6115-01-046-0135
Alternating Current Generator
6115010460135 010460135 D987-3 MS/WS6094
A generator having a characteristic of current and voltage that is continually reversing in direction of flow at regular intervals. Does not include rotary inverters, motor-generators, generator sets, synchros, and frequency or phase changers. Excludes GENERATOR, TACHOMETER. View more Alternating Current Generator
October 2025
8
Marketplace 6115-01-046-0135
Request a Quotation from participating marketplace vendors
Related Documents 6115-01-046-0135 5+ Documents (More...)
/fsc-6115/us 6115-01-046-0135 Alternating Current Generator 6115010460135 D987-3MS/WS6094 A generator
Alternating Current Generator 6115010460135 D987-3MS/WS6094 A generator 6115010460135 D987-3MS/
Alternating Current Generator 6115010460135 D987-3MS/ https//www.nsnlookup.com /fsg-61/fsc https
AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Air Force (DF)LAConsolidated With 6115-01-046-0135
6115002841209 002841209 123-1859 6115-01-435-9015 6115-01-173-9636 6115-00-678-6319 6115-01-123-7589 6115-01-046-0135
071-5441 6115-01-502-5822 6115-01-047-9330 6115-01-435-9015 6115-01-123-7589 6115-00-678-6319 6115-01-046-0135
Restrictions 6115-01-046-0135
6115-01-046-0135 is a Alternating Current Generator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 6115-01-046-0135
- Greece (ZU01)
- Effective Date:
- 1 Jun 2006
Approved Sources 6115-01-046-0135
- Part Number
- Manufacturer
- Status
- D987-3
- Manufacturer
- 44180 - Emerson Electric Co Emerson (Obsolete)
- Original Design
- Original Design
- MS/WS6094
- 44180 - Emerson Electric Co Emerson (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6115-01-046-0135
- Characteristic
- Specifications
- FIIG
- Specifications
- A271A0
- Overall Length [AAJU]
- 17.969 Inches
- Overall Width [AAJV]
- 13.875 Inches
- Overall Height [AAJT]
- 13.938 Inches
- Length Of Shaft From Housing [CWCS]
- 4.875 Inches Single End
- Shaft Center To Mounting Surface Distance [CWDM]
- 7.031 Inches Single End
- Mounting Method [AXGY]
- Fixed Base
- Mounting Facility Type And Quantity [AXHR]
- 4 Unthreaded Hole
- Nominal Center To Center Distance Between Mounting Facilities Parallel To Length [CWDT]
- 9.500 Inches
- Nominal Center To Center Distance Between Mounting Facilities Parallel To Width [CWFY]
- 11.000 Inches
- Shaft End Characteristic [CWHZ]
- A9 Single Style Single End
Similar Supply Items to 6115-01-046-0135
Freight Information 6115-01-046-0135
6115-01-046-0135 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of C. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI SUB3. 6115-01-046-0135 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6115-01-046-0135 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 590 for ocean manifesting and military sealift. 6115-01-046-0135 is not classified as a special type of cargo when transported by water. 6115-01-046-0135 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6115-01-046-0135
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- Special requirements
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- No Requirement
