6115-00-726-7933
Gasoline Engine Generator Set
6115007267933 007267933 MILG52373
A generator set using a gasoline engine as the prime mover. Excludes GENERATOR SET, GASOLINE ENGINE, TRAILER MOUNTED. View more Gasoline Engine Generator Set
May 2023
8
Marketplace 6115-00-726-7933
Request a Quotation from participating marketplace vendors
Related Documents 6115-00-726-7933 4+ Documents (More...)
Gasoline Engine Generator Set 6115007267933 www.nsnlookup.com /nato/nato-stock-numbers/inc Gasoline
Commercial Supplier with the Cage Code 5J288 and is tracked by Dun & Bradstreet under DUNS Number 007267933
Restrictions 6115-00-726-7933
6115-00-726-7933 is a Gasoline Engine Generator Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6115-00-726-7933
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6115-00-726-7933
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 6115-00-726-7933
- Part Number
- Manufacturer
- Status
- MILG52373
- Manufacturer
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 6115-00-726-7933
- Characteristic
- Specifications
- FIIG
- Specifications
- T322-A
- Ac Wattage Rating [AYGY]
- 400.0 Watts
- Ambient Temp In Deg Celsius [AZCL]
- 57.2
- Automatic Starting Feature [AZBM]
- Not Provided
- Dc Voltage Rating [ACYR]
- 28.0 Volts Nominal
- Dc Wattage Rating [AYHA]
- 80.0 Watts
- End Item Identification [AGAV]
- Type No. An/Tps-21
- Excitor Type [AYHE]
- Self-Excited
- Excitor [AYHF]
- Not Included
- Frequency Rating [ACZB]
- 400.0 Hertz Nominal
- Housing Type [AZCB]
- Inclosed
- Identifying Number [AMSB]
- Gj1391-1 Part No. And Gj1391-1 Drawing No.
- Current Type [ACDC]
- Ac And Dc
- Mounting Type [AAXX]
- Shock
- Inclosure Type [AKNA]
- Fully Inclosed
- Line To Line Voltage In Volts [AYHB]
- 115.0
- Manufacturer Name [AQGA]
- Admiral Corp
- Power Factor In Percent [AYHD]
- 0.9
- Prime Mover Manufacturer Name [AZBN]
- Briggs And Stratton Co
- Prime Mover Starting Method [AYQZ]
- Manually By Rope
- Prime Mover Cooling Medium [AAXS]
- Air
- Prime Mover Identifying Number [AZBP]
- Aip-A Model No.
- Radio Interference Suppression [AZKT]
- Included
- Overall Height [ABKW]
- 13.750 Inches Nominal
- Overall Length [ABHP]
- 15.750 Inches Nominal
- Overall Width [ABMK]
- 15.750 Inches Nominal
- Phase [FAAZ]
- Single
- Special Features [FEAT]
- Operates Reliable Over Temp Range Of Minus 65 Deg F To Plus 135 Deg F At Sea Level And To Plus 85 Deg F At 10,000 Ft Above Sea Level
- Winterization Feature [AMWJ]
- Included
NATO Stock Numbers Related to 6115-00-726-7933
Freight Information 6115-00-726-7933
6115-00-726-7933 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062075. A Sub NMFC of Z. It has a NMFC Description of GENERATORS-ENGINES COMBINED. 6115-00-726-7933 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 6115-00-726-7933 is rated as class 70 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6115-00-726-7933 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 590 for ocean manifesting and military sealift. 6115-00-726-7933 is not classified as a special type of cargo when transported by water. 6115-00-726-7933 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
