6115-00-420-8486
Gas Turbine Engine Generator Set
6115004208486 004208486 MILG38195A AM32A60A 69E39110
A generator set using a gas turbine engine as a prime mover. Excludes GENERATOR SET, GAS TURBINE ENGINE, TRAILER MOUNTED and GENERATOR SET, GAS TURBINE ENGINE, SEMITRAILER MOUNTED. View more Gas Turbine Engine Generator Set
May 2023
40
Marketplace 6115-00-420-8486
Request a Quotation from participating marketplace vendors
Related Documents 6115-00-420-8486 4+ Documents (More...)
.. 69E39110 GENERATOR SET,GAS TURBINE ENGINE RQST NS Request Quotation Updated Every Day 6115-00-420-
8486 RQST NE Updated Every Day 6115-00-420-8486 RQST Updated Every Day 6115-00-420-8486 RQST NE Related
Gas Turbine Engine Generator Set 004208486 Identification [AGAV]Am32a-60A Gen Set Nsn 6115004208486
Datasheet 2835-00-256-0374 CharacteristicSpecificationsFIIGA530F0End Item Identification [AGAV]6115-00-420-8486
Gas Turbine Engine Generator Set 004208486 CharacteristicSpecificationsFIIGA530F0End Item Identification
[AGAV]6115-00-420-8486 https//www.nsnlookup.com /fsg-61/fsc-6150/us 6150-01-245-7365 6150012457365 012457365,305986
/www.nsnlookup.com /fsg-59/fsc-5935/us 5935-01-206-9422 Connector Adapter 5935012069422012069422 AM32A60A
/www.nsnlookup.com /fsg-59/fsc-5935/us 5935-01-206-9422 Connector Adapter 5935012069422012069422 AM32A60A
Restrictions 6115-00-420-8486
IUID Required
6115-00-420-8486 is a Gas Turbine Engine Generator Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). The precious metals content of this item is unknown.
Import and Export 6115-00-420-8486
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6115-00-420-8486
- US Air Force (FGG4)
- Effective Date:
- 1 Sep 2000
- Former MOE Rule:
- FAA4
- US Navy (NSGS)
- Effective Date:
- 1 Jun 2009
- Supplementary Receivers:
- GG
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Oct 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Feb 2007
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Sep 2012
Approved Sources 6115-00-420-8486
- Part Number
- Manufacturer
- Status
- 69E39110
- Manufacturer
- 98752 - Warner Robins Air Logistics Center (Active)
- Primary Buy
- Primary Buy
- MILG38195A
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- AM32A60A
- 80049 - Department Of The Air Force (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 69E39110
- 98749 - Sacramento Air Logistics Center (Obsolete)
- Informational Drawing
- Informational Drawing
Datasheet 6115-00-420-8486
- Characteristic
- Specifications
- FIIG
- Specifications
- T322-A
- Ac Wattage Rating [AYGY]
- 60.0 Kilowatts
- Cranking Current In Amps [AYSB]
- 200.0
- Cranking Voltage In Volts [AYSA]
- 24.0
- Excitor Type [AYHE]
- Self-Excited
- Frequency Rating [ACZB]
- 400.0 Hertz Nominal
- Functional Description [FTLD]
- Used To Supply Ac And Dc Electrical Power,As Well As Pneumatic Power For Ground Support Of Certain Acft
- Mounting Type [AAXX]
- Wheel
- Line To Line Voltage In Volts [AYHB]
- 208.0
- Line To Neutral Voltage In Volts [AYHC]
- 120.0
- Power Factor In Percent [AYHD]
- 75.0
- Prime Mover Identifying Number [AZBP]
- Gtc85-180 Model No.
- Prime Mover Manufacturer Name [AZBN]
- Airesearch Mfg Co
- Reference Data And Literature [RDAL]
- T.O. 35C2-3-372-11
- Overall Height [ABKW]
- 67.000 Inches Nominal
- Overall Length [ABHP]
- 90.000 Inches Nominal
- Overall Width [ABMK]
- 67.000 Inches Nominal
- Phase [FAAZ]
- Three
- Special Features [FEAT]
- Pneumatic Capability,150 Porm 5 Lbs/Minute At 49 Porm2 Psia /34-3 Psig Porm 2 Psig/. 59 Deg F,29.92 In. Hg. Barometer
Management Data 6115-00-420-8486
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- May 2011
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- G
- Replaces 6115-00-225-7663
- AAA
- G
- Department of the Air Force (DF)
- L
- G
- Replaces 6115-01-123-7589
- AAB
- G
- Department of the Air Force (DF)
- L
- R
- Refer To Afto 375 Reqd
- AFTO 375 REQD
- R
- Department of the Air Force (DF)
- L
- Dod I&S Family Master Nsn - - -
- AAC
- Department of the Navy (DN)
- N
- 7
- Substitute For 6115-01-123-7589
- AAA
- 7
- Department of the Navy (DN)
- N
- Dod I&S Family Master Nsn - - -
- ABA
Air Force
- Budget:
- M
- 57X3080 - Other Base Maintenance and Support Equipment
- Aggregation Code:
- ID
- GENERATORS AND GENERATOR SETS, GROUND
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - S
- Reparable. Condemn at Depot. AF Equipment Management System (AFEMS).
Navy
- Cognizance:
- 6R
- Bypass
- Special Material ID:
- SX
- Special Aircraft and Engine Tool and Support Equipment/Parts
- Issue, Repair, Requisition Restriction Code:
- 00
- No Restriction
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
NATO Stock Numbers Related to 6115-00-420-8486
Freight Information 6115-00-420-8486
6115-00-420-8486 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of C. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI SUB3. 6115-00-420-8486 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. 6115-00-420-8486 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6115-00-420-8486 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 738 for ocean manifesting and military sealift. 6115-00-420-8486 is not classified as a special type of cargo when transported by water. 6115-00-420-8486 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6115-00-420-8486
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 134.0" H x 64.0" W x 79.5" L
- --
- --
- --
- Any Suitable Process
- 134.0" H x 64.0" W x 79.5" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- MIL-C-104, Type II, Class 2, Bolted Wood Crate, Plywood Sheathed
- Special requirements
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
