 6115-01-256-1059

US Air Force (FGG4)
Effective Date:
1 Sep 2000
Former MOE Rule:
FAA4
US Navy (NSGS)
Effective Date:
1 Sep 2000
Israel (YD01)
Effective Date:
1 Oct 2016

6115-01-256-1059 Manufacturers Approved Sources 6115-01-256-1059

6115-01-256-1059 Technical Data Datasheet 6115-01-256-1059

Characteristic
Specifications
FIIG
T322-A
Accessory Component Name [AZCG]
Pilot Lamp;Ac Receptacle;Dc Receptacle;Braker;Fuse;Change-Over Switch;Key Switch;Oil Alert;Stop Solenoid
Accessory Component Quantity [AFHS]
9
Ac Wattage Rating [AYGY]
3.1 Kilowatts
Accessory Controlling Agency [AKVY]
T & J Manufacturing
Ambient Temp In Deg Celsius [AZCL]
20.0
Automatic Starting Feature [AZBM]
Not Provided
Dc Wattage Rating [AYHA]
100.0 Watts
Dc Voltage Rating [ACYR]
12.0 Volts Nominal
Direct Current Rating In Amps [ACUT]
8.3
Excitor [AYHF]
Included
Excitor Type [AYHE]
Self-Excited
Frequency Rating [ACZB]
60.0 Hertz Nominal
Housing Type [AZCB]
Open
Current Type [ACDC]
Ac And Dc
Mounting Type [AAXX]
Skid Shock Tubular Frame
Line To Line Voltage In Volts [AYHB]
120.0
Line To Neutral Voltage In Volts [AYHC]
120.0 And 240.0
Power Factor In Percent [AYHD]
100.0
Prime Mover Starting Method [AYQZ]
Electric Motor Or Manually By Rope
Prime Mover Cooling Medium [AAXS]
Air
Prime Mover Identifying Number [AZBP]
30336R Model No.
Prime Mover Manufacturer Name [AZBN]
T & J Manufacturing
Radio Interference Suppression [AZKT]
Not Included
Overall Height [ABKW]
22.000 Inches Nominal
Overall Length [ABHP]
25.000 Inches Nominal
Overall Width [ABMK]
19.000 Inches Nominal
Phase [FAAZ]
Single
Unpackaged Unit Weight [AWJN]
180.000 Pounds
Winterization Feature [AMWJ]
Not Included

6115-01-256-1059 Management Data Management Data 6115-01-256-1059

Effective Date
Organization
Unit of Issue
Unit Price
Qty Unit Pack
Nov 2019
Department of the Air Force (DF)
EA
Subscribe
1
May 2010
Department of the Navy (DN)
EA
Subscribe
1

Air Force Air Force

Budget:
M
57X3080 - Other Base Maintenance and Support Equipment
Aggregation Code:
ID
GENERATORS AND GENERATOR SETS, GROUND
Price Validation Code:
N
The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
Expendability
Recoverability
Repairability:
U
Reparable. Condemn at Intermediate. AF Equipment Management System (AFEMS).

Navy Navy

Cognizance:
1H
Consumable material assigned to NAVICP MECH for inventory management
Naval Inventory Control Point, Mechanicsburg
Issue, Repair, Requisition Restriction Code:
00
No Restriction
Special Material Content:
9
Non-Hazardous or Non-Sensitive Item

6115-01-256-1059 Related Items NATO Stock Numbers Related to 6115-01-256-1059

6115-01-256-1059 Freight Data Freight Information 6115-01-256-1059

6115-01-256-1059 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of D. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI SUB4. 6115-01-256-1059 is rated as class 65 when transported by Less-Than Truckload (LTL) freight. 6115-01-256-1059 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6115-01-256-1059 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 738 for ocean manifesting and military sealift. 6115-01-256-1059 is not classified as a special type of cargo when transported by water. 6115-01-256-1059 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

6115-01-256-1059 Packaging Data Packaging Data 6115-01-256-1059

Responsible Activity
Packaging Data Source
Secondary Inventory Control Activity (SICA)
Packaging Data does not meet current MIL-STD-2073-1E
Storage Environment
Heated General Purpose – Heated 40 F and above

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation
24.5" H x 18.5" W x -- L
--
--
Over 10lb
Less than 85G
No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying
1
33.0" H x 27.0" W x 32.0" L
--
--
Physical Protection
Any Suitable Process
Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking
No Requirement
No Requirement
Wood Blocking and Bracing, Fasteners, or Steel Strapping, for Tie-down purposes. Rubber tired wheels shall be blocked clear of the floor of the crate or skid and shall not be load bearing
Not Applicable
ASTM-D6251, Type III, Class 1, Wood Cleated Plywood Box, Domestic
--

Intermediate Pack Level

Quantity of Unit Packs
Container
--
No Requirement
