6115-00-225-7663
Gas Turbine Engine Generator Set
6115002257663 002257663 TYPEM32A60 6314-110
A generator set using a gas turbine engine as a prime mover. Excludes GENERATOR SET, GAS TURBINE ENGINE, TRAILER MOUNTED and GENERATOR SET, GAS TURBINE ENGINE, SEMITRAILER MOUNTED. View more Gas Turbine Engine Generator Set
May 2023
17
Marketplace 6115-00-225-7663
Request a Quotation from participating marketplace vendors
Related Documents 6115-00-225-7663 4+ Documents (More...)
/us 6115-00-225-7663 Gas Turbine Engine Generator Set 002257663 www.nsnlookup.com /fsg-61/fsc-6115/us
Gas Turbine Engine Generator Set 002257663 www.nsnlookup.com /fsg-61/fsc-6115/us 6115-00-225-7663 https
1378 RQST NE Related Documents 5975-01-655-1378 https//www.nsnlookup.com /fsg-61/fsc-6115/us 6115-00-225-7663
Gas Turbine Engine Generator Set 002257663 www.nsnlookup.com /fsg-61/fsc-6115/us 6115-00-225-7663
https 6115011793863011793863 Day 6115-01-179-3863 https//www.nsnlookup.com /fsg-61/fsc-6115/us 6115-00-225-7663
Gas Turbine Engine Generator Set 002257663 123-7589 Turbine Engine Generator Set 002257663 https
Gas Turbine Engine Generator Set 002257663 Gas Turbine Engine Generator Set 011237589 7589 Gas
Turbine Engine Generator Set 011237589 https Turbine Engine Generator Set 002257663 www.nsnlookup.com
Restrictions 6115-00-225-7663
IUID Required
6115-00-225-7663 is a Gas Turbine Engine Generator Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. The DCMO has forced the Demilization requirements for this item as the ICP has not collaborated. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6115-00-225-7663
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6115-00-225-7663
- US Air Force (FGG4)
- Effective Date:
- 1 Sep 2000
- Former MOE Rule:
- FAA4
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 6115-00-225-7663
- Part Number
- Manufacturer
- Status
- 6314-110
- Manufacturer
- 87823 - Wolverine Diesel Power Co (Obsolete)
- Original Design
- Original Design
- TYPEM32A60
- 80049 - Department Of The Air Force (Active)
- Secondary Buy
- Secondary Buy
Datasheet 6115-00-225-7663
- Characteristic
- Specifications
- FIIG
- Specifications
- T322-A
- Ac Wattage Rating [AYGY]
- 75.0 Kilovolt-Ampere
- Cranking Voltage In Volts [AYSA]
- 24.0
- Cranking Current In Amps [AYSB]
- 100.0
- Dc Voltage Rating [ACYR]
- 28.0 Volts Nominal
- Direct Current Rating In Amps [ACUT]
- 500.0
- Excitor Type [AYHE]
- Self-Excited
- Excitor [AYHF]
- Not Included
- Frequency Rating [ACZB]
- 400.0 Hertz Nominal
- Current Type [ACDC]
- Ac And Dc
- Mounting Type [AAXX]
- Wheel
- Line To Line Voltage In Volts [AYHB]
- 208.0
- Line To Neutral Voltage In Volts [AYHC]
- 120.0
- Power Factor In Percent [AYHD]
- 80.0
- Prime Mover Identifying Number [AZBP]
- Gtc+85-397 Model No.
- Prime Mover Manufacturer Name [AZBN]
- Airesearch Mfg Co
- Overall Height [ABKW]
- 67.000 Inches Nominal
- Overall Length [ABHP]
- 90.000 Inches Nominal
- Overall Width [ABMK]
- 67.000 Inches Nominal
- Phase [FAAZ]
- Three
- Special Features [FEAT]
- Pneumatic Capability,120 Porm 4 Lbs/Minute At 49 Porm 2 Psia/34.3 Psig Porm 2 Psig/,59 Deg F,29.92 In. Hg. Barometer
Management Data 6115-00-225-7663
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Dec 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- E
- Replaced By 6115-00-420-8486
- E
- Department of the Air Force (DF)
- L
- R
- Refer To Afto 375 Reqd
- AFTO 375 REQD
- R
Air Force
- Budget:
- A
- 57X3010 - Common Aircraft Ground Support Equipment
- Aggregation Code:
- ID
- GENERATORS AND GENERATOR SETS, GROUND
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - U
- Reparable. Condemn at Intermediate. AF Equipment Management System (AFEMS).
NATO Stock Numbers Related to 6115-00-225-7663
Freight Information 6115-00-225-7663
6115-00-225-7663 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of C. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI SUB3. 6115-00-225-7663 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. 6115-00-225-7663 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6115-00-225-7663 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 738 for ocean manifesting and military sealift. 6115-00-225-7663 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 6115-00-225-7663 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6115-00-225-7663
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 134.0" H x 64.0" W x 79.5" L
- --
- --
- --
- Any Suitable Process
- 134.0" H x 64.0" W x 79.5" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- MIL-C-104, Type II, Class 2, Bolted Wood Crate, Plywood Sheathed
- Special requirements
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
