6105-01-179-9090
Alternating Current Motor
6105011799090 011799090 M8009T 00781568214046
A motor which is designed for operation from an alternating current source. See also MOTOR, CONTROL. View more Alternating Current Motor
May 2023
12
Marketplace 6105-01-179-9090
Request a Quotation from participating marketplace vendors
Related Documents 6105-01-179-9090 2+ Documents (More...)
BUY NE FedMall Updated Every Day 6105-01-179-9090 RQST NE Updated Every Day 6105-01-179-9090 RQST
Updated Every Day 6105-01-179-9090 RQST NE Related Documents 6105-01-179-9090 2+ Documents ( More...
www.nsnlookup.com /fsg-61/fsc-6105/us 6105-01-695 https//www.nsnlookup.com /fsg-61/fsc-6105/us 6105-01-179-9090
Alternating Current Motor 6105011799090 day Upgrade your Account Upgrade 6105-01-179-9090Alternating
Restrictions 6105-01-179-9090
6105-01-179-9090 is a Alternating Current Motor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 6105-01-179-9090
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 6105-01-179-9090
- US Navy (N9BG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
Approved Sources 6105-01-179-9090
- Part Number
- Manufacturer
- Status
- M8009T
- Manufacturer
- 05472 - Baldor Electric Co (Replaced)
- Original Design
- Original Design
- 00781568214046
- 05472 - Baldor Electric Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- M8009T
- 46UR5 - Abb Motors & Mechanical Inc (Active)
- Advisory Reference
- Advisory Reference
- 00781568214046
- 46UR5 - Abb Motors & Mechanical Inc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 6105-01-179-9090
- Characteristic
- Specifications
- FIIG
- Specifications
- A271A0
- Duty Cycle [AKPS]
- Continuous
- Connection Type And Voltage Rating In Volts [CWGQ]
- 460.0 Line To Neutral Single Input
- Cooling Method [BFMF]
- Ambient Air
- Features Provided [CBBL]
- Horizontal Mounting Position
- Frame Size Designation [CNMM]
- 215T
- Frequency In Hertz [FREQ]
- 60.0 Input
- Mounting Facility Type And Quantity [AXHR]
- 4 Unthreaded Hole
- Mounting Method [AXGY]
- Fixed Base
- Nominal Center To Center Distance Between Mounting Facilities Parallel To Length [CWDT]
- 5.500 Inches
- Nominal Center To Center Distance Between Mounting Facilities Parallel To Width [CWFY]
- 8.250 Inches
- Overall Length [AAJU]
- 19.062 Inches
- Inclosure Feature [ANPZ]
- Totally Inclosed
- Inclosure Specification [BKPQ]
- Nema
- Keyway Width [ABRR]
- 0.312 Inches Nominal Single End
- Keyway Depth [ABRV]
- 0.312 Inches Nominal Single End
- Keyway Length [AFYS]
- 2.375 Inches Nominal Single End
- Length Of Shaft From Housing [CWCS]
- 3.875 Inches Single End
- Power Rating [CNXS]
- 10.000 Horsepower Output
- Rotor Speed Rating In Rpm [CWFX]
- 1725.0 Single Full Load
- Shaft Diameter [ABWV]
- 1.375 Inches Nominal Single End
- Shaft End Characteristic [CWHZ]
- A9 Single Style Single End
- Shaft Rotation Direction [AKCT]
- Clockwise Single End Or Counterclockwise Single End
- Overall Height [AAJT]
- 10.188 Inches
- Overall Width [AAJV]
- 11.744 Inches
- Phase [FAAZ]
- Three Input
- Winding Type [AXCP]
- Induction-Squirrel Cage
- Terminal Type And Quantity [TTQY]
- 9 Wire Lead
Weapon Systems (WSDC) 6105-01-179-9090
DLA Procurement Analysis 6105-01-179-9090
Management Data 6105-01-179-9090
Navy
- Cognizance:
- 3B
Similar Supply Items to 6105-01-179-9090
Freight Information 6105-01-179-9090
6105-01-179-9090 has freight characteristics managed by the US Postal Service (USPS).It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of Z. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI. 6105-01-179-9090 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6105-01-179-9090 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 6105-01-179-9090 is not classified as a special type of cargo when transported by water. 6105-01-179-9090 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6105-01-179-9090
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- 2lb to 5lb, all dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
