6115-01-143-3311
Gasoline Engine Generator Set
6115011433311 011433311 MEP-016C 13208E5800
A generator set using a gasoline engine as the prime mover. Excludes GENERATOR SET, GASOLINE ENGINE, TRAILER MOUNTED. View more Gasoline Engine Generator Set
May 2023
9
Marketplace 6115-01-143-3311
Request a Quotation from participating marketplace vendors
Related Documents 6115-01-143-3311 5+ Documents (More...)
RQST NE Updated Every Day 6115-01-143-3311 RQST Updated Every Day 6115-01-143-3311 RQST NE Related
Documents 6115-01-143-3311 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-61/fsc-6115/us 6115
Gasoline Engine Generator Set 6115011433311 Contact 5999015017123015017123 /fsg- https//www.nsnlookup.com
Contact 5999015017123015017123 CFQ-2518A Electrical https//www.nsnlookup.com /fsg-61/fsc-6115/us 6115-01-143-3311
Gasoline Engine Generator Set 6115011433311 Contact 5999015017123 015017123 /fsg-61/fsc-6115 015017123
Electrical Contact 5999015017123015017123 CFQ-2518A www.nsnlookup.com /fsg-61/fsc-6115 / us 6115-01-143-3311
Gasoline Engine Generator Set 6115011433311 Account Upgrade 6115-01-143-3311Gasoline Engine https
Upgrade your Account Upgrade 6115-00-017-8237Gasoline https//www.nsnlookup.com /fsg-61/fsc-6115/us 6115-01-143-3311
Gasoline Engine Generator Set 6115011433311 your Account Upgrade 6115-01-143-3311Gasoline Engine
Restrictions 6115-01-143-3311
IUID Required
6115-01-143-3311 is a Gasoline Engine Generator Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal. This item is sensitive to Electrostatic Discharge and Electromagnetic Interference.
Import and Export 6115-01-143-3311
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6115-01-143-3311
- US Army (A502)
- Effective Date:
- 1 Oct 1997
- Former MOE Rule:
- A002
Approved Sources 6115-01-143-3311
- Part Number
- Manufacturer
- Status
- MEP-016C
- Manufacturer
- 30554 - Department Of Defense Project (Active)
- Primary Buy
- Primary Buy
- 13208E5800
- 97403 - Cecom Lr Center (Active)
- Secondary Buy
- Secondary Buy
Datasheet 6115-01-143-3311
- Characteristic
- Specifications
- FIIG
- Specifications
- T322-A
- Special Features [FEAT]
- 3Kw,60Hz,Ged,Tu Mod (Gas Generator);Mep-016C;4 Cylinder Gasoline,6Hp At3600rpm,Rope Start,Air Cooled;Tubular Frame Skid,Lifting Attachments Provided;12 Cu Ft,Man Portable;Opt Equip Diesel Conversation Kit 2815-01-440-4426
Management Data 6115-01-143-3311
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jun 2010
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- G
- Communications and Electronics Equipment, Electronics Materiel
- Appropriation and Budget Activity:
- Q
- Other Support Equipment
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- VL
- Power Generation Systems
Generator Sets: .15 to 3KW 60HZ
- Accounting Requirements:
- N
- Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.
NATO Stock Numbers Related to 6115-01-143-3311
Freight Information 6115-01-143-3311
6115-01-143-3311 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062075. A Sub NMFC of Z. It has a NMFC Description of GENERATORS-ENGINES COMBINED. 6115-01-143-3311 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 6115-01-143-3311 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6115-01-143-3311 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 590 for ocean manifesting and military sealift. 6115-01-143-3311 is not classified as a special type of cargo when transported by water. 6115-01-143-3311 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6115-01-143-3311
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 42.0" H x 29.0" W x 31.0" L
- --
- --
- --
- Special Requirements
- 42.0" H x 29.0" W x 31.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
