6110-01-532-1835
Power Distribution Panel
6110015321835 015321835 DB350MA-P2WAS3 DB350MA-P2WQA3
A panel designed for connecting, disconnecting and protecting power line feeders and/or direct control of specific electric devices such as lights, motors, electronic equipment, and the like. See also FUSE BOX; SWITCH BOX; DISTRIBUTION BOX; and PANEL,POWER BUS,CURCUIT BREAKER. View more Power Distribution Panel
May 2023
7
Marketplace 6110-01-532-1835
Request a Quotation from participating marketplace vendors
Related Documents 6110-01-532-1835 5+ Documents (More...)
/fsg-61/fsc-6110/us
disconnecting and protecting power line /fsg-61/fsc-6110/us 6110-01-532-1835 /fsg-61/fsc-6110/us 6110
Power Distribution Panel 6110015321835 Panel 6110015321835 www.nsnlookup.com Distribution https
Power Distribution Panel 6110015321835 Panel 6110015321835 www.nsnlookup.com Distribution https
Day 6145-01-549-1954 RQST Updated https//www.nsnlookup.com www.nsnlookup.com Distribution Panel 6110015321835
Power Distribution Panel 6110015321835 www.nsnlookup.com Distribution Panel 6110015321835 https
Datasheet 5975-01-549-2507 CharacteristicSpecificationsFIIGA05500End Item Identification [AGAV] 6110-01-532-1835
Power Distribution Panel 6110015321835 www.nsnlookup.com /fsg-61/fsc-6110/us 6110-01-532-1835 https
CharacteristicSpecificationsFIIGT12400Core Outside Diameter [ALNE]15.000 Inches NominalEnd Item Identification [AGAV] 6110-01-532-1835
Power Distribution Panel 6110015321835 www.nsnlookup.com Distribution Panel 6110015321835 https
CharacteristicSpecificationsFIIGT12400Core Outside Diameter [ALNE]15.000 Inches NominalEnd Item Identification [AGAV] 6110-01-532-1835
Restrictions 6110-01-532-1835
IUID Required
6110-01-532-1835 is a Power Distribution Panel that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. The DCMO has forced the Demilization requirements for this item as the ICP has not collaborated. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 6110-01-532-1835
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6110-01-532-1835
- Office of the Secretary of Housing & Urban Development (MM33)
- Effective Date:
- 1 Aug 2005
- Brazil (YA01)
- Effective Date:
- 1 May 2012
- Canada (ZC01)
- Effective Date:
- 1 Apr 2016
Approved Sources 6110-01-532-1835
- Part Number
- Manufacturer
- Status
- DB350MA-P2WAS3
- Manufacturer
- 00Y95 - Lex Products, Llc (Active)
- Primary Buy
- Primary Buy
- DB350MA-P2WQA3
- 00Y95 - Lex Products, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6110-01-532-1835
- Characteristic
- Specifications
- FIIG
- Specifications
- T122-G
- Cubic Measure [AFJK]
- 168.000 Cubic Inches
- Output Frequency Rating [ANSQ]
- 60 Hertz
- Output Voltage Rating [APPA]
- 120.0 Ac Volts Minimum And 208.0 Ac Volts Maximum
- Overall Height [ABKW]
- 31.000 Inches Nominal
- Overall Length [ABHP]
- 36.250 Inches Nominal
- Overall Width [ABMK]
- 26.250 Inches Nominal
- Part Name Assigned By Controlling Agency [CXCY]
- 100 Kilowatt Power Distribution Panel
- Phase [FAAZ]
- Single And Three
- Unpackaged Unit Weight [AWJN]
- 268.000 Pounds
DLA Procurement Analysis 6110-01-532-1835
- DLA Administrative Lead Time:
- Subscribe
Management Data 6110-01-532-1835
Marine Corps
- Stores Account:
- 3
- Appropriation Stores Account Principal Item
- Combat Essentiality:
- 1
- Combat Essential End Item
- Echelon Management:
- 43
- Material Identification:
- A
- Type 1 End Items
- Operational Test:
- 0
- Physical Category:
- 2
- Bulk
Similar Supply Items to 6110-01-532-1835
Freight Information 6110-01-532-1835
6110-01-532-1835 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of A. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI SUB1. 6110-01-532-1835 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6110-01-532-1835 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 590 for ocean manifesting and military sealift. 6110-01-532-1835 is not classified as a special type of cargo when transported by water. 6110-01-532-1835 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6110-01-532-1835
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 36.3" H x 26.3" W x 31.0" L
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 40.3" H x 30.3" W x 35.0" L
- --
- --
- --
- Any Suitable Process
- 40.3" H x 30.3" W x 35.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-PRF-81705, Type III, Class 1, Transparent, Electrostatic Protective, Static Shielding, Barrier Material or MIL-DTL-117, Type II, Class H, Style 2 bag
- Cushion, Anchor, Block or Brace as Required
- 1/2 inch thick
- ASTM-D6256, Class 1, Domestic, Wood-Cleated Skidded Box
- ESD sensitive electronic device requirements of MIL-STD-129 apply
- MIL-PRF-81705, Type III, Class 1, Transparent, Electrostatic Protective, Static Shielding, Barrier Material or MIL-DTL-117, Type II, Class H, Style 2 bag
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- No Requirement
