6110-01-118-5905
Motor Starter
6110011185905 011185905 14GP32AJ81 14GF32AJ71 14GP32AJ71 10903
A device primarily designed to control the supply circuit(s) of a motor in order to accelerate the motor from rest to normal speed. Includes manual starters with overload protection and manual, automatic or semiautomatic starters consisting of combinations of items such as relays, resistors, switches, circuit breakers, and the like. Excludes RELAY-SWITCH; CIRCUIT BREAKER; SWITCH (as modified) and RELAY (as modified). For devices, which in addition to starting and stopping, reverse, select and/or regulate the speed of a motor, see CONTROLLER (as modified). View more Motor Starter
May 2023
7
Marketplace 6110-01-118-5905
Request a Quotation from participating marketplace vendors
Related Documents 6110-01-118-5905 5+ Documents (More...)
Quotation Updated Every Day 6110-01-118-5905 RQST NE Updated Every Day 6110-01-118-5905 RQST Updated
Every Day 6110-01-118-5905 RQST NE Related Documents 6110-01-118-5905 5+ Documents ( More... ) https
https//www.nsnlookup.com /fsg-61/fsc-6110/us 6110-01-118-5905 Motor Starter 6110011185905 011185905
Upgrade your Account Upgrade 6110-01-118-5905Motor Starter6110011185905 011185905 14GP32AJ81 14GF32AJ71
/fsg-53/fsc-5360/uk
LR201-10903 X3XCLR201-10903 42AA1905 An open-or close-coiled spring, wound in various forms and from
Battery 6135015653284,10903 MOTOR 1200 EA NS Request Quotation Subscribe to View Vendor Details... 10903
Restrictions 6110-01-118-5905
6110-01-118-5905 is a Motor Starter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6110-01-118-5905
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6110-01-118-5905
- US Air Force (FXGG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- FXCX
Approved Sources 6110-01-118-5905
- Part Number
- Manufacturer
- Status
- 14GP32AJ81
- Manufacturer
- 23826 - Siemens Energy And Automation Inc (Active)
- Primary Buy
- Primary Buy
- 14GF32AJ71
- 23826 - Siemens Energy And Automation Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 14GP32AJ71
- 23826 - Siemens Energy And Automation Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 10903
- 90598 - Engineered Air Systems Inc. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6110-01-118-5905
- Characteristic
- Specifications
- FIIG
- Specifications
- A541C0
- Duty Cycle [AKPS]
- Continuous
- Ac Voltage Rating [ACYN]
- 600.0 Volts Maximum
- Actuation Method [AFLW]
- Magnetic
- Actuator Voltage [ANDE]
- 24.0 Ac
- Control Type [AQZF]
- Local
- Frequency In Hertz [FREQ]
- 50.0 And 60.0
- Frequency Rating [ACZB]
- 50.0 Hertz Minimum And 60.0 Hertz Maximum
- Hazardous Locations/Environmental Protection [ABFE]
- Fungus Resistant
- Horsepower Rating [ANCY]
- 15.000 And 30.000
- Mounting Configuration [ALGC]
- Three Mtg Holes On Isosceles 10-1/2 In. By 6 In. C To C
- National Electrical Manufacturers Association Standards Design [ANQC]
- Designed Per Nema Std
- Operating Voltage Characteristic [ANCN]
- Full
- Inclosure Feature [ANPZ]
- Open
- Load Protection Type [ANDW]
- Overload
- Size Designator [AJXE]
- 2-1/2
- Overall Height [ABKW]
- 4.688 Inches Nominal
- Overall Length [ABHP]
- 13.500 Inches Nominal
- Overall Width [ABMK]
- 7.812 Inches Nominal
- Performance Type [AGLD]
- Manual
- Phase [FAAZ]
- Three
- Special Features [FEAT]
- Capable Of Proper Operation When Tilted Up To 8.5 Deg In Any Direction From The Normal Mtg Position
- Speed Adjustments [ABBB]
- 0 To Full Speed
- Switch Functional Positions [ANRK]
- Reset
DLA Procurement Analysis 6110-01-118-5905
Management Data 6110-01-118-5905
Similar Supply Items to 6110-01-118-5905
Freight Information 6110-01-118-5905
6110-01-118-5905 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 130395. A Sub NMFC of X. It has a NMFC Description of STARTERS OR STARTER MOTORS. 6110-01-118-5905 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6110-01-118-5905 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 6110-01-118-5905 is not classified as a special type of cargo when transported by water. 6110-01-118-5905 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6110-01-118-5905
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- Cushion, Anchor, Block or Brace as Required
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 6110-01-118-5905 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
