6105-00-343-1646
Alternating Current Motor
6105003431646 003431646 3A92X
A motor which is designed for operation from an alternating current source. See also MOTOR, CONTROL. View more Alternating Current Motor
May 2023
7
Marketplace 6105-00-343-1646
Request a Quotation from participating marketplace vendors
Related Documents 6105-00-343-1646 1+ Documents (More...)
RQST NE Updated Every Day 6105-00-343-1646 RQST Updated Every Day 6105-00-343-1646 RQST NE Related Documents
6105-00-343-1646 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-61/fsc-6105/us 6105-00-343-1646
Restrictions 6105-00-343-1646
6105-00-343-1646 is a Alternating Current Motor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 6105-00-343-1646
- US Navy (N9BG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- NIGD
- Supplementary Collaborators:
- HD
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 6105-00-343-1646
- Part Number
- Manufacturer
- Status
- 3A92X
- Manufacturer
- 12763 - Dynalec Corporation (Active)
- Original Design
- Original Design
- 3A92X
- 20049 - The Electric Tachometer Corp. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 6105-00-343-1646
- Characteristic
- Specifications
- FIIG
- Specifications
- A271A0
- Duty Cycle [AKPS]
- Continuous
- Connection Type And Voltage Rating In Volts [CWGQ]
- 80.0 Line To Neutral Single Input
- Cooling Method [BFMF]
- Nonventilated
- Features Provided [CBBL]
- Horizontal Mounting Position And Vertical Mounting Position
- Frequency In Hertz [FREQ]
- 60.0 Input
- Mounting Facility Circle Diameter [CWFQ]
- 1.281 Inches
- Mounting Facility Type And Quantity [AXHR]
- 3 Threaded Hole
- Mounting Method [AXGY]
- Face
- Overall Length [AAJU]
- 2.531 Inches
- Inclosure Feature [ANPZ]
- Totally Inclosed
- Inclosure Specification [BKPQ]
- Commercial
- Length Of Shaft From Housing [CWCS]
- 0.266 Inches Single End
- Power Rating [CNXS]
- 0.0010 Horsepower Output
- Rotor Speed Rating In Rpm [CWFX]
- 3600.0 Single Full Load
- Shaft Diameter [ABWV]
- 0.2188 Inches Nominal Single End
- Shaft End Characteristic [CWHZ]
- A14 Single Style Single End
- Shaft Rotation Direction [AKCT]
- Counterclockwise Single End
- Overall Height [AAJT]
- 1.750 Inches
- Overall Width [AAJV]
- 1.750 Inches
- Phase [FAAZ]
- Single Input
- Winding Type [AXCP]
- Synchronous Split Phase
- Spline Length [AXFH]
- 0.2600 Inches Nominal Single End
- Spline Minor Diameter [AAUH]
- 0.1988 Inches Nominal Single End
- Spline Quantity [ABSA]
- 8 Single End
- Terminal Type And Quantity [TTQY]
- 4 Wire Lead
DLA Procurement Analysis 6105-00-343-1646
Management Data 6105-00-343-1646
Navy
- Cognizance:
- 3B
Similar Supply Items to 6105-00-343-1646
Freight Information 6105-00-343-1646
6105-00-343-1646 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of Z. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI. 6105-00-343-1646 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 6105-00-343-1646 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 6105-00-343-1646 is not classified as a special type of cargo when transported by water. 6105-00-343-1646 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 6105-00-343-1646
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 6105-00-343-1646 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
